Contract No. HY/2010/02 – Hong Kong-Zhuhai-Macao Bridge
Hong Kong Boundary Crossing Facilities – Reclamation Works (here below, known
as “the Contract”) mainly comprises reclamation at the northeast of the
Hong Kong International Airport of an area of about 130-hectare for the
construction of an artificial island for the development of the Hong Kong
Boundary Crossing Facilities (HKBCF), and about 19-hectare for the southern
landfall of the Tuen Mun - Chek Lap Kok Link (TMCLKL). It is a designated Project
and is governed by the current permits for the Project, i.e. the amended
Environmental Permits (EPs) issued on 11 April 2016 (EP-353/2009/K) and 13 March
2015 (EP-354/2009/D) (for TMCLKL Southern Landfall Reclamation only).
Ove Arup & Partners Hong Kong Limited (Arup) was appointed
by Highways Department (HyD) as the consultants for the design and construction
assignment for the Project’s reclamation works (i.e. the Engineer for the Contract).
China Harbour Engineering Company Limited (CHEC) was
awarded by HyD as the Contractor to undertake the construction work of the Contract.
Ramboll Hong Kong Limited was employed by HyD as the
Independent Environmental Checker (IEC) and Environmental Project Office (ENPO)
for the Project.
AECOM Asia Co. Ltd. (AECOM) was appointed by CHEC to
undertake the role of Environmental Team for the Contract for carrying out the
environmental monitoring and audit (EM&A) works.
The construction phase of the Project under the EPs was
commenced on 12 March 2012. The EM&A programme, including air quality,
noise, water quality and dolphin monitoring and environmental site inspections,
was commenced on 12 March 2012.
This report documents the
findings of EM&A works conducted in the period between 1
and 30 April 2018. As informed by the Contractor, major
activities in the reporting period was:-
Land-base
-
Maintenance works of Site Office at Works Area WA2
(*WA2 was evacuated in the end of Mar 2018 and
pending for handover)
A summary of monitoring* and audit activities conducted
in the reporting period is listed below:
Environmental site inspection
|
4 sessions
|
*monitoring works for the
Contract are covered by Contract No. HY/2013/01 Hong Kong-Zhuhai Macao Bridge
HKBCF – Passenger Clearance Building.
Breaches of Action and Limit
Levels for Air Quality
For impact air quality monitoring, no
exceedance was recorded at all monitoring stations by Environmental Team of
Contract No. HY/2013/01 in the reporting month.
Breaches of Action and Limit
Levels for Noise
For construction noise monitoring, no
exceedance was recorded at all monitoring stations by Environmental Team of
Contract No. HY/2013/01 in the reporting month.
Breaches of Action and
Limit Levels for Water Quality
For impact water quality
monitoring, 3 action level exceedances of suspended solids at SR7 during flood
tide on 18 and 23 April 2018, and at IS10(N) during flood tide on 20 April 2018.
After investigation, no marine-based work was conducted on the monitoring dates
as confirmed by the contractor. It was concluded that the recorded exceedances
were not Contract-related. No other water quality exceedance was recorded at
all monitoring stations by Environmental Team of Contract No. HY/2013/01 in the
reporting month. For level of exceedance, location and when exceedances were
recorded, please refer to Appendix D.
Breaches of Action and Limit Levels for Impact Dolphin Monitoring
Impact dolphin monitoring results
at all transects are reported in EM&A Report prepared for Contract No.
HY/2013/01.
Complaint, Notification of Summons and Successful
Prosecution
No complaint, notification of summons
or prosecution was received in the reporting period.
Reporting Change
No reporting change in this
reporting month.
Future Key Issues
Key
issues to be considered in the coming month included:
-
Site runoff should be properly collected and treated prior to
discharge;
-
Regular review and maintenance of silt curtain systems, drainage
systems and desilting facilities;
-
Exposed surfaces/soil stockpiles should be properly treated to
avoid generation of silty surface run-off during rainstorm;
-
Regular review and maintenance of wheel washing facilities
provided at all site entrances/exits;
-
Conduct regular inspection of various working machineries and
vessels within works areas to avoid any dark smoke emission;
-
Suppress dust generated from work processes with use of bagged
cements, earth movements, excavation activities, exposed surfaces/soil
stockpiles and haul road traffic;
-
Quieter powered mechanical equipment should be used;
-
Provision of proper and effective noise control measures for
operating equipment and machinery on-site, such as erection of movable noise
barriers or enclosure for noisy plants;
-
Closely check and replace the sound insulation materials
regularly;
-
Better scheduling of construction works to minimize noise
nuisance;
-
Properly store and label oil drums and chemical containers placed
on site;
-
Proper chemicals, chemical wastes and wastes management;
-
Maintenance works should be carried out within roofed, paved and
confined areas;
-
Collection and segregation of construction waste and general
refuse on land and in the sea should be carried out properly and regularly; and
-
Proper protection and regular inspection of existing trees,
transplanted/retained trees.
-
Control night-time lighting and glare by hooding all lights.
-
Regular review and provide maintenance to dust control measures
such as sprinkler system
1.1.1
Contract No. HY/2010/02 – Hong Kong-Zhuhai-Macao Bridge Hong Kong
Boundary Crossing Facilities – Reclamation Works (here below, known as “the Contract”)
mainly comprises reclamation at the northeast of the Hong Kong
International Airport of an area of about 130-hectare for the
construction of an artificial island for the development of the Hong Kong
Boundary Crossing Facilities (HKBCF), and about 19-hectare for the southern
landfall of the Tuen Mun - Chek Lap Kok Link (TMCLKL).
1.1.2
The environmental impact assessment (EIA) reports (Hong Kong –
Zhuhai – Macao Bridge Hong Kong Boundary Crossing Facilities – EIA Report
(Register No. AEIAR-145/2009) (HKBCFEIA) and Tuen Mun – Chek Lap Kok Link – EIA
Report (Register No. AEIAR-146/2009) (TMCLKLEIA), and their environmental
monitoring and audit (EM&A) Manuals (original EM&A Manuals), for the Project
were approved by Environmental Protection Department (EPD) in October 2009.
1.1.3
EPD subsequently issued the Environmental
Permit (EP) for HKBCF in November 2009 (EP-353/2009) and the Variation of
Environmental Permit (VEP) in June 2010 (EP-353/2009/A), November
2010 (EP-353/2009/B), November 2011 (EP-353/2009/C), March
2012 (EP-353/2009/D), October 2012 (EP-353/2009/E), April 2013 (EP-353/2009/F),
August 2013 (EP-353/2009/G), January 2015 (EP-353/2009/H), July 2015 (EP-353/2009/I), February 2016
(EP-353/2009/J) and April 2016 (EP-353/2009/K). Similarly, EPD issued the
Environmental Permit (EP) for TMCLKL in November 2009 (EP-354/2009) and the
Variation of Environmental Permit (VEP) in December 2010 (EP-354/2009/A),
January 2014 (EP-354/2009/B), December 2014 (EP-354/2009/C) and March 2015
(EP-354/2009/D)
1.1.4
The Project is a designated Project and is governed by the current
permits for the Project, i.e. the amended EPs issued on 11 April 2016 (EP-353/2009/K)
and 13 March 2015 (EP-354/2009/D) (for TMCLKL Southern Landfall Reclamation
only).
1.1.5
A Contract Specific EM&A Manual, which included all Contract -relation
contents from the original EM&A Manuals for the Contract, was issued in May
2012.
1.1.6
Ove Arup & Partners Hong Kong Limited (Arup) was appointed by
Highways Department (HyD) as the consultants for the design and construction
assignment for the Project’s reclamation works (i.e. the Engineer for the Contract).
1.1.7
China Harbour Engineering Company Limited (CHEC) was awarded by HyD as
the Contractor to undertake the construction work of the Contract.
1.1.8
Ramboll Hong Kong Limited was employed by HyD as the Independent
Environmental Checker (IEC) and Environmental Project Office (ENPO) for the Project.
1.1.9
AECOM Asia Co. Ltd. (AECOM) was appointed by CHEC to undertake the role
of Environmental Team for the Contract for carrying out the EM&A works.
1.1.10
The construction phase of the Project under the EPs was commenced on 12 March
2012.
1.1.11
According to the Contract Specific EM&A Manual, there is a need of
an EM&A programme including air quality, noise, water quality and dolphin
monitoring and environmental site inspections. The EM&A programme of the Contract
commenced on 12 March 2012.
1.2 Scope of Report
1.2.1 This is the seventy-fourth
monthly EM&A Report under the Contract No. HY/2010/02 Hong
Kong-Zhuhai-Macao Bridge Hong Kong Boundary Crossing Facilities – Reclamation
Works. This report presents a summary of the environmental monitoring and audit
works, list of activities and mitigation measures proposed by the ET for the Contract
in April 2018.
1.3.1
The Contract organization structure is shown in Appendix A. The key
personnel contact names and numbers are summarized in Table 1.1.
Table
1.1 Contact Information of Key Personnel
Party
|
Position
|
Name
|
Telephone
|
Fax
|
Engineer’s Representative (ER)
(Ove Arup &
Partners Hong Kong Limited)
|
Senior Resident
Engineer
|
Anthony Wong
|
3698 5868
|
3698 5999
|
IEC / ENPO
(Ramboll Hong Kong
Limited)
|
Independent
Environmental Checker
|
Raymond Dai
|
3465 2888
|
3465 2899
|
Environmental Project
Office Leader
|
Y. H. Hui
|
3465 2850
|
3465 2899
|
Contractor
(China
Harbour Engineering Company Limited)
|
Environmental
Officer
|
Louie Chan
|
3693 2254
|
2578 0413
|
24-hour Hotline
|
Alan C.C. Yeung
|
9448 0325
|
--
|
ET
(AECOM Asia Company
Limited)
|
ET Leader
|
Echo Leong
|
3922 9280
|
2317 7609
|
1.4.1
The construction phase of the Project under the EP commenced on 12 March
2012.
1.4.2
As informed by the Contractor, details of the major works carried out in
this reporting period are listed below:
Land-base
-
Maintenance works of Site Office at Works Area WA2
(*WA2 was evacuated in the end of Mar 2018 and
pending for handover)
1.4.3
As informed by the Contractor, only touch up works were carried out
under Contract no. HY/2010/02 in the reporting month. Contractor’s planning
team confirmed that major works (outfall/reinstatement of seawall) were
completed in February 2018 and there was no update on the construction
programme. Please refer to Appendix B of Monthly EM&A report for January
2018 for 3-months rolling programme.
1.4.4
The general layout plan of the Contract site showing the detailed works
areas is shown in Figure 1.
1.4.5
The environmental mitigation measures implementation schedule are
presented in Appendix B.
1.5.1 The
EM&A programme required environmental monitoring for air quality, noise,
water quality, marine ecology and environmental site inspections for air
quality, noise, water quality, waste management, marine ecology, and landscape
and visual impact. The EM&A requirements for each parameter described in
the following sections include:-
- All monitoring parameters;
- Action and Limit levels for all environmental
parameters;
- Event / Action Plan;
- Environmental mitigation measures, as recommended in
the Project EIA reports; and
- Environmental requirement in contract documents.
2.1.1 In
accordance with the Contract Specific EM&A Manual, baseline 1-hour and
24-hour Total Suspended Particulates (TSP) levels at 4 air quality monitoring
stations were established. Impact 1-hour TSP monitoring was conducted for at
least three times every 6 days, while impact 24-hour TSP monitoring was carried
out for at least once every 6 days. The Action and Limit level of the air
quality monitoring is provided in Appendix C.
2.1.2 The
air quality monitoring works for the Contract are covered by Contract No.
HY/2013/01 Hong Kong-Zhuhai Macao Bridge HKBCF – Passenger Clearance Building.
2.1.3 The
monitoring requirements, monitoring equipment, monitoring parameters, frequency
and duration, monitoring methodology, monitoring schedule and meteorological
information are detailed in the monthly EM&A Reports prepared for Contract
No. HY/2013/01.
2.1.4 The
ET of the Contract or other ET of the HZMB project is required to conduct air
quality monitoring at AMS2, AMS3B and AMS7B as part of EM&A programme if
these air quality monitoring stations are no longer covered under Contract No.
HY/2013/01.
2.1.5 If
exceedance(s) is/are recorded by the ET of the Contract or referred by the
other ET under the HZMB project to the contract, the ET of the Contract will
carry out an investigation and findings will be reported in the monthly
EM&A Report.
2.2 Monitoring Locations
2.2.1 Monitoring
locations AMS2 and AMS7 were set up at the proposed locations in accordance
with Contract Specific EM&A Manual. For AMS6 (Dragonair/CNAC (Group)
Building), permission on setting up and carrying out impact monitoring works
was sought, however, access to the premise has not been granted yet on this
report issuing date. For monitoring location AMS3 (Ho Yu College), as proposed
in the Contract Specific EM&A Manual, approval for carrying out impact
monitoring could not be obtained from the principal of the school. Permission
on setting up and carrying out impact monitoring works at nearby sensitive
receivers, like Caribbean Coast and Coastal Skyline, was also sought. However,
approvals for carrying out impact monitoring works within their premises were
not obtained. Impact air quality monitoring was conducted at site boundary of
the site office area in Works Area WA2 (AMS3B) respectively. Same baseline and
Action Level for air quality, as derived from the baseline monitoring data
recorded at Ho Yu College, was adopted for this alternative air quality
location.
2.2.2 It
was observed that a tree near AMS3B may affect the wind flow around the HVS
located at AMS3B. With no further comment received from IEC, the HVS at AMS3B
has been relocated on 8 September 2014 to slightly more than 2 meters
separation from it, measured horizontally. Same baseline and Action Level for
air quality, as derived from the baseline monitoring data recorded at Ho Yu
College, was adopted for this alternative air quality location.
2.2.3 Reference
is made to ET’s proposal of the omission of air monitoring station (AMS 6)
dated on 1 November 2012 and EPD’s letter dated on 19 November 2012 regarding
the conditional approval of the proposed omission of air monitoring station
(AMS 6) for Contract No. HY/2010/02. The aforesaid omission of Monitoring
Station AMS6 is effective since 19 November 2012.
2.2.4 The
impact air quality monitoring station AMS7A (Chu Kong Air-Sea Union
Transportation Company Limited) has been relocated to AMS7 (Hong Kong SkyCity
Marriott Hotel) on 30 December 2015. The impact air quality monitoring was
conducted at AMS7 (Hong Kong SkyCity Marriott Hotel) since January 2016, action
Level for air quality, as derived from the baseline monitoring data recorded at
Hong Kong SkyCity Marriott Hotel has been adopted for this air quality
monitoring location.
2.2.5 As
informed by IEC/ENPO on 28 September 2017, air quality monitoring station
(AMS3B) and the meteorological station were relocated to AECOM PRE’s Office
effective since 1 September 2017.
2.2.6 As
informed by IEC/ENPO on 26 February 2018, air quality monitoring station AMS7
was relocated due to permission to carry out AQM at Hong Kong SkyCity Marriott
Hotel could not be granted after the end of January 2018. Alternative air
quality monitoring station AMS7B was justified and certified by ET Leader of
Contract No. HY/2013/01 on 22 January 2018, verified by IEC/ENPO on 24 January
2018. The proposal was submitted to the authority for review and approval on 30
January 2018. Relocation of air quality monitoring stations from AMS7 to AMS7B
is adopted effective from 6 February 2018 with the authority’s consent.
2.2.7 Figure
2 shows the locations of monitoring stations. Table 2.1 describes the details
of the monitoring stations.
Table 2.1 Locations of Impact Air
Quality Monitoring Stations
Monitoring Station
|
Location
|
Description
|
AMS2
|
Tung Chung
Development Pier
|
Rooftop of the premise
|
AMS3B
|
Site
Boundary of Site Office
Area at
Works Area WA2
|
On ground at the area boundary
|
AMS6*
|
Dragonair/CNAC
(Group) Building
|
On ground at boundary of the premise
|
AMS7B^
|
3RS Site Office
|
On the ground at the area boundary
|
#Remarks:
Reference is made to EPD conditional approval of the omission of air monitoring
station (AMS 6) for the Contract. The omission will be effective on 19 November
2012.
^ Remarks: Air quality monitoring station AMS7B is adopted effective from 6 February 2018 with the
authority’s consent.
2.3
Monitoring Schedule for the Reporting Month
2.3.1 The
schedule for air quality monitoring in April 2018 is detailed in the monthly
EM&A Report prepared for Contract No. HY/2013/01.
2.4 Results
and Observations
2.4.1 The
monitoring results for 1-hour TSP and 24-hour TSP are reported in the monthly
EM&A Report prepared for Contract No. HY/2013/01.
2.4.2 There
was no action and limit level exceedance of 1-hour TSP and 24-hr TSP recorded
by ET of Contract No. HY/2013/01 in the reporting month.
2.4.3 No
other exceedance was recorded in the reporting month.
2.4.4 The
event action plan is annexed in Appendix F.
2.4.5 Meteorological
information are reported in the monthly EM&A Reports prepared for Contract
No. HY/2013/01.
3.1.1 In
accordance with the Contract Specific EM&A Manual, impact noise monitoring
was conducted for at least once per week during the construction phase of the Contract.
The Action and Limit level of the noise monitoring is provided in Appendix C.
3.1.2 The
impact noise monitoring works for the Contract are covered by Contract No.
HY/2013/01 Hong Kong-Zhuhai Macao Bridge HKBCF – Passenger Clearance Building.
3.1.3 The
monitoring requirements, monitoring equipment, monitoring parameters, frequency
and duration, monitoring methodology and monitoring schedule are detailed in
the monthly EM&A Reports prepared for Contract No. HY/2013/01.
3.1.4 The
ET of the Contract or other ET of the HZMB project is required to conduct
impact noise monitoring at NMS2 and NMS3B as part of EM&A programme if
these impact noise monitoring stations are no longer covered under Contract No.
HY/2013/01.
3.1.5 If
exceedance(s) is/are recorded by the ET of the Contract or referred by the
other ET under the HZMB project to the contract, the ET of the Contract will
carry out an investigation and findings will be reported in the monthly
EM&A Report.
3.2
Monitoring Locations
3.2.1 Monitoring
locations NMS2 was set up at the proposed locations in accordance with Contract
Specific EM&A Manual. However, for monitoring location NMS3 (Ho Yu
College), as proposed in the Contract Specific EM&A Manual, approval for
carrying out impact monitoring could not be obtained from the principal of the
school. Permission on setting up and carrying out impact monitoring works at
nearby sensitive receivers, like Caribbean Coast and Coastal Skyline, was also
sought. However, approvals for carrying out impact monitoring works within
their premises were not obtained. Impact noise monitoring was conducted at site
boundary of the site office area in Works Area WA2 (NMS3B) respectively. Same
baseline noise level (as derived from the baseline monitoring data recorded at
Ho Yu College) and Limit Level were adopted for this alternative noise
monitoring location.
3.2.2 Figure
2 shows the locations of the monitoring stations. Table 3.1 describes the
details of the monitoring stations.
Table 3.1 Locations
of Impact Noise Monitoring Stations
Monitoring Station
|
Location
|
NMS2
|
Seaview Crescent
Tower 1
|
NMS3B
|
Site Boundary of Site Office Area at Works Area WA2
|
3.3.1 The
schedule for construction noise monitoring in April 2018 is detailed in the
monthly EM&A Report prepared for Contract No. HY/2013/01.
3.4.1 The
monitoring results for construction noise are reported in the monthly EM&A
Report prepared for Contract No. HY/2013/01.
3.4.2 There
was no action and Limit Level exceedance recorded by ET of Contract No.
HY/2013/01 in the reporting month.
3.4.3 The
event action plan is annexed in Appendix F.
4.
WATER QUALITY
MONITORING
4.1 Monitoring Requirements
4.1.1 The
impact water quality monitoring works for the Contract are covered by Contract
No. HY/2013/01 Hong Kong-Zhuhai Macao Bridge HKBCF – Passenger Clearance
Building.
4.1.2 The
monitoring requirements, monitoring equipment, monitoring parameters, frequency
and duration, monitoring methodology and monitoring schedule are detailed in
the monthly EM&A Reports prepared for Contract No. HY/2013/01.
4.1.3 The
ET of the Contract or other ET of the HZMB project is required to conduct
impact water quality monitoring as part of EM&A programme if these
monitoring stations are no longer covered under Contract No. HY/2013/01.
4.1.4 If
exceedance(s) is/are recorded by the ET of the Contract or referred by the
other ET under the HZMB project to the contract, the ET of the Contract will
carry out an investigation and findings will be reported in the monthly
EM&A Report.
4.2.1 In
accordance with the Contract Specific EM&A Manual, twenty-one stations (9
Impact Stations, 7 Sensitive Receiver Stations and 5 Control/Far Field
Stations) were designated for impact water quality monitoring. The nine Impact
Stations (IS) were chosen on the basis of their proximity to the reclamation
and thus the greatest potential for water quality impacts, the seven Sensitive
Receiver Stations (SR) were chosen as they are close to the key sensitive
receives and the five Control/ Far Field Stations (CS) were chosen to
facilitate comparison of the water quality of the IS stations with less
influence by the Project/ ambient water quality conditions.
4.2.2 Due
to safety concern and topographical condition of the original locations of SR4
and SR10B, alternative impact water quality monitoring stations, naming as SR4
(N) and SR10B (N), were adopted, which are situated in vicinity of the original
impact water quality monitoring stations (SR4 and SR10B) and could be
reachable.
4.2.3 Due
to marine work of the Expansion of Hong Kong International Airport into a
Three-Runway System (3RS Project), original locations of water quality
monitoring stations SR5, IS10 and CS(Mf)3 are enclosed by works boundary of 3RS
Project. Alternative impact water quality monitoring stations, naming as SR5(N),
IS10(N) and CS(Mf)3(N) was approved in 12 May 2017 and were adopted starting
from 15 May 2017 to replace the original locations of water quality monitoring.
For details and status of the proposed changes, please refer to section 6.4.8
4.2.4 Due
to substantial completion of marine works by this Contract, scale-down of
impact water quality monitoring was approved on 7 September 2017. Ten stations
(6 Impact Stations, 2 Sensitive Receiver Stations and 2 Control/Far Field
Stations) were adopted for impact water quality monitoring effective since 8
September 2017. For details and status of the proposed changes, please refer to
section 6.4.9.
4.2.5 Due
topographical condition of the original location of SR3, alternative water
quality monitoring station, naming as SR3(N) which is situated in vicinity of
the original water quality monitoring stations (SR3) was justified and verified
by the ET Leader of Contract No. HY/2013/01 on 8 November 2017 and IEC/ENPO on
13 November 2017 respectively. Alternative water quality monitoring stations
SR3(N) was approved by the authority and adopted on 22 December 2017.
4.2.6 Same
baseline and Action Level for water quality, as derived from the baseline
monitoring data recorded, were adopted for these alternative water quality
monitoring stations.
4.2.7 The
locations of these monitoring stations are summarized in Table 4.1 and depicted
in Figure 3.
Table 4.1 Impact
Water Quality Monitoring Stations
Station
|
Description
|
East
|
North
|
IS7
|
Impact Station (Close to HKBCF
construction site)
|
812244
|
818777
|
IS(Mf)9
|
Impact Station (Close to HKBCF
construction site)
|
813273
|
818850
|
IS10(N)
|
Impact Station (Close to HKBCF
construction site)
|
812942
|
820881
|
IS(Mf)11
|
Impact Station (Close to
HKBCF construction site)
|
813562
|
820716
|
IS(Mf)16
|
Impact Station (Close to HKBCF
construction site)
|
814328
|
819497
|
IS17
|
Impact Station (Close to HKBCF
construction site)
|
814539
|
820391
|
SR3(N)
|
Sensitive receivers (San Tau
SSSI)
|
810689
|
816591
|
SR7
|
Sensitive
receivers (Tai Mo Do)
|
814293
|
821431
|
CS(Mf)3(N)
|
Control Station
|
808814
|
822355
|
CS(Mf)5
|
Control Station
|
817990
|
821129
|
Remarks: Impact water quality monitoring
stations were retained after the proposal for scaling down of EM&A
programme was approved by the Authority on 7 September 2017.
4.3 Monitoring
Schedule for the Reporting Month
4.3.1 The
schedule for impact water quality monitoring in April 2018 is detailed in the
monthly EM&A Report prepared for Contract No. HY/2013/01.
4.4 Results and Observations
4.4.1 The
monitoring results for impact water quality monitoring are reported in the
monthly EM&A Report prepared for Contract No. HY/2013/01.
4.4.2 There
were 3 action level exceedance of suspended solids recorded at SR7 during flood
tide on 18 and 23 April 2018, and at IS10(N) during flood tide on 20 April 2018.
After investigation, no marine-based work was conducted on the monitoring date
as confirmed by the contractor. It was concluded that the recorded exceedance
not Contract-related. No other water quality exceedance was recorded at all
monitoring stations by Environmental Team of Contract No. HY/2013/01 in the
reporting month. For level of exceedance, location and when exceedances were
recorded, please refer to Appendix D.
4.4.3 The
detailed Investigation Reports No. W129-131 (including the cause of exceedance
and recommendation for mitigation) for action or limit level non-compliance was
provided in Appendix E.
4.4.4 There
was no other action and limit level exceedance was recorded by ET of Contract
No. HY/2013/01 in the reporting month.
4.4.5 The
event action plan is annexed in Appendix F.
5.1.1
The dolphin monitoring works for the Contract are covered by
Contract No. HY/2013/01 Hong Kong-Zhuhai-Macao Bridge Hong Kong Boundary
Crossing Facilities – Passenger Clearance Building. Another ET of the HZMB
project is required to conduct dolphin monitoring at the twenty-four transects
as part of EM&A programme if these transects are no longer covered under
Contract No. HY/2013/01. The dolphin monitoring should adopt line-transect
vessel survey method. The survey follows pre-set and fixed transect lines
in the two areas defined by AFCD as: Northeast Lantau survey area;
and Northwest Lantau survey area. The change of transect lines
2, 3, 4, 5, 6 and 7 and new vessel-based transect line 24 for dolphin
monitoring have been proposed due to the marine work of a designated project -
Expansion of Hong Kong International Airport into a Three-Runway System (3RS
Project). It was justified and verified by the ET Leader and the IEC of this
Contract (Contract No. HY/2010/02) respectively on 24 March 2017 and it was
approved by EPD on 12 May 2017. The Action and Limit level of the impact
dolphin monitoring is provided in Appendix C.
5.1.2
The monitoring requirements, monitoring equipment, monitoring
parameters, frequency and duration, monitoring methodology, monitoring
schedule, meteorological information are detailed in the monthly
EM&A Reports prepared for Contract No. HY/2013/01.
5.2.1
The impact dolphin monitoring is vessel-based. The survey follows
pre-set and fixed transect lines in the two areas defined by AFCD as:
5.2.2
Northeast Lantau survey area; and
5.2.3
Northwest Lantau survey area.
5.2.4
The co-ordinates for the transect lines and layout map have been
provided by AFCD and are shown in Table 5.1 and Figure 4.
Table 5.1 Impact Dolphin Monitoring
Line Transect Co-ordinates (Provided by AFCD)
|
HK Grid System
|
Long Lat in
WGS84
|
ID
|
X
|
Y
|
Long
|
Lat
|
1
|
804671
|
815456
|
113.870287
|
22.277678
|
1
|
804671
|
831404
|
113.869975
|
22.421696
|
2
|
805476
|
820800
|
113.878079
|
22.325952
|
2
|
805476
|
826654
|
113.878079
|
22.378814
|
3
|
806464
|
821150
|
113.887615
|
22.329130
|
3
|
806464
|
822911
|
113.887550
|
22.345030
|
4
|
807518
|
821500
|
113897833
|
22.332308
|
4
|
807518
|
829230
|
113.897663
|
22.402113
|
5
|
808504
|
821850
|
113.907397
|
22.335485
|
5
|
808504
|
828602
|
113.907252
|
22.396462
|
6
|
809490
|
822150
|
113.916965
|
22.338210
|
6
|
809490
|
825352
|
113.916884
|
22.367128
|
7
|
810499
|
822000
|
113.926749
|
22.336709
|
7
|
810499
|
824613
|
113.926688
|
22.360464
|
8
|
811508
|
821123
|
113.936539
|
22.328966
|
8
|
811508
|
824254
|
113.936486
|
22.357241
|
9
|
812516
|
821303
|
113.946320
|
22.330606
|
9
|
812516
|
824254
|
113.946279
|
22.357255
|
10
|
813525
|
820827
|
113.956112
|
22.326321
|
10
|
813525
|
824657
|
113.956066
|
22.360908
|
11
|
814556
|
818853
|
113.966155
|
22.304858
|
11
|
814556
|
820992
|
113.966125
|
22.327820
|
12
|
815542
|
818807
|
113.975726
|
22.308109
|
12
|
815542
|
824882
|
113.975647
|
22.362962
|
13
|
816506
|
819480
|
113.985072
|
22.314192
|
13
|
816506
|
824859
|
113.985005
|
22.362771
|
14
|
817537
|
820220
|
113.995070
|
22.320883
|
14
|
817537
|
824613
|
113.995018
|
22.360556
|
15
|
818568
|
820735
|
114.005071
|
22.325550
|
15
|
818568
|
824433
|
114.005030
|
22.358947
|
16
|
819532
|
821420
|
114.014420
|
22.331747
|
16
|
819532
|
824209
|
114.014390
|
22.356933
|
17
|
820451
|
822125
|
114.023333
|
22.338117
|
17
|
820451
|
823671
|
114.023317
|
22.352084
|
18
|
821504
|
822371
|
114.033556
|
22.340353
|
18
|
821504
|
823761
|
114.033544
|
22.352903
|
19
|
822513
|
823268
|
114.043340
|
22.348458
|
19
|
822513
|
824321
|
114.043331
|
22.357971
|
20
|
823477
|
823402
|
114.052695
|
22.349680
|
20
|
823477
|
824613
|
114.052686
|
22.360610
|
21
|
805476
|
827081
|
113.877878
|
22.382668
|
21
|
805476
|
830562
|
113.877811
|
22.414103
|
22
|
806464
|
824033
|
113.887520
|
22.355164
|
22
|
806464
|
829598
|
113.887416
|
22.405423
|
23
|
814559
|
821739
|
113.966142
|
22.334574
|
23
|
814559
|
824768
|
113.966101
|
22.361920
|
24
|
805476
|
815900
|
113.878028
|
22.281702
|
24
|
805476
|
819100
|
113.878028
|
22.310600
|
Remarks:
(a) *Due to the presence of
deployed silt curtain systems at the site boundaries of the Contract, some of
the transect lines shown in Figure 5 could not be fully surveyed during the
regular survey. Transect 10 is reduced from 6.4km to approximately 3.6km in length
due to the HKBCF construction site.
(b) Coordinates for transect
lines 1, 2, 7, 8, 9 and 11 have been updated in respect to the
Proposal for Alteration of Transect Line for Dolphin Monitoring
approved by EPD on 19 August 2015.
(c) Due to marine work of the
Expansion of Hong Kong International Airport into a Three-Runway System (3RS
Project), original transect lines of dolphin monitoring 2, 3, 4, 5, 6 and 7 are
enclosed by works boundary of 3RS Project. Alternative dolphin monitoring
transect lines 2, 3, 4, 5, 6, 7 and 24 are adopted starting from 17 May 2017 to
replace the original transect lines.
(d) Coordinates for transect
lines 2, 3, 4, 5, 6 and 7 have been updated and transect line 24 has been
adopted in respect to the Proposal for Alteration of Transect Line of
Dolphin Monitoring and Alternative Monitoring Location for Impact Water Quality
Monitoring (IWQM) Stations Due to Commencement of Third Runway Project approved
by EPD on 12 May 2017. The total transect length for both NEL and NWL
combined is reduced to approximately 99km.
5.3.1 The
schedule for impact dolphin monitoring in April 2018 is detailed in the monthly
EM&A Report prepared for Contract No. HY/2013/01.
5.4.2
The event action plan is annexed in Appendix F.
5.4.3
If exceedance(s) at these survey transect(s) is/are recorded by the ET
of the Contract or referred by the other ET under the HZMB project to the
Contract, the ET of the Contract will carry out an investigation and findings
will be reported in the Quarterly EM&A Report.
6.1.2 Particular
observations during the site inspections are described below:
Air
Quality
6.1.3 No
relevant adverse impact was observed in the reporting month.
Noise
6.1.4 No
relevant adverse impact was observed in the reporting month.
Water Quality
6.1.5
No relevant adverse impact was observed in the reporting month.
Chemical
and Waste Management
6.1.6
The Contractor was reminded to clear general refuse observed at the
entrance of site office at WA2 and keep the site clean and tidy on 26 April
2018.
Ecological
Impact
6.1.7
No relevant adverse impact was observed in the reporting month.
Landscape
and Visual Impact
6.1.8 No
relevant adverse impact was observed in the reporting month.
Others
6.1.9
No relevant adverse impact was observed in the reporting month.
6.2.1
The Contractor had registered as a chemical waste producer for this Project.
Receptacles were available for general refuse collection and sorting.
6.2.2
As advised by the Contractor, 3920 kg of paper/cardboard packaging and
32.5m3 of general refuse were generated and disposed of in the
reporting period. Monthly summary of waste flow table is detailed in Appendix G.
6.2.3
The Contractor is advised to properly maintain on site C&D materials
and wastes storage, collection, sorting and recording system, dispose of
C&D materials and wastes at designated ground and maximize reuse / recycle
of C&D materials and wastes. The Contractor is reminded to properly
maintain the site tidiness and dispose of the wastes accumulated on site
regularly and properly.
6.2.4
The Contractor is reminded that chemical waste should be properly
treated and stored temporarily in designated chemical waste storage area on
site in accordance with the Code of Practice on the Packaging, Labeling and
Storage of Chemical Wastes.
6.2.5
After checking with the Contractor, no surplus surcharge was
exported to Macau during the reporting month. The Contractor was reminded to
ensure consistency in quantities in case of any C&D material
disposed off-site and/or no surcharge material removed off site.
6.3.1 The
environmental licenses and permits for the Contract and valid in the reporting
month is summarized in Table 6.1.
Table 6.1 Summary of Environmental Licensing and
Permit Status
Statutory Reference
|
License/ Permit
|
License or Permit
No.
|
Valid Period
|
License/ Permit
Holder
|
Remarks
|
From
|
To
|
EIAO
|
Environmental Permit
|
EP-353/2009/K
|
11/04/2016
|
N/A
|
HyD
|
Hong Kong – Zhuhai – Macao Bridge Hong
Kong Boundary Crossing Facilities
|
EP-354/2009/D
|
13/03/2015
|
N/A
|
Tuen Mun – Chek Lap Kok Link
(TMCLKL Southern Landfall Reclamation only)
|
APCO
|
NA notification
|
--
|
30/12/2011
|
--
|
CHEC
|
Works Area WA2
|
APCO
|
NA notification
|
--
|
25/07/2014
|
--
|
CHEC
|
Works Area WA1
|
WDO
|
Chemical Waste
Producer Registration
|
5213-951-C1186-30
|
28/10/2015
|
N/A
|
CHEC
|
Chemical waste
produced in Contract HY/2010/02 (WA1)
|
WDO
|
Chemical Waste
Producer Registration
|
5213-951-C1186-21
|
30/3/2012
|
N/A
|
CHEC
|
Chemical waste
produced in Contract HY/2010/02 (WA2)
|
WDO
|
Billing Account for
Disposal of
Construction Waste
|
7014181
|
05/12/2011
|
N/A
|
CHEC
|
Waste disposal in
Contract HY/2010/02
|
6.4.1 In
response to the site audit findings, the Contractors carried out corrective
actions.
6.4.2 A
summary of the Implementation Schedule of Environmental Mitigation Measures
(EMIS) is presented in Appendix B. Most of the necessary mitigation measures
were implemented properly.
6.4.3
There were minimal vessel movement after major works has been
substantially completed under this Contract and training of marine travel route
for marine vessels operator was given to relevant staff and relevant records
were kept properly, as necessary. Nevertheless, the Contractor is reminded
strictly follows the approved Regular Marine Travel Routes plan.
6.4.4
Regarding the implementation of dolphin monitoring and protection
measures (i.e. implementation of Dolphin Watching Plan, Dolphin Exclusion Zone
and Silt Curtain integrity Check), regular checking were conducted by the
experienced MMOs within the works area to ensure no dolphin was trapped by the
enclosed silt curtain systems. Any dolphin spotted within the enclosed silt
curtain systems was reported and recorded. Relevant procedures were followed
and measures were well implemented. Silt curtain systems were also inspected
timely in accordance to the submitted plan. All inspection records were kept
properly.
6.4.5 Acoustic
decoupling measures on noisy plants on construction vessels were checked
regularly and the Contractor was reminded to ensure provision of ongoing
maintenance to noisy plants and to carry out improvement work once insufficient
acoustic decoupling measures were found.
6.4.6 Frequency
of watering per day on exposed soil was checked; with reference to the record
provided by the Contract, watering was conducted at least 8 times per day on
reclaimed land. The frequency of watering is the mainly refer to water truck.
Sprinklers are only served to strengthen dust control measure for busy traffic
at the entrance of Portion D. As informed by the Contractor, during the
mal-function period of sprinkler, water truck will enhance watering at such
area. The Contractor was reminded to ensure provision of watering of at least 8
times per day on all exposed soil within the Contract site and associated works
areas throughout the construction phase.
6.4.7 After
review, no floating grout production was in operation at any time in April
2018 for Contract No.HY/2010/02. Condition 3.26A of EP-353/2009/K for Contract
No.HY/2010/02 is complied with during the reporting month.
6.4.8
Due to the commencement of marine work of the Expansion of Hong Kong
International Airport into a Three-Runway System (3RS Project), a large
portion of works site boundary will be established at the northern part
of the existing airport Island. The recent arrangement of works boundary of 3RS
Project which delineates the boundary of the designated 3RS Project (for the
indicative 3RS boundary, please refer to Figure 5). The works area of 3RS
project will affect several water quality monitoring stations and the dolphin
monitoring transect lines which are being used for conducting
monitoring under Contract No. HY/2010/02. The EM&A Programme for the HZMB
HKBCF Project will therefore be affected. As a result, a proposal was prepared
by ET in accordance with condition 5.1 of EP-353/2009/K and condition 4.1 of
EP-354/2009/D, to relocate water quality monitoring stations from SR5, IS10,
CS(Mf)3 and alternate the transect lines of dolphin monitoring 2, 3, 4, 5, 6
and 7. A revised proposal has been updated and sent to IEC/ENPO for their
further review on 24 March 2017 and IEC/ENPO verified the revised proposal on
the same date. The revised proposal has been sent to authority by project team for
review and approval on 3 April 2017. The authority subsequently approved the
proposal on 12 May 2017.
6.4.9
Due to substantial completion of marine works by the end of June 2017, it
is anticipated that the remaining construction works under Contract No.
HY/2010/02, which include ground investigation (GI) works, construction of
temporary timber platform, removal of jetty and reinstatement of seawall at the
western section, construction of outfall at the eastern seawall, would cause
limited disturbance to water column and not to the seabed. In view of this, a
proposal for change of EM&A programme/requirements was prepared by ET in
accordance with Condition 5.1 of EP-353/2009/K and Condition 4.1 of EP-354/2009/D,
to terminate water quality monitoring works at stations IS5, IS(Mf)6, IS8,
SR4(N), SR5(N), SR6, SR10A, SR10B(N), CS4, CSA and CS6, and dolphin monitoring
(line-transect vessel survey method) covering NEL and NWL when perimeter silt
curtain under the Contract is completely removed and vessel traffic numbers
average 10 per month for Contract No. HY/2010/02. A revised proposal has been
updated and sent to IEC/ENPO for their further review on 15 August 2017 and
IEC/ENPO verified the revised proposal on 16 August 2017. The revised proposal
has been sent to authority by project team for review and approval on 21 August
2017. The authority subsequently approved the proposal on 7 September 2017.
6.4.10 The
monthly EM&A programme was undertaken in accordance with the Updated
EM&A Manual for HKBCF (Version 1.0). It should be noted that the air
quality, noise, water quality and dolphin monitoring works for the Contract are
covered by Contract No. HY/2013/01 Hong Kong-Zhuhai-Macao Bridge HKBCF –
Passenger Clearance Building effective since 1 September 2017. The ET of the
Contract is required to conduct EM&A monitoring as part of EM&A
programme if these monitoring stations are no longer covered under Contract No.
HY/2013/01.
6.4.11 Due
topographical condition of the original location of SR3, alternative water
quality monitoring station, naming as SR3(N) which is situated in vicinity of
the original water quality monitoring stations (SR3) was justified and verified
by the ET Leader of Contract No. HY/2013/01 on 8 November 2017 and IEC/ENPO on
13 November 2017 respectively. Alternative water quality monitoring stations
SR3(N) was approved by the authority and adopted on 22 December 2017.
6.4.12 Due
to permission to carry out AQM at Hong Kong SkyCity Marriott Hotel could not be
granted after the end of January 2018, alternative air quality monitoring
station naming as AMS7B was justified and verified by the ET Leader of Contract
No. HY/2013/01 on 22 January 2018 and IEC/ENPO on 24 January 2018. Alternative
air quality monitoring station AMS7B was submitted to the authority on 30
January 2018 and effective from 6 February 2018 with the authority’s consent.
6.4.13 As
informed by the Contractor, major construction activities for Contract no.
HY/2010/02 has been substantially completed and it is anticipated that
potential environmental impact for remaining works which only include ad hoc
minor maintenance/touch up works on seawall under the Contract would be
insignificant. In view of this, a proposal for Termination of EM&A
Programme was prepared and certified by ET in accordance with Condition 5.1 of EP-353/2009/K
and Condition 4.1 of EP-354/2009/D to terminate the EM&A Programme for
Contract no. HY/2010/02. The proposal has been sent to IEC/ENPO for their
further review on 17 April 2018 and IEC/ENPO verified the proposal on 18 April
2018. The proposal has been sent to authority by project team on 19 April 2018.
6.5 Summary of
Exceedances of the Environmental Quality Performance Limit
6.5.1
For impact air quality monitoring, no exceedance was recorded at all
monitoring stations by Environmental Team of Contract No. HY/2013/01 in the
reporting month.
6.5.2
For construction noise monitoring, no exceedance was recorded at all
monitoring stations by Environmental Team of Contract No. HY/2013/01 in the reporting
month.
6.5.3
For impact water quality monitoring, 3 action level exceedances of
suspended solids at at SR7 during flood tide on 18 and 23 April 2018, and at
IS10(N) during flood tide on 20 April 2018. After investigation, no
marine-based works was conducted on the monitoring dates as confirmed by the
contractor. It was concluded that the recorded exceedances were not
Contract-related. No other exceedance was recorded at all monitoring stations
by Environmental Team of Contract No. HY/2013/01 in the reporting month. For
level of exceedance, location and when exceedances were recorded, please refer
to Appendix D.
6.5.4
Impact dolphin monitoring results at all transects are reported in
EM&A Report prepared for Contract No. HY/2013/01.
6.5.5 Environmental
site inspection was carried out 4 times in April 2018. Recommendations on
remedial actions were given to the Contractors for the deficiencies identified
during the site audits.
6.5.6 Cumulative
statistics on exceedance is provided in Appendix H.
6.6
Summary of Complaints, Notification of Summons and Successful
Prosecutions
6.6.1
No complaint, notification of summons or prosecution was received in the
reporting period.
6.6.1 The
Environmental Complaint Handling Procedure is annexed in Figure 5.
6.6.2 Statistics
on complaints, notifications of summons and successful prosecutions are
summarized in Appendix H.
*Construction activity in May 2018
will be changed subject to works progress.
7.2.1 Key
issues to be considered in the coming months:-
- Site runoff should be properly collected and treated
prior to discharge;
- Regular review and maintenance of silt curtain
systems, drainage systems and desilting facilities;
- Exposed surfaces/soil stockpiles should be properly
treated to avoid generation of silty surface run-off during rainstorm;
- Regular review and maintenance of wheel washing
facilities provided at all site entrances/exits;
- Conduct regular inspection of various working
machineries and vessels within works areas to avoid any dark smoke emission;
- Suppress dust generated from work processes with use
of bagged cements, earth movements, excavation activities, exposed
surfaces/soil stockpiles and haul road traffic;
- Quieter powered mechanical equipment should be used;
- Provision of proper and effective noise control
measures for operating equipment and machinery on-site, such as erection of
movable noise barriers or enclosure for noisy plants;
-
Closely check and replace the sound
insulation materials regularly;
-
Better scheduling of construction works
to minimize noise nuisance;
- Properly store and label oil drums and chemical
containers placed on site;
- Proper chemicals, chemical wastes and wastes
management;
- Maintenance works should be carried out within roofed,
paved and confined areas;
- Collection and segregation of construction waste and
general refuse on land and in the sea should be carried out properly and
regularly; and
- Proper protection and regular inspection of existing
trees, transplanted/retained trees.
- Control night-time lighting and glare by hooding all
lights.
- Regular review and provide maintenance to dust control
measures such as sprinkler system.
7.3 Monitoring
Schedule for the Coming Month
7.3.1
The tentative schedule for environmental monitoring of May 2018 are
detailed in the monthly EM&A Report prepared for Contract No. HY/2013/01.
8.1.1 For impact
air quality monitoring, no exceedance was recorded at all monitoring stations
by Environmental Team of Contract No. HY/2013/01 in the reporting month.
8.1.2 For
construction noise monitoring, no exceedance was recorded at all monitoring stations
by Environmental Team of Contract No. HY/2013/01 in the reporting month.
8.1.3 For impact
water quality monitoring, 3 action level exceedances of suspended solids at SR7
during flood tide on 18 and 23 April 2018, and at IS10(N) during flood tide on
20 April 2018. After investigation, no marine-based works was conducted on the
monitoring dates as confirmed by the contractor. It was concluded that the
recorded exceedances were not Contract-related. No other exceedance was
recorded at all monitoring stations by Environmental Team of Contract No.
HY/2013/01 in the reporting month. For level of exceedance, location and when
exceedances were recorded, please refer to Appendix D.
8.1.4 Impact
dolphin monitoring results at all transects are reported in EM&A Report prepared
for Contract No. HY/2013/01.
8.1.5 No
complaint, notification of summons or prosecution was received in the reporting
period.
8.2.1 According
to the environmental site inspections performed in the reporting month, the
following recommendations were provided:
Air Quality Impact
l All working plants
and vessels on site should be regularly inspected and properly maintained to
avoid dark smoke emission.
l
All vehicles should be washed to remove any dusty materials
before leaving the site.
l
Haul roads should be sufficiently dampened to minimize fugitive
dust generation.
l
Wheel washing facilities should be properly maintained and
reviewed to ensure properly functioning.
l
Temporary exposed slopes and open stockpiles should be properly
covered.
l
Enclosure should be erected for cement debagging, batching and
mixing operations.
l
Water spraying should be provided to suppress fugitive dust for
any dusty construction activity.
l
Regular review and provide maintenance to dust control measures
such as sprinkler system.
Construction Noise
Impact
l
Quieter powered mechanical equipment should be used as far as
possible.
l
Noisy operations should be oriented to a direction away from
sensitive receivers as far as possible.
l
Proper and effective noise control measures for operating
equipment and machinery on-site should be provided, such as erection of movable
noise barriers, enclosure for noisy plants or enhancement works to provide
sufficient acoustic decoupling measure(s). Closely check and replace the sound
insulation materials regularly
l
Vessels and equipment operating should be checked regularly and
properly maintained.
l
Noise Emission Label (NEL) shall be affixed to the air compressor
and hand-held breaker operating within works area.
l
Acoustic decoupling measures should be properly implemented for
all existing and incoming construction vessels with continuous and regularly
checking to ensure effective implementation of acoustic decoupling measures.
Water Quality
Impact
l
Regular review and maintenance of silt curtain systems, drainage
systems and desilting facilities in order to make sure they are functioning
effectively.
l
Construction of seawall should be completed as early as possible.
l
Regular inspect and review the loading process from barges to
avoid splashing of material.
l
Silt, debris and leaves accumulated at public drains, wheel
washing bays and perimeter u-channels and desilting facilities should be
cleaned up regularly.
l
Silty effluent should be treated/ desilted before discharged.
Untreated effluent should be prevented from entering public drain channel.
l
Proper drainage channels/bunds should be provided at the site
boundaries to collect/intercept the surface run-off from works areas.
l
Exposed slopes and stockpiles should be covered up properly
during rainstorm.
Chemical and Waste
Management
l
All types of wastes, both on land and floating in the sea, should
be collected and sorted properly and disposed of timely and properly. They
should be properly stored in designated areas within works areas temporarily.
l
All chemical containers, batteries and oil drums should be
properly stored and labelled.
l
All plants and vehicles on site should be properly maintained to
prevent oil leakage. Proper measures, like drip trays and/or bundings, should
be provided for retaining leaked oil/chemical from plants.
l
All kinds of maintenance works should be carried out within
roofed, paved and confined areas.
l
All drain holes of the drip trays utilized within works areas
should be properly plugged to avoid any oil and chemical waste leakage.
l
Oil stains on soil surface, accumulated oil mixture and empty chemical
containers should be cleared and disposed of as chemical waste.
l
Regular review should be conducted for working barges and patrol
boats to ensure sufficient measures and spill control kits were provided on
working barges and patrol boats to avoid any spreading of leaked oil/chemicals.
Landscape and
Visual Impact
l
All existing, retained/transplanted trees at the works areas
should be properly fenced off and regularly inspected.
l
Control night-time lighting and glare by hooding all lights.
