TABLE
OF CONTENTS
|
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|
|
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|
|
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|
|
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|
|
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|
|
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|
|
|
||||
|
|
||||||
|
Figure 1 |
Air Quality and Noise Monitoring Stations for HKBCF |
|
||||
|
Figure 2 |
Water Quality Monitoring Stations(construction phases) |
|
||||
|
Figure 3 |
Dolphin
Monitoring TransectLine and Layout Map |
|
||||
|
|
|
|
||||
|
|
|
|
||||
|
|
|
|
||||
|
TABLE |
|
|
||||
|
Table 1.1 |
Contact Information of Key Personnel |
|
||||
|
Table 2.1 |
Air Quality Monitoring Locations |
|
||||
|
Table 2.2 |
Action and Limit Levels for 1-hour TSP |
|
||||
|
Table 2.3 |
Action and Limit Levels for 24-hour TSP |
|
||||
|
Table 3.1 |
Construction Noise Monitoring Locations |
|
||||
|
Table 3.2 |
Action and Limit Levels for Construction Noise |
|
||||
|
Table 4.1 |
Water Quality Monitoring Stations (construction phases) |
|
||||
|
Table 4.2 |
Action and Limit Levels for Water Quality |
|
||||
|
Table 4.3 |
Number of Exceedance for Water Quality Monitoring |
|
||||
|
Table 5.1 |
New co-ordinates of changed vessel-based transect lines |
|
||||
|
Table 5.2a |
Action and Limit Levels for Chinese White Dolphin
Monitoring – Approach to Define Action Level (AL) and Limit Level (LL) |
|
||||
|
Table 5.2b |
Action and Limit Levels for Chinese White Dolphin
Monitoring - |
|
||||
|
Table 6.1 |
Summary of marine sediment disposed to dumping
site via Contract No. HY/2013/03 |
|
||||
|
|
|
|
||||
|
|
|
|
||||
|
|
|
|
||||
|
APPENDICES |
|
|||||
|
Location of Works Areas |
|
|||||
|
Project Organization for Environmental Works |
|
|||||
|
Construction Programme |
|
|||||
|
Event and Action Plan |
|
|||||
|
Monthly Summery of Waste Flow Table & Monthly
Summery of Marine Sediment |
|
|||||
|
Environmental Licenses and Permits |
|
|||||
|
Implementation Schedule for Environmental Mitigation
Measures (EMIS) |
|
|||||
|
Statistics on Environmental Complaints,
Notification of Summons and Successful Prosecutions |
|
|||||
|
Environmental Site Inspection Schedule |
|
|||||
|
Investigation Reports on Action Level or Limit Level Non-compliance |
|
|||||
|
|
|
|
||||
|
|
|
|
|||
|
|
|
This Monthly Environmental
Monitoring and Audit (EM&A) Report is
prepared for Contract HY/2013/02 “Hong Kong–Zhuhai-Macao Bridge Hong Kong
Boundary Crossing Facilities (HKBCF) – Infrastructure Works Stage I (Western
Portion)” (hereafter referred to as “the Contract”) for the Highways Department
of Hong Kong Special Administrative Region (HKSAR). The Contract was awarded to
China Harbour Engineering Co., Ltd. (hereafter referred to as “the Contractor”)
and ETS-Testconsult Limited was appointed as the Environmental Team (ET) by the
Contractor.
The Contract is part of
Hong Kong–Zhuhai–Macao Bridge HKBCF which is a “Designated Project”, under
Schedule 2 of the Environmental Impact Assessment Ordinance (EIAO) (Cap 499)
and Environmental Impact Assessment (EIA) Report (Register No. AEIAR-145/2009)
was prepared for the Project. The current Environmental Permit (EP) No. EP-353/2009/K for HKBCF was issued on 11 April 2016.
These documents are available through the EIA Ordinance Register. Site
preparation works of the Contract was started on 25 July 2014 and the
construction works of the Contract commenced on 24 November 2014.
ETS-Testconsult Limited
has been appointed by the Contractor to implement the Environmental Monitoring
& Audit (EM&A) programme for the Contract in accordance with the
Updated EM&A Manual for HKBCF (Version 1.0) and provide environmental team
services to the Contract.
This is theThirty-fourth Monthly Environmental Monitoring
and Audit (EM&A) Report for the Contractwhich summaries findings of the
EM&A works conducted during the reporting period from 01September to 30September2017.
Site Activities
As
informed by the Contractor, site
activities were carried out in
this reporting month:
l Road and Bituminous works;
l Storm, sewer drainage and water main
construction;
l Retaining wall, slop and earth works;
l Construction of signs gantries, cable trench
and ducting;
l Demolition of temporary loading and unloading
point (Marine-based activity);
l Construction of bridge deck in Portion D, A,
E, C & F
Environmental Monitoring and Audit Progress
The monthly EM&A programme was
undertaken in accordance with the Updated EM&A Manual for HKBCF (Version 1.0).
It should be noted that the air quality and noise monitoring works for the
Contract are covered by Contract No. HY/2013/01 “Hong Kong-Zhuhai-Macao Bridge
HKBCF –Passenger Clearance Building”and Contract No. HY/2011/03 “Hong Kong-Zhuhai-Macao Bridge Hong Kong
Link Road – Section between Scenic Hill and HKBCF”. The
ET of the Contract or another ET of the HZMB project is required to conduct
impact air quality monitoring at AMS6 and AMS7, noise monitoring at NMS2 and
NMS3B, water quality monitoring show in Figure
2 and dolphinmonitoring show in Figure
3as part of
EM&A programme if these monitoring stations are no longer covered under Contract
No. HY/2013/01 and HY/2011/03. However, this is subject to
ENPO’s final decision on which ET should carry out the monitoring works at
these stations.The dates of site inspection during the reporting period are
listed below:
Environmental Site Inspection:07,14, 21&28September2017
Breaches of
Action and Limit Levels
Summary
of Action and Limit Level exceedance of 1-hr TSP level and 24-hr TSP level at
AMS6 shall be referred to the monthly EM&A report prepared by Contract No. HY/2011/03.
There was noAction and Limit Level exceedance
of 1-hr TSP level and 24-hr TSP level
recorded at station AMS7 by the Environmental Team of Contract No. HY/2013/01during the reporting period.
There was no Action and Limit Level exceedance
for noise recorded at
station NMS2 and station NMS3B by the Environmental Team of Contract No. HY/2013/01during the reporting period.
During September
2017, there were 137 action level exceedances and 26 limit
level exceedances of dissolved
oxygen, 5 action level exceedances
and
1 limit level exceedance of turbidity, 8action level exceedances and 1 limit
level exceedances of suspended solid.
The following tablesummarized the number of exceedance on each sampling data.
|
Sampling Date |
No. of Exceedances |
|||||
|
DO |
Turbidity |
SS |
||||
|
Action |
Limit |
Action |
Limit |
Action |
Limit |
|
|
1/9/2017 |
8 |
0 |
0 |
0 |
0 |
0 |
|
6/9/2017 |
4 |
4 |
1 |
0 |
3 |
0 |
|
8/9/2017 |
24 |
4 |
4 |
0 |
2 |
1 |
|
11/9/2017 |
30 |
3 |
0 |
0 |
0 |
0 |
|
13/9/2017 |
13 |
3 |
0 |
0 |
0 |
0 |
|
15/9/2017 |
10 |
2 |
0 |
1 |
0 |
0 |
|
18/9/2017 |
8 |
2 |
0 |
0 |
1 |
0 |
|
20/9/2017 |
3 |
2 |
0 |
0 |
1 |
0 |
|
22/9/2017 |
17 |
4 |
0 |
0 |
0 |
0 |
|
25/9/2017 |
1 |
1 |
0 |
0 |
1 |
0 |
|
27/9/2017 |
6 |
1 |
0 |
0 |
0 |
0 |
|
29/9/2017 |
13 |
0 |
0 |
0 |
0 |
0 |
|
Total: |
137 |
26 |
5 |
1 |
8 |
1 |
After investigation, there
was concluded that the exceedances were not relevant to this Contract since there was only one marine based activity which is demolition of temporary loading and
unloading pointof this Contract
worked at HKBCF reclamation site near the sea area or area near the monitoring stations.The demolition of temporary loading and unloading point was started from
18 July 2017. The major marine based activity was the removal of marine piling
of temporary loading and unloading point.
All marine based activities were carried out within the silt curtain and no
defect of silt curtain was recorded by Contract No. HY/2010/02 from 18 July 2017 to 31August 2017. Besides, there was also no DO, turbidity and SS
exceedance recorded during 18 July 2017 to 31 August 2017. Therefore, the exceedance was not caused by demolition of temporary loading and
unloading point.The Investigation Reports No. 019, 020,
021 and 022(including
the causes of exceedance, action taken and recommendation for mitigation) for
Action or Limit Level Non-compliance were provided in Appendix J. As confirmed by SRE, removal of temporary loading and
unloading point by Contract No. HY/2013/02, which involved marine work, was
completed on 10 September and the area was handed back to Reclamation
Contractor on 11 September 2017 for subsequent seawall construction. No
marine based works for demolition of loading and unloading point was conducted
so that no investigation report was provided for all exceedances recorded after
11 September 2017. There was no Action and Limit Level exceedance
recorded on other monitoring date at the monitoring stations showed at Table
4.1 by the Environmental Team of Contract No. HY/2013/01 during the reporting
period.
Impact dolphin monitoring results at all transects are reported in the EM&A Report prepared for Contract
No. HY/2013/01.
Complaint Log
There was no
complaint received in relation to the environmental impact during thereporting period.
Notifications of Summons and Successful
Prosecutions
There were no
notifications of summons or prosecutions received during thereporting period.
Reporting Change
From 01
September 2017, the implementation of environmental monitoring for Contract No.
HY/2010/02 (covering air quality, noise, water quality and marine ecology) was
suspended and the same implementation will be conducted by the ET for Contract
No. HY/2013/01 of which the noise monitoring station (NMS3B) and the
meteorological station have been slightly re-located to AECOM PRE's
Office.
Future
Key Issues
The future key
issues to be undertakenin the upcoming month are as follows:
l Road and Bituminous works
l Storm, sewer drainage and water main
construction;
l Retaining wall, slop and earth works
l Construction of signs gantries, cable trench
and ducting;
l Construction of parapet &
barrier
1.1.
Basic Project Information
1.1.1.
This Monthly Environmental
Monitoring and Audit (EM&A) Report is
prepared for Contract HY/2013/02 “Hong Kong–Zhuhai-Macao Bridge Hong Kong
Boundary Crossing Facilities (HKBCF) – Infrastructure Works Stage I (Western
Portion)” (hereafter referred to as “the Contract”) for the Highways Department
of Hong Kong Special Administrative Region (HKSAR). The Contract was awarded to
China Harbour Engineering Co., Ltd. (hereafter referred to as “the Contractor”)
and ETS-Testconsult Limited was appointed as the Environmental Team (ET) by the
Contractor.
1.1.2.
The Contract is part of
Hong Kong–Zhuhai–Macao Bridge HKBCF which is a “Designated Project”, under
Schedule 2 of the Environmental Impact Assessment Ordinance (EIAO) (Cap 499)
and Environmental Impact Assessment (EIA) Report (Register No. AEIAR-145/2009)
was prepared for the Project. The current Environmental Permit (EP) No. EP-353/2009/K for HKBCF was issued on 11 April 2016.
These documents are available through the EIA Ordinance Register. Site
preparation works of the Contract started on 25 July 2014 and the construction
works of the Contract commenced on 24 November 2014. The works area of the Contract
is shown in Appendix A.
1.1.3.
Theproposed
works under this Contract comprise the following:
§
Construction of the
viaducts and roads at the western portion of Hong KongBoundaryCrossing
Facilities (HKBCF) mainly for connection with the Hong Kong–Zhuhai–MacaoBridge
(HZMB), Hong Kong Link Road (HKLR), Hong Kong International Airport (HKIA) and
the Tuen Mun-Chek Lap Kok Link (TM-CLKL);
§
Construction of the road modification at the
SkyCity Interchange at Airport Island;
§
Construction of associated street lighting,
street furniture, road marking, roadsignage,drainage, sewerage, fresh water and
flushing water supply, irrigation, landscape, electricaland mechanical
(E&M), utilities and services works;
§
Provisioning of civil engineering works and power
supply installation for the Traffic Control and Surveillance System TCSS;
§
Other works in accordance with the
Contract.
1.1.4.
This is the Thirty-fourthMonthly Environmental
Monitoring and Audit (EM&A) Report for the Contract which summaries the
audit findings of the EM&A programme during the reporting
period from 01 September to 30September 2017.
1.2.
Project Organization
1.2.1.
The project
organization
structure and lines of communication with respect to the on-site environmental
management structure is shown in Appendix B. The key personnel contact
names and numbers are summarized in Table
1.1.
Table 1.1 Contact Information of Key Personnel
|
Party |
Position |
Name of Key Staff |
Tel. No. |
Fax No. |
|
Engineer or Engineer’s Representative (AECOM Asia Co. Ltd.) |
Resident Engineer |
Mr. Winston Wong |
6330 8293 |
31525116 |
|
Environmental Project Office / Independent Environmental Checker (Ramboll Environ Hong Kong Limited) |
Environmental Project Office Leader |
Mr. Y. H. Hui |
3465 2888 |
3465 2899 |
|
Independent Environmental Checker |
Mr. Raymond Dai |
3465 2888 |
3465 2899 |
|
|
Environmental Site Supervisor |
Mr. Ray Yan |
5181 8165 |
3465 2899 |
|
|
Contractor (China Harbour Engineering Co., Ltd.) |
EnvironmentalOfficer |
Mr. Richard Ng |
5977 0593 |
3915 0300 |
|
EnvironmentalOfficer |
Mr. Paper Chan |
6486 8967 |
3915 0300 |
|
|
Environmental Supervisor |
Mr. Endy Tse |
5512 2662 |
3915 0300 |
|
|
Environmental
Team (ETS-Testconsult Ltd.) |
Environmental
Team Leader |
Mr. C. L. Lau |
2946
7791 |
2695
3944 |
1.3.
Construction Programme
1.3.1. A copy of the Contractor’s construction programme is provided in Appendix
C.
1.4.
Construction Works Undertaken During the Reporting Period
1.4.1.
A
summary of the construction activities undertaken during this reporting period is
shown below:
l
Road and Bituminous works;
l
Storm, sewer drainage and water main construction;
l
Retaining wall, slop and earth works;
l
Construction of signs gantries, cable trench and ducting;
l
Demolition of temporary loading and unloading point (Marine-based
activity);
l
Construction of bridge deck in Portion D, A, E, C & F
2.1.
Monitoring Locations
2.1.1.
Theair quality monitoring works for
the Contract are covered by Contract No. HY/2013/01 Hong Kong-Zhuhai-Macao Bridge HKBCF –Passenger Clearance
Buildingand
Contract No. HY/2011/03 Hong Kong-Zhuhai-Macao Bridge Hong Kong Link Road –
Section between Scenic Hill and HKBCF. The ET of the Contract or another ET of
the HZMB project is required to conduct impact air quality monitoring at AMS6
and AMS7 as part of EM&A programme if these air quality monitoring stations
are no longer covered under Contract No. HY/2013/01 and HY/2011/03.Table 2.1 andFigure 1shows the locations of air monitoring
stations.
Table 2.1 Air Quality Monitoring Locations
|
IdentificationNo. |
LocationDescription |
|
AMS6(1) |
Dragonair / CNAC (Group)
Building
|
|
AMS7(1) (2) |
Hong Kong SkyCity Marriott Hotel |
|
Remarks: |
|
(1)
The ET of this Contract should conduct impact air quality
monitoring at the AMS listed in the table aspart ofEM&A programme
according to latest notification from ENPO when the monitoring station(s)
is/are no longer covered by another ET of the HZMB project. |
|
(2)
The air quality monitoring location
AMS7A was relocated back to the original monitoring location AMS7 of
the updated EM&A Manual started from January 2016. |
2.2.
Monitoring Requirements
2.2.1.
The monitoring requirements, monitoring
equipment, monitoring parameters, frequency and duration, monitoring
methodology, monitoring schedule, meteorological information are detailed in
the monthly EM&A Reports prepared for Contract Nos. HY/2013/01 and
HY/2011/03.
2.2.2.
TheAction and
Limit Levels for 1-hr TSP and 24-hr TSP are provided in Table 2.2and Table
2.3 respectively. The Action and Limit Levels of AMS7 are as same as its
original levels and AMS7A.
Table 2.2 Action and Limit Levels for 1-hour TSP
|
Monitoring Station |
Action Level,mg/m3 |
Limit Level,mg/m3 |
|
AMS6
– Dragnair / SNAC (Group) Building (HKIA) |
360 |
500 |
|
AMS7
–Hong Kong SkyCity Marriott
Hotel |
370 |
500 |
Table 2.3 Action and Limit Levels for 24-hour TSP
|
Monitoring Station |
Action Level,mg/m3 |
Limit Level,mg/m3 |
|
AMS6
– Dragnair / SNAC (Group) Building (HKIA) |
173 |
260 |
|
AMS7
–Hong Kong SkyCity Marriott
Hotel |
183 |
260 |
2.2.3.
The event and
action plan is provided in Appendix D.
2.2.4.
If
exceedance(s) at these stations is/are recorded by the ET of the Contract or
referred by the other ET under the HZMB project to the Contract, the ET of the
Contract will carry out an investigation and findings will be reported in the
monthly EM&A Report.
2.3.
Monitoring Results
2.3.1.
The
monitoring results for AMS6 and AMS7 are reported in the monthly EM&A
Reports prepared for Contract Nos. HY/2011/03 and HY/2013/01 respectively.
2.3.2.
Summary of Action and
Limit Level exceedance of 1-hr TSP level and 24-hr TSP level at AMS6 shall be
referred to the monthly EM&A report prepared by Contract No. HY/2011/03.
2.3.3.
There was no
Action and Limit Level
exceedance of 1-hr TSP level and 24-hr TSP
level recorded at station AMS7 by the Environmental Team of Contract
No. HY/2013/01during the reporting period.
3.1.
Monitoring
Locations
3.1.1. The noise monitoring works for the Contract are covered by Contract
No. HY/2013/01 Hong Kong-Zhuhai-Macao Bridge HKBCF –Passenger
Clearance Building.
The ET of the Contract or another ET of the HZMB project is required to conduct
noise monitoring at NMS2 and NMS3B as part of EM&A programme if these
monitoring stations are no longer covered under Contract No. HY/2013/01. Table 3.1 and Figure 1shows the locations of noise monitoring stations.
Table 3.1 Construction Noise Monitoring Locations
|
IdentificationNo. |
LocationDescription |
|
|
NMS2(1) |
Sea View
Crescent |
|
|
NMS3B(1) (2) |
Site Boundary of Site Office Area at Works
Area WA2 |
|
|
Remarks: |
|
|
|
(1)
The ET of this Contract should conduct impact noise monitoring
at the NMS listed in the table as part of EM&A programme according to
latest notification from ENPO when the monitoring station(s) is/are no longer
covered by anotherET of the HZMB project. |
|
|
|
(2)
The Action and Limit Levels for schools will be applied for this
alternative monitoring location. |
|
|
3.2.
Monitoring Requirements
3.2.1.
The monitoring requirements, monitoring
equipment, monitoring parameters, frequency and duration, monitoring
methodology, monitoring schedule, meteorological information are detailed in
the monthly EM&A Reports prepared for Contract No. HY/2013/01.
3.2.2.
The Action and Limit Levelsfor construction noise are provided in Table 3.2
3.2.3.
The event and action plan is provided in Appendix D.
Table 3.2 Action and Limit Levels for
Construction Noise
|
Parameter |
Action Level |
Limit Level |
|
|
07:00 – 19:00 hours on normal weekdays |
When one documented complaint is received |
75
dB(A)* |
|
|
Notes: |
|
||
|
Ifworksaretobecarriedout duringrestrictedhours,theconditionsstipulatedintheconstruction noisepermitissuedbytheNoiseControlAuthorityhavetobefollowed. |
|
||
|
*Reduce to70dB(A) for schools and65 dB(A)duringschoolexaminationperiod. |
|
||
3.2.4.
If exceedance(s) at these stations
is/are recorded by the ET of the Contract or referred by the other ET under the
HZMB project to the Contract, the ET of the Contract will carry out an
investigation and findings will be reported in the monthly EM&A Report.
3.3.
Monitoring
Results
3.3.1 Themonitoring results for NMS2 and NMS3B are
reported in the monthly EM&A Reports prepared for Contract No. HY/2013/01. There was
no exceedance for noise recorded
at station NMS2 and station NMS3B by the Environmental Team of Contract No. HY/2013/01during the reporting period.
4.1.
Monitoring
Locations
The watermonitoring works for the
Contract are covered by Contract No. HY/2013/01 Hong Kong-Zhuhai-Macao Bridge HKBCF –Passenger Clearance Building.
The ET of the Contract or another ET of the HZMB project is required to conduct
waterquality monitoring at twenty
one stations (9 Impact Stations, 7
Sensitive Receiver Stations and 5 Control/Far Field Stations). Table 4.1 and Figure
2shows the locations of water quality monitoring stations.
Table 4.1 Water Quality Monitoring Stations
(construction phases)
|
Station |
Description |
East |
North |
|
IS5 |
Impact Station (Close to HKBCF
construction site) |
811579 |
817106 |
|
IS(Mf)6 |
Impact Station (Close to HKBCF
construction site) |
812101 |
817873 |
|
IS7 |
Impact Station (Close to HKBCF
construction site) |
812244 |
818777 |
|
IS8 |
Impact Station (Close to HKBCF
construction site) |
814251 |
818412 |
|
IS(Mf)9 |
Impact Station (Close to HKBCF
construction site) |
813273 |
818850 |
|
IS10(N) |
Impact
Station (Close to HKBCF construction site) |
812942 |
820881 |
|
IS(Mf)11 |
Impact Station (Close to HKBCF
construction site) |
813562 |
820716 |
|
IS(Mf)16 |
Impact Station (Close to HKBCF
construction site) |
814328 |
819497 |
|
IS17 |
Impact Station (Close to HKBCF
construction site) |
814539 |
820391 |
|
SR3 |
Sensitive receivers (San Tau SSSI) |
810525 |
816456 |
|
SR4(N) |
Sensitive receivers (Tai Ho) |
814705 |
817859 |
|
SR5(N) |
Sensitive
receiver (Artificial Reef in NE Airport) |
812569 |
821475 |
|
SR6 |
Sensitive receivers (Sha Chau and Lung
Kwu Chau Marine Park) |
805837 |
821818 |
|
SR7 |
Sensitive receivers (Tai Mo Do) |
814293 |
821431 |
|
SR10A[1] |
Sensitive receivers (Ma Wan FCZ)1 |
823741 |
823495 |
|
SR10B(N)[1] |
Sensitive receivers (Ma Wan FCZ)2 |
823683 |
823187 |
|
CS(Mf)3(N) |
Control
Station |
808814 |
822355 |
|
CS(Mf)5 |
Control Station |
817990 |
821129 |
|
CS4 |
Control Station |
810025 |
824004 |
|
CS6 |
Control Station |
817028 |
823992 |
|
CSA[2] |
Control Station |
818103 |
823064 |
|
Note: |
|||
|
(1) Additional monitoring station for Ma Wan
FCZ. |
|||
|
(2)
Additional
control monitoring station for Ma Wan FCZ |
|||
|
Remarks: |
|||
|
The ET of this Contract should conduct impact water quality
monitoring at the WQMS listed in the table as part of EM&A programme
according to latest notification from ENPO when the monitoring station(s)
is/are no longer covered by another ET of the HZMB project. The ET of the Contract
shall communicate and share the monitoring data to the ET(s) of other works
contracts if the water quality monitoring station(s) is/are as part of
EM&A programme. |
|||
4.2
Monitoring
Requirements
The
monitoring requirements, monitoring equipment, monitoring parameters, frequency
and duration, monitoring methodology, monitoring schedule, meteorological
information are detailed in the monthly EM&A Reports prepared for Contract
No. HY/2013/01.
4.2.1 The event and action plan is provided in Appendix
D.
4.2.2 The Action and Limit Levelsfor Water Quality are provided in Table 4.2
Table 4.2 Action and Limit
Levels for Water Quality
|
Parameters |
Action |
Limit |
|
DO in mg/L (Surface, Middle & Bottom) |
Surface and Middle 5.0 Bottom 4.7 |
Surface and Middle 4.2 (except 5 mg/L for FCZ) Bottom 3.6 |
|
SS in mg/L(depth-averaged) at all monitoring
stations and control stations |
23.5 and 120% of upstream control station's SS at
the same tide of the same day* |
34.4 and 130% ofupstream control station's SS at
the same tide of the same day and 10mg/L for WSD Seawater intakes* |
|
Turbidity in NTU (depth-averaged) |
27.5 and 120% of upstream control station's
turbidity at the same tide of the same day* |
47.0 and 130% of upstream control station's
turbidity at the same tide of the same day* |
|
* Remarks: Reference is made to EPD
approval of adjustment of water quality assessment criteria issued and became
effective on 18 February 2013. |
|||
|
Notes:
1.
"depth-averaged" is calculated by taking the arithmetic
means of reading of all three depths. |
|||
|
2. For DO, non-compliance of
the water quality limits occurs when monitoring result is lower than the
limits. |
|||
|
3.For
turbidity, SS, non-compliance of the water quality limits occurs when
monitoring result is higher than the limits. |
|||
|
4. All the figures given in
the table are used for reference only and the EPD may amend the figures
whenever it is considered as necessary. |
|||
|
5. The 1%-ile of baseline
data for dissolved oxygen (surface and middle) and dissolved oxygen (bottom)
are 4.2mg/L and 3.6mg/L respectively. |
|||
4.2.3 If exceedance(s) at these stations is/are recorded by
the ET of the Contract or referred by the other ET under the HZMB project to
the Contract, the ET of the Contract will carry out an investigation and
findings will be reported in the monthly EM&A Report.
4.3
Monitoring Result
4.3.1 Themonitoring
results for the monitoring stations showed in Table 4.1 are reported in
the monthly EM&A Report prepared for Contract No. HY/2013/01. During September 2017, there
were 137 action level exceedances and 26 limit
level exceedances of dissolved
oxygen, 5 action level
exceedances and 1 limit level exceedance of turbidity, 8 action
level exceedances and 1 limit level exceedances of suspended solid. Table 4.3summarized
the number of exceedance on each sampling data.
Table 4.3
Number of Exceedances for Water Quality Monitoring
|
Sampling Date |
No. of Exceedances |
|||||
|
DO |
Turbidity |
SS |
||||
|
Action |
Limit |
Action |
Limit |
Action |
Limit |
|
|
1/9/2017 |
8 |
0 |
0 |
0 |
0 |
0 |
|
6/9/2017 |
4 |
4 |
1 |
0 |
3 |
0 |
|
8/9/2017 |
24 |
4 |
4 |
0 |
2 |
1 |
|
11/9/2017 |
30 |
3 |
0 |
0 |
0 |
0 |
|
13/9/2017 |
13 |
3 |
0 |
0 |
0 |
0 |
|
15/9/2017 |
10 |
2 |
0 |
1 |
0 |
0 |
|
18/9/2017 |
8 |
2 |
0 |
0 |
1 |
0 |
|
20/9/2017 |
3 |
2 |
0 |
0 |
1 |
0 |
|
22/9/2017 |
17 |
4 |
0 |
0 |
0 |
0 |
|
25/9/2017 |
1 |
1 |
0 |
0 |
1 |
0 |
|
27/9/2017 |
6 |
1 |
0 |
0 |
0 |
0 |
|
29/9/2017 |
13 |
0 |
0 |
0 |
0 |
0 |
|
Total: |
137 |
26 |
5 |
1 |
8 |
1 |
4.3.2
After investigation, there was concluded that the
exceedances were not relevant to this Contract since there was only one marine
based activity which is demolition of temporary loading and unloading pointof this Contract worked at HKBCF reclamation
site near the sea area or area near the monitoring stationsThe demolition of temporary loading and unloading point
was started from 18 July 2017. The major marine based activity was the removal
of marine piling of temporary loading and unloading point. All marine based activities were carried
out within the silt curtain and no defect of silt curtain was recorded by Contract
No. HY/2010/02 from 18 July
2017 to 31August 2017. Besides, there was also no DO, turbidity and SS exceedance recorded during 18 July 2017 to 31 August
2017. Therefore, the exceedance was not caused by demolition
of temporary loading and unloading point.The Investigation Reports No. 019, 020, 021 and 022(including the causes of exceedance, action taken
and recommendation for mitigation) for Action or Limit Level Non-compliance
were provided in Appendix J. As confirmed by
SRE, removal of temporary loading and unloading point by Contract No.
HY/2013/02, which involved marine work, was completed on 10 September and the
area was handed back to Reclamation Contractor on 11 September 2017 for
subsequent seawall construction. No marine based works for demolition of
loading and unloading point was conducted so thatno investigation report was
provided for all exceedances recorded after 11 September 2017.There was
no Action and Limit Level exceedance recorded on other monitoring date at the
monitoring stations showed at Table 4.1 by the Environmental Team of
Contract No. HY/2013/01 during the
reporting period.
4.3.3
Although the
exceedances were not relevant to this Contract, the Contractor was reminded to
ensure that the maintenance of perimeter silt curtains with respect to the work
boundary of this Contract carried out by the Contractor of Contract
No. HY/2010/02is maintained properly.
5.
DOLPHIN MONITORING
5.1.
Monitoring Locations
The dolphin monitoring works for the Contract are covered by Contract No. HY/2013/01 Hong Kong-Zhuhai-Macao Bridge HKBCF –Passenger Clearance Building. The ET of the Contract
or another ET of the HZMB project is required to conduct dolphin monitoring at
24 transects as part of EM&A programme if these
transects are no longer covered under Contract No. HY/2013/01. The dolphin
monitoring should adopt line-transect vessel survey method. The survey
follows pre-set and fixed transect lines in the two areas defined by AFCD as:
Northeast Lantau survey area; and Northwest Lantau survey area. Figure 3shows the co-ordinates
for the transect lines and layout map.
5.2.
Monitoring Requirements
The
monitoring requirements, monitoring equipment, monitoring parameters, frequency
and duration, monitoring methodology, monitoring schedule, meteorological
information are detailed in the monthly EM&A Reports prepared for Contract
No. HY/2013/01.
5.2.1.
The event and
action plan is provided in Appendix D.
5.2.2.
The Action and Limit Levels for Chinese White Dolphin Monitoring are provided in Table 5.2a & Table 5.2b
Table 5.2a Action and Limit
Levels for Chinese White Dolphin Monitoring – Approach to
Define
Action Level (AL) and Limit Level (LL)
|
|
North Lantau Social Cluster |
|
|
NEL |
NWL |
|
|
Action Level |
(STG< 70% of baseline) & (ANI < 70% of
baseline) |
(STG < 70% of baseline) & (ANI < 70% of baseline) |
|
Limit Level |
[(STG < 40% of baseline) & (ANI < 40%
of baseline)] AND [(STG < 40% of baseline) & (ANI <
40% of baseline)] |
|
For North Lantau Social
Cluster, action level will be trigger if either NEL or NWL fall below the
criteria; limit level will be triggered if both NEL and NWL fall below the
criteria.
Table 5.2b Derived
Value of Action Level (AL) and Limit Level (LL) for Chinese White
Dolphin
Monitoring
|
|
North Lantau Social Cluster |
|
|
NEL |
NWL |
|
|
Action Level |
(STG < 4.2) & (ANI < 15.5) |
(STG < 6.9) & (ANI < 31.3) |
|
Limit Level |
[(STG < 2.4) & (ANI < 8.9)] AND [(STG
< 3.9) & (ANI < 17.9)] |
|
5.2.3.
If exceedance(s) at these transects is/are recorded by the ET of the Contract or referred by the other ET
under the HZMB project to the Contract, the ET of the Contract will carry out
an investigation and findings will be reported in the monthly EM&A Report.
5.3
Monitoring Result
Thedolphin survey
results for all transects are reported in the monthly
EM&A Reports prepared for Contract No. HY/2013/01.
6.
ENVIRONMENTAL SITE INSPECTION AND AUDIT
6.1
Site Inspection
6.1.1
SiteInspections
were carried out on a weekly basis to monitor the implementation of proper
environmental pollution control mitigation measures for the project. During the
reporting period, site inspections were carried out on 07, 14, 21 &
28September 2017.
6.1.2
Particular observations during the site inspections are described
below:
31 August 2017
(a)
Improper disposal of general refuse was observed at Portion D.General refuse
was collected at Portion D.The observation was closed
on07 September 2017.
(b)
Oil container
without drip tray was observed at Portion F. Oil container was removed at Portion F.The observation was closed on07 September 2017.
(c)
Improper disposal
of general refuse was observed at Portion F. General refuse was collected at Portion F.The observation was closed on07 September 2017.
07 September 2017
(a)
Improper disposal of general refuse was
observed at Portion C.General refuse was collected at Portion C.The
observation was closed on14 September 2017.
14
September 2017
(a)
Damaged NRMM label was observed on a generator at Portion C.Appropriate NMRR label was provided on a
generator at Portion C.The observation was closed
on 21 September 2017.
(b)
Oil container
without drip tray was observed at Portion F. Oil container was removed at
Portion F. The observation was closed on 21 September 2017.
21
September 2017
(a)
Oil container without drip tray was observed
at Portion C.Drip tray was provided
for the oil container at Portion C.The observation was closed
on 28September 2017.
(b)
C& D waste was observed at Portion C & D waste was sorted and stored at a
designated area at Portion C.The observation was closed
on 28 September 2017.
(c)
Substandard NRMM label was observed on a
generator at Portion F.Appropriate
NRMM label was provided at Portion F.The observation was closed
on 28 September 2017.
(d)
Sand was found accumulated in the drip tray
at Portion F.Accumulated sand was
removed at Portion F.The observation was closed
on 28 September 2017.
28September 2017
(a)
Missing of NRMM label was observed on an
excavator at Portion D.Follow-actions for
outstanding observation will be inspected during the next site inspection.
(b)
Cement mixing process without sheltered on
top and 3 sides was observed at Portion D.Follow-actions for outstanding observation will be inspected during the
next site inspection.
(c)
Substandard NRMM label was observed on a
generator at Portion D.Follow-actions for
outstanding observation will be inspected during the next site inspection.
6.2
Advice on the Solid and
Liquid Waste Management Status
6.2.1
TheContractor registered as a chemical waste producer for the Contract.
Sufficient numbers of receptacles were available for general refuse collection
and sorting.
6.2.2
There wasno excavated marine sedimentgenerated in this reporting period. The
excavated marine sediment was stored properly on site during this reporting period until further instruction by
the Engineer. The disposal of excavated sediment as
per EP-353/2009/K to be implemented subject to confirmation.
6.2.3
Disposal of Marine
Sediment
6.2.3.1
For the marine sediment disposal, after the
acceptance of the review of the approved Sediment Quality Report (SQR) for this
Project under EPD letter dated 19 August 2015, an approval to dispose the
marine sediment extracted from bored piling for this Project was then approved
under memo from Secretary, Marine Fill Committee of CEDD dated 20 August 2015
for the disposal of marine sediment extracted from bored piling works. The
disposal sites allocated to this Project are the Mud Pit CMP2 of the Confined
Marine Sediment Disposal Facility to the South of The Brothers (or at the East
of Sha Chau). As advised by CEDD in the memo dated 19 February 2016, from 00:00
on 22 March 2016 onward, the disposal space at CMP2 of the South of The
Brothers is closed and all disposal of contaminated sediment is to be carried
out at CMP Vd to the East of Sha Chau (ESC). As a practical means, the disposal
operation is managed by one contractor who is also responsible for applying
dumping permit and its subsequent extension applications from EPD. Contract No.
HY/2013/03 has been assigned to coordinate and arrange for disposal of
extracted marine sediment from Contract No. HY/2013/02, HY/2013/03 and
HY/2013/04.
6.2.3.2
For the dumping arrangement, the barge for disposal
of marine sediment will moor at the temporary loading and unloading at the east
shore of the HKBCF Island, which has been being used by contractor Contract No.
HY/2010/02 for reclamation activities. In terms of safety consideration and to
avoid mixing of sediment between contracts, each dumping date will be allocated
to one Contract. The quantity of marine sediment disposed on each date is from
one Contract.
6.2.3.3 During dumping,
HY/2013/02 is responsible for transporting the marine sediment from his site
area to the barge by Land transportation. The estimated quantity of marine
sediment in each truck is confirmed by Resident Site
Staff of each Contract. The trip tickets for transportation and disposal of
marine sediment are collected and checked. Contract No. HY/2013/03 as the
dumping permit holder is responsible for reporting to EPD the quantity
disposed of as the condition stipulated in the dumping permit.
6.2.4 There was no marine sediment
extracted from bored piling in this Contract disposed to allocated dumping site
via Contract No. HY/2013/03 in this reporting period. As confirmed by RSS that the disposal ofexcavated marine sediments has been completed
with the last batch disposal on 30 August 2017. The quantity disposed up to end of September 2017 was 20664 m3.The Monthly Summary of Marine sediment disposed to
dumping site was provided in Appendix E and Table 6.1.
Table 6.1 Summary
of marine sediment disposed to dumping site via Contract No.
HY/2013/03
|
Month/Year |
Quantity disposed (m3) |
|
January 2016 |
1272 |
|
February 2016 |
2816 |
|
March 2016 |
600 |
|
April 2016 |
5128 |
|
May 2016 |
0 |
|
June 2016 |
1200 |
|
July 2016 |
728 |
|
August 2016 |
1784 |
|
September 2016 |
2328 |
|
October 2016 |
1096 |
|
November 2016 |
0 |
|
December 2016 |
1568 |
|
January 2017 |
0 |
|
February 2017 |
88 |
|
March 2017 |
0 |
|
April 2017 |
624 |
|
May 2017 |
0 |
|
June 2017 |
1432 |
|
July 2017 |
0 |
|
August 2017 |
0 |
|
September 2017 |
0 |
|
Total = |
20664 |
6.2.5 The Contractor shall
ensure no spilling and overflowing of materials during loading / unloading /
transportation is allowed.
6.2.6 The monthly summary of waste flow table is
detailed in Appendix E.
6.2.7 The Contractor was reminded that chemical
waste containers should be properly treated and stored temporarily in
designated chemical waste storage area on site in accordance with the Code of
Practice on the Packing, Labelling and Storage of Chemical Waste.
6.3
Environmental Licenses
and Permits
6.3.1 The valid environmental licenses and permits
during the reporting period are summarized in Appendix F.
6.4
Implementation Status of Environmental Mitigation
Measures
6.4.1 In response to the site audit findings, the
Contractor carried out corrective actions.
6.4.2 The Contractor waters 8 times per day on all
exposed soil within the project site and associated works areas when
construction activities are being undertaken.
6.4.3 TheContractor wasreminded to provide well-maintained plant operated on-site and plant served
regularly;
6.4.4 TheContractor wasreminded to switch off vehicles and equipment while not in use;
6.4.5 TheContractor wasreminded to schedule the construction works to minimize noise nuisance etc.
6.4.6 The implementation status of Regular Marine Travel Route Plan (RMTRP) was
checked by ET. Training material
of Regular Marine Travel Route Plan was prepared and given to relevant staff.
Those records were kept properly. Since the marine delivery of precast segments
was completed in July 2017 and the removal of
temporary loading and unloading point by Contract No. HY/2013/02, which
involved marine work, was completed on 10 September 2017 and the area was handed back to Reclamation Contractor on
11 September 2017 for subsequent seawall construction, no marine traffic records and geographical
plots of the vessels tracks to demonstrate the conformance of the vessel to the
proposed route in September 2017 would be provided to ER, ETL, IEC/ENPO for
checking within the month of October 2017.The implementation
status of silt curtain deployment and dolphin watching plan was also checked by
ET that silt curtain was deployed and MMO was provided by Contract No.
HY/2010/02.
6.4.7 The tool box training of dolphin was carried
out in Dec 2015. According to the action plan and communication flow chart of
dolphin instruction, if any dolphin intruded BCF perimeter silt curtain, ETL
should be informed. There was no notification received on any dolphin intrusion
during the reporting period.
6.4.8 A summary of the implementation Schedule of
Environmental Mitigation Measures (EMIS) is presented in Appendix G.
Most of the necessary mitigation measures were implemented properly.
6.5
Summary of Exceedance of
the Environmental Quality Performance Limit
6.5.1 Summary of Action and Limit Level exceedance of 1-hr TSP level and 24-hr
TSP level at AMS6 shall be referred to the monthly EM&A report prepared by
Contract No. HY/2011/03.
6.5.2 There was no Action and Limit Level exceedance
of 1-hr TSP level and 24-hr TSP level
recorded at station AMS7 by the Environmental Team of Contract No. HY/2013/01during the reporting period.
6.5.3 There was no Action and Limit Level exceedance
for noise recorded at station
NMS2 and station NMS3B by the Environmental Team of Contract No. HY/2013/01during the reporting period.
6.5.4 There were 137 action level exceedances and 26 limit level
exceedances of dissolved
oxygen, 5 action level
exceedances and 1 limit level exceedance of turbidity, 8 action
level exceedances and 1 limit level exceedances of suspended solid. Table 4.3summarized
the number of exceedance on each sampling data. The Investigation Reports
No. 019, 020, 021 and 022 (including the causes of exceedance,
action taken and recommendation for mitigation) for Action or Limit Level
Non-compliance were provided in Appendix J. As
confirmed by SRE, removal of temporary loading and unloading point by Contract
No. HY/2013/02, which involved marine work, was completed on 10 September 2017 and the area was handed back to
Reclamation Contractor, Contract
No. HY/2010/02,on 11 September 2017 for
subsequent seawall construction. No marine based works for demolition of
loading and unloading point was conducted so that no investigation report was
provided for all exceedances recorded after 11 September 2017. There was no
Action and Limit Level exceedance recorded on other monitoring date at the
monitoring stations showed at Table 4.1 by the Environmental Team of Contract
No. HY/2013/01 during the
reporting period.
Table 4.3
Number of Exceedances for Water Quality Monitoring
|
Sampling Date |
No. of Exceedances |
|||||
|
DO |
Turbidity |
SS |
||||
|
Action |
Limit |
Action |
Limit |
Action |
Limit |
|
|
1/9/2017 |
8 |
0 |
0 |
0 |
0 |
0 |
|
6/9/2017 |
4 |
4 |
1 |
0 |
3 |
0 |
|
8/9/2017 |
24 |
4 |
4 |
0 |
2 |
1 |
|
11/9/2017 |
30 |
3 |
0 |
0 |
0 |
0 |
|
13/9/2017 |
13 |
3 |
0 |
0 |
0 |
0 |
|
15/9/2017 |
10 |
2 |
0 |
1 |
0 |
0 |
|
18/9/2017 |
8 |
2 |
0 |
0 |
1 |
0 |
|
20/9/2017 |
3 |
2 |
0 |
0 |
1 |
0 |
|
22/9/2017 |
17 |
4 |
0 |
0 |
0 |
0 |
|
25/9/2017 |
1 |
1 |
0 |
0 |
1 |
0 |
|
27/9/2017 |
6 |
1 |
0 |
0 |
0 |
0 |
|
29/9/2017 |
13 |
0 |
0 |
0 |
0 |
0 |
|
Total: |
137 |
26 |
5 |
1 |
8 |
1 |
6.5.5 Impact dolphin monitoring results at all transects are reported in the EM&A Reports
prepared for Contract No. HY/2013/01.
6.6
Summary of Complaints,
Notification of Summons and Successful Prosecution
6.6.1 There were no complaints received during the reporting period.
6.6.2 There were no notifications
of summons or prosecutions received during thereporting period.
6.6.3 Statistics on environmentalcomplaints, notifications of
summons and successful prosecutions are summarized in
Appendix H.
7.1
Construction Programme
for the Coming Months
7.1.1 As informedby the Contractor, the major
construction activities for October 2017 are summarized:
l
Road and Bituminous works
l
Storm, sewer drainage and water main construction;
l
Retaining wall, slop and earth works
l
Construction of signs gantries, cable trench and ducting;
l
Construction of parapet & barrier
7.2
Environmental Site
Inspection Schedule for the Coming Month
7.2.1 The tentative schedule for weekly site
inspections for October2017 is provided in Appendix I.
8.1
Conclusions
8.1.1 The site preparation work of the Contract was
started on 25 July 2014 and the construction works of the Contract commenced on
24 November 2014.
8.1.2 Summary of Action and Limit Level exceedance of 1-hr TSP level and 24-hr
TSP level at AMS6 shall be referred to the monthly EM&A report prepared by
Contract No. HY/2011/03.
8.1.3 There was no Action and Limit Level exceedance
of 1-hr TSP level and 24-hr TSP level
recorded at station AMS7 by the Environmental Team of Contract No. HY/2013/01during the reporting period.
8.1.4 There was no Action and Limit Level exceedance for noise recorded at station NMS2 and station NMS3B by the
Environmental Team of Contract No. HY/2013/01during the reporting period.
8.1.5 There were 137 action level exceedances and 26 limit level
exceedances of dissolved
oxygen, 5 action level
exceedances and 1 limit level exceedance of turbidity, 8 action
level exceedances and 1 limit level exceedances of suspended solid. Table 4.3summarized
the number of exceedance on each sampling data. The Investigation Reports
No. 019, 020, 021, 022, 023 and 024 (including the causes of exceedance, action taken and recommendation
for mitigation) for Action or Limit Level Non-compliance were provided in Appendix
J. As confirmed by SRE, removal of temporary
loading and unloading point by Contract No. HY/2013/02, which involved marine
work, was completed on 10 September and the area was handed back to Reclamation
Contractor on 11 September 2017 for subsequent seawall construction. No
marine based works for demolition of loading and unloading point was conducted
so that no investigation report was provided for all exceedances recorded after
11 September 2017. There was no Action and Limit Level exceedance
recorded on other monitoring date at the monitoring stations showed at Table
4.1 by the Environmental Team of Contract No. HY/2013/01 during the reporting period.
Table 4.3
Number of Exceedances for Water Quality Monitoring
|
Sampling Date |
No. of Exceedances |
|||||
|
DO |
Turbidity |
SS |
||||
|
Action |
Limit |
Action |
Limit |
Action |
Limit |
|
|
1/9/2017 |
8 |
0 |
0 |
0 |
0 |
0 |
|
6/9/2017 |
4 |
4 |
1 |
0 |
3 |
0 |
|
8/9/2017 |
24 |
4 |
4 |
0 |
2 |
1 |
|
11/9/2017 |
30 |
3 |
0 |
0 |
0 |
0 |
|
13/9/2017 |
13 |
3 |
0 |
0 |
0 |
0 |
|
15/9/2017 |
10 |
2 |
0 |
1 |
0 |
0 |
|
18/9/2017 |
8 |
2 |
0 |
0 |
1 |
0 |
|
20/9/2017 |
3 |
2 |
0 |
0 |
1 |
0 |
|
22/9/2017 |
17 |
4 |
0 |
0 |
0 |
0 |
|
25/9/2017 |
1 |
1 |
0 |
0 |
1 |
0 |
|
27/9/2017 |
6 |
1 |
0 |
0 |
0 |
0 |
|
29/9/2017 |
13 |
0 |
0 |
0 |
0 |
0 |
|
Total: |
137 |
26 |
5 |
1 |
8 |
1 |
8.1.6 Impact dolphin monitoring
results at all transects are reported in the EM&A
Reports prepared for Contract No. HY/2013/01.
8.1.7 There were no complaints received during the reporting period.
8.1.8 There were no
notifications of summons or prosecutions received during thereporting period.
- END OF REPORT -
