TABLE OF CONTENTS
|
||
1 |
1-2 |
|
1.1 |
Basic Project Information |
1 |
1.2 |
Project Organization |
2 |
1.3 |
Construction Programme |
2 |
1.4 |
Construction Works Undertaken During the Reporting Period |
2 |
|
|
|
2 |
3 |
|
2.1 |
Monitoring Locations |
3 |
2.2 |
Monitoring Requirements |
3 |
2.3 |
Monitoring Results |
3 |
|
|
|
3 |
4 |
|
3.1 |
Monitoring Locations |
4 |
3.2 |
Monitoring Requirements |
4 |
3.3 |
Monitoring Results |
4 |
|
|
|
4 |
5-7 |
|
4.1 |
Monitoring Locations |
5 |
4.2 |
Monitoring Requirements |
6 |
4.3 |
Monitoring Results |
6-7 |
|
|
|
5 |
7 |
|
5.1 |
Monitoring Locations |
7 |
5.2 |
Monitoring Requirements |
7-8 |
5.3 |
Monitoring Results |
8 |
|
|
|
6 |
8-11 |
|
6.1 |
Site Inspection |
8 |
6.2 |
Advice on the Solid and Liquid Waste Management Status |
8-9 |
6.3 |
Environmental Licenses and Permits |
9 |
6.4 |
Implementation Status of Environmental Mitigation Measures |
9 |
6.5 |
Summary of Exceedance of the Environmental Quality Performance Limit |
10 |
6.6 |
Summary of Complaints, Notification of Summons and Successful Prosecution |
10-11 |
|
|
|
7 |
11 |
|
7.1 |
Construction Programme for the Coming Months |
11 |
7.2 |
Environmental Site Inspection Schedule for the Coming Month |
11 |
|
|
|
8 |
11-12 |
|
8.1 |
Conclusions |
11-12 |
Figure 1 |
Air Quality and Noise Monitoring Stations for HKBCF |
Figure 2 |
Water Quality Monitoring Stations (construction phases) |
Figure 3 |
Dolphin Monitoring Transect Line and Layout Map |
|
|
|
|
|
|
TABLE |
|
Table 1.1 |
Contact Information of Key Personnel |
Table 2.1 |
Air Quality Monitoring Locations |
Table 2.2 |
Action and Limit Levels for 1-hour TSP |
Table 2.3 |
Action and Limit Levels for 24-hour TSP |
Table 3.1 |
Construction Noise Monitoring Locations |
Table 3.2 |
Action and Limit Levels for Construction Noise |
Table 4.1 |
Water Quality Monitoring Stations (construction phases) |
Table 4.2 |
Action and Limit Levels for Water Quality |
Table 5.1a |
Action and Limit Levels for Chinese White Dolphin Monitoring – Approach to Define Action Level (AL) and Limit Level (LL) |
Table 5.1b |
Action and Limit Levels for Chinese White Dolphin Monitoring - |
Table 6.1 |
Summary of Quantities of Inert C&D Materials |
Table 6.2 |
Summary of Quantities of C&D Materials |
|
|
|
|
|
|
APPENDICES |
|
Location of Works Areas |
|
Project Organization for Environmental Works |
|
Construction Programme |
|
Event and Action Plan |
|
Monthly Summery of Waste Flow Table & Monthly Summery of Marine Sediment |
|
Environmental Licenses and Permits |
|
Implementation Schedule for Environmental Mitigation Measures (EMIS) |
|
Statistics on Environmental Complaints, Notification of Summons and Successful Prosecutions |
|
Environmental Site Inspection Schedule |
|
Complaint Investigation Report |
This Monthly Environmental Monitoring and Audit (EM&A) Report is prepared for Contract HY/2013/02 “Hong Kong–Zhuhai-Macao Bridge Hong Kong Boundary Crossing Facilities (HKBCF) – Infrastructure Works Stage I (Western Portion)” (hereafter referred to as “the Contract”) for the Highways Department of Hong Kong Special Administrative Region (HKSAR). The Contract was awarded to China Harbour Engineering Co., Ltd. (hereafter referred to as “the Contractor”) and ETS-Testconsult Limited was appointed as the Environmental Team (ET) by the Contractor.
The Contract is part of Hong Kong–Zhuhai–Macao Bridge HKBCF which is a “Designated Project”, under Schedule 2 of the Environmental Impact Assessment Ordinance (EIAO) (Cap 499) and Environmental Impact Assessment (EIA) Report (Register No. AEIAR-145/2009) was prepared for the Project. The current Environmental Permit (EP) No. EP-353/2009/K for HKBCF was issued on 11 April 2016. These documents are available through the EIA Ordinance Register. Site preparation works of the Contract was started on 25 July 2014 and the construction works of the Contract commenced on 24 November 2014.
ETS-Testconsult Limited has been appointed by the Contractor to implement the Environmental Monitoring & Audit (EM&A) programme for the Contract in accordance with the Updated EM&A Manual for HKBCF (Version 1.0) and provide environmental team services to the Contract.
This is the forty-fourth Monthly Environmental Monitoring and Audit (EM&A) Report for the Contract which summaries findings of the EM&A works conducted during the reporting period from 01 July to 31 July 2018.
Site Activities
As confirmed by RSS, the capital works were substantially completed on 28 March 2018. Site activities were carried out in this reporting month as informed by the Contractor:
l Establishment work for Landscape
Environmental Monitoring and Audit Progress
The monthly EM&A programme was undertaken in accordance with the Updated EM&A Manual for HKBCF (Version 1.0). It should be noted that the air quality and noise monitoring works for the Contract are covered by Contract No. HY/2013/01 “Hong Kong-Zhuhai-Macao Bridge HKBCF – Passenger Clearance Building” and Contract No. HY/2011/03 “Hong Kong-Zhuhai-Macao Bridge Hong Kong Link Road – Section between Scenic Hill and HKBCF”. The ET of the Contract or another ET of the HZMB project is required to conduct impact air quality monitoring at AMS6 and AMS7B, noise monitoring at NMS2 and NMS3B, water quality monitoring show in Figure 2 and dolphin monitoring show in Figure 3 as part of EM&A programme if these monitoring stations are no longer covered under Contract No. HY/2013/01 and HY/2011/03. However, this is subject to ENPO’s final decision on which ET should carry out the monitoring works at these stations. The dates of site inspection during the reporting period are listed below:
Environmental Site Inspection: 05, 12, 19 & 26 July 2018
Breaches of Action and Limit Levels
Summary of Action and Limit Level exceedance of 1-hr TSP level and 24-hr TSP level at AMS6 shall be referred to the monthly EM&A report prepared by Contract No. HY/2011/03.
There was no Action and Limit Level exceedance of 1-hr TSP level and 24-hr TSP level recorded at station AMS7B by the Environmental Team of Contract No. HY/2013/01 during the reporting period.
There was no Action and Limit Level exceedance for noise recorded at station NMS2 and station NMS3B by the Environmental Team of Contract No. HY/2013/01 during the reporting period.
During July 2018, there were 39 action level exceedances and 18 limit level exceedance of dissolved oxygen, 1 action level exceedance of turbidity and 6 action level exceedance of suspended solid. The following table summarized the number of exceedance on each sampling data.
Sampling Date |
No. of Exceedances |
|||||
DO |
Turbidity |
SS |
||||
Action |
Limit |
Action |
Limit |
Action |
Limit |
|
02/07/2018 |
6 |
0 |
0 |
0 |
0 |
0 |
04/07/2018 |
5 |
0 |
0 |
0 |
0 |
0 |
06/07/2018 |
8 |
5 |
0 |
0 |
0 |
0 |
09/07/2018 |
12 |
9 |
0 |
0 |
0 |
0 |
11/07/2018 |
2 |
0 |
1 |
0 |
0 |
0 |
13/07/2018 |
4 |
2 |
0 |
0 |
3 |
0 |
16/07/2018 |
2 |
2 |
0 |
0 |
2 |
0 |
27/07/2018 |
0 |
0 |
0 |
0 |
1 |
0 |
Total: |
39 |
18 |
1 |
0 |
6 |
0 |
Since the removal of temporary loading and unloading point by Contract No. HY/2013/02, which involved marine work, was completed on 10 September 2017 and the area was handed back to Reclamation Contractor with Contract No. HY/2010/02 on 11 September 2017 for subsequent seawall construction as confirmed by RSS, there was no marine works or barge of this Contract worked at HKBCF reclamation site near the sea area or area near the monitoring station under Contract No. HY/2013/02 during July 2018. Hence, specific investigation shall be referred to other ET’s report(s) under the HZMB Projects in which the respective contract(s) with remaining marine works on-going for the exceedances recorded in water quality monitoring during this reporting month. There was no Action and Limit Level exceedance recorded on other monitoring date at the monitoring stations showed at Table 4.1 by the Environmental Team of Contract No. HY/2013/01 during the reporting period.
Complaint Log
Follow-up action to the complaint received by Highways Department on 13 June 2018 and referred to the ENPO on 22 June 2018. Then the ENPO forwarded the complaint by email to the R.E. (AECOM), the Contractor (China Harbour) and the ET (ETS-Testconsult Ltd.) of Contract No. HY/2013/02 at 10:42 on 25 June 2018. After received the details of the complaint from the ENPO on 25 June 2018, a related follow-up inspection was conducted by ET and the Contractor of Contract No. HY/2013/02 to investigate this event. The inspection was concentrated to check if there is any improper discharged by Contract No. HY/2013/02. After checked with the Contractor of Contract No. HY/2013/02, only Box Culvert A is within our site boundary. There was no any muddy water discharge observed during inspection on 25 June 2018. Besides, during weekly environmental site inspection on 27 June 2018, Box Culvert A was checked and inspected. No muddy water discharge was observed. Besides, the capital works were substantially completed on 28 March 2018 and no construction activities that would generate wastewater with high concentrations of suspended solid were conducted on 13 June 2018. Moreover, as discussed with the contractor, all the washing/de-silting/removal of grit works inside manholes has been completed before 30 April 2018 and no exposed earth ground was observed during the inspection. Hence, the complaint received on 13 June 2018 was found non-related to Contract No. HY/2013/02. The complaint investigation report (Log No. 019) was provided in Appendix J.
Notifications of Summons and Successful Prosecutions
There were no notifications of summons or prosecutions received during the reporting period.
Reporting Change
There were no reporting changes during the reporting period.
Future Key Issues
The future key issues to be undertaken in the upcoming month are as follows:
l Establishment work for Landscape
1. INTRODUCTION
1.1. Basic Project Information
1.1.1. This Monthly Environmental Monitoring and Audit (EM&A) Report is prepared for Contract HY/2013/02 “Hong Kong–Zhuhai-Macao Bridge Hong Kong Boundary Crossing Facilities (HKBCF) – Infrastructure Works Stage I (Western Portion)” (hereafter referred to as “the Contract”) for the Highways Department of Hong Kong Special Administrative Region (HKSAR). The Contract was awarded to China Harbour Engineering Co., Ltd. (hereafter referred to as “the Contractor”) and ETS-Testconsult Limited was appointed as the Environmental Team (ET) by the Contractor.
1.1.2. The Contract is part of Hong Kong–Zhuhai–Macao Bridge HKBCF which is a “Designated Project”, under Schedule 2 of the Environmental Impact Assessment Ordinance (EIAO) (Cap 499) and Environmental Impact Assessment (EIA) Report (Register No. AEIAR-145/2009) was prepared for the Project. The current Environmental Permit (EP) No. EP-353/2009/K for HKBCF was issued on 11 April 2016. These documents are available through the EIA Ordinance Register. Site preparation works of the Contract started on 25 July 2014 and the construction works of the Contract commenced on 24 November 2014. The works area of the Contract is shown in Appendix A.
1.1.3. The proposed works under this Contract comprise the following:
l Construction of the viaducts and roads at the western portion of Hong Kong Boundary Crossing Facilities (HKBCF) mainly for connection with the Hong Kong–Zhuhai–Macao Bridge (HZMB), Hong Kong Link Road (HKLR), Hong Kong International Airport (HKIA) and the Tuen Mun-Chek Lap Kok Link (TM-CLKL);
l Construction of the road modification at the SkyCity Interchange at Airport Island;
l Construction of associated street lighting, street furniture, road marking, road signage, drainage, sewerage, fresh water and flushing water supply, irrigation, landscape, electrical and mechanical (E&M), utilities and services works;
l Provisioning of civil engineering works and power supply installation for the Traffic Control and Surveillance System TCSS;
l Other works in accordance with the Contract.
1.1.4. This is the forty-fourth Monthly Environmental Monitoring and Audit (EM&A) Report for the Contract which summaries the audit findings of the EM&A programme during the reporting period from 01 July to 31 July 2018.
1.2. Project Organization
1.2.1. The project organization structure and lines of communication with respect to the on-site environmental management structure is shown in Appendix B. The key personnel contact names and numbers are summarized in Table 1.1.
Table 1.1 Contact Information of Key Personnel
Party |
Position |
Name of Key Staff |
Tel. No. |
Fax No. |
Engineer or Engineer’s Representative (AECOM Asia Co. Ltd.) |
Resident Engineer |
Mr. Winston Wong |
6330 8293 |
3152 5116 |
Environmental Project Office / Independent Environmental Checker (Ramboll Hong Kong Limited*) |
Environmental Project Office Leader |
Mr. Y. H. Hui |
3465 2888 |
3465 2899 |
Independent Environmental Checker |
Mr. Raymond Dai |
3465 2888 |
3465 2899 |
|
Environmental Site Supervisor |
Mr. Ray Yan |
5181 8165 |
3465 2899 |
|
Contractor (China Harbour Engineering Co., Ltd.) |
Environmental Officer |
Mr. Richard Ng |
5977 0593 |
3915 0300 |
Environmental Supervisor |
Mr. Endy Tse |
5977 0594 |
3915 0300 |
|
Environmental Team (ETS-Testconsult Ltd.) |
Environmental Team Leader |
Mr. C. L. Lau |
2946 7791 |
2695 3944 |
(*) “Ramboll Environ Hong Kong Limited“ was re-branded as “Ramboll Hong Kong Limited” since 03 January 2018. |
1.3. Construction Programme
1.3.1. A copy of the Contractor’s construction programme is provided in Appendix C.
1.4. Construction Works Undertaken During the Reporting Period
1.4.1. As confirmed by RSS, the capital works were substantially completed on 28 March 2018. A summary of the construction activities undertaken during this reporting period is shown below:
- Establishment work for Landscape
2.1. Monitoring Locations
2.1.1. The air quality monitoring works for the Contract are covered by Contract No. HY/2013/01 Hong Kong-Zhuhai-Macao Bridge HKBCF – Passenger Clearance Building and Contract No. HY/2011/03 Hong Kong-Zhuhai-Macao Bridge Hong Kong Link Road – Section between Scenic Hill and HKBCF. The ET of the Contract or another ET of the HZMB project is required to conduct impact air quality monitoring at AMS6 and AMS7B as part of EM&A programme if these air quality monitoring stations are no longer covered under Contract No. HY/2013/01 and HY/2011/03. Table 2.1 and Figure 1 shows the locations of air monitoring stations.
Table 2.1 Air Quality Monitoring Locations
Identification No. |
Location Description |
AMS6(1) |
Dragonair / CNAC (Group) Building |
AMS7B(1) (2) |
3RS Site Offices |
Remarks: |
|
(1) The ET of this Contract should conduct impact air quality monitoring at the AMS listed in the table as part of EM&A programme according to latest notification from ENPO when the monitoring station(s) is/are no longer covered by another ET of the HZMB project. |
|
(2) Alternative Air Quality Monitoring Stations with effect from 06 February 2018 |
2.2. Monitoring Requirements
2.2.1. The monitoring requirements, monitoring equipment, monitoring parameters, frequency and duration, monitoring methodology, monitoring schedule, meteorological information are detailed in the monthly EM&A Reports prepared for Contract Nos. HY/2013/01 and HY/2011/03.
2.2.2. The Action and Limit Levels for 1-hr TSP and 24-hr TSP are provided in Table 2.2 and Table 2.3 respectively.
Table 2.2 Action and Limit Levels for 1-hour TSP
Monitoring Station |
Action Level,mg/m3 |
Limit Level,mg/m3 |
AMS6 – Dragnair / SNAC (Group) Building (HKIA) |
360 |
500 |
AMS7B - 3RS Site Offices |
370 |
500 |
Table 2.3 Action and Limit Levels for 24-hour TSP
Monitoring Station |
Action Level,mg/m3 |
Limit Level,mg/m3 |
AMS6 – Dragnair / SNAC (Group) Building (HKIA) |
173 |
260 |
AMS7B - 3RS Site Offices |
183 |
260 |
2.2.3. The event and action plan is provided in Appendix D.
2.2.4. If exceedance(s) at these stations is/are recorded by the ET of the Contract or referred by the other ET under the HZMB project to the Contract, the ET of the Contract will carry out an investigation and findings will be reported in the monthly EM&A Report.
2.3. Monitoring Results
2.3.1. The monitoring results for AMS6 and AMS7B are reported in the monthly EM&A Reports prepared for Contract Nos. HY/2011/03 and HY/2013/01 respectively.
2.3.2. Summary of Action and Limit Level exceedance of 1-hr TSP level and 24-hr TSP level at AMS6 shall be referred to the monthly EM&A report prepared by Contract No. HY/2011/03.
2.3.3. There was no Action and Limit Level exceedance of 1-hr TSP level and 24-hr TSP level recorded at station AMS7B by the Environmental Team of Contract No. HY/2013/01 during the reporting period.
3.1. Monitoring Locations
3.1.1. The noise monitoring works for the Contract are covered by Contract No. HY/2013/01 Hong Kong-Zhuhai-Macao Bridge HKBCF – Passenger Clearance Building. The ET of the Contract or another ET of the HZMB project is required to conduct noise monitoring at NMS2 and NMS3B as part of EM&A programme if these monitoring stations are no longer covered under Contract No. HY/2013/01. Table 3.1 and Figure 1 shows the locations of noise monitoring stations.
Table 3.1 Construction Noise Monitoring Locations
Identification No. |
Location Description |
NMS2(1) |
Sea View Crescent |
NMS3B(1) (2) |
Site Boundary of Site Office Area at Works Area WA2 |
Remarks: |
|
(1) The ET of this Contract should conduct impact noise monitoring at the NMS listed in the table as part of EM&A programme according to latest notification from ENPO when the monitoring station(s) is/are no longer covered by another ET of the HZMB project. |
|
(2) The Action and Limit Levels for schools will be applied for this alternative monitoring location. |
3.2. Monitoring Requirements
3.2.1. The monitoring requirements, monitoring equipment, monitoring parameters, frequency and duration, monitoring methodology, monitoring schedule, meteorological information are detailed in the monthly EM&A Reports prepared for Contract No. HY/2013/01.
3.2.2. The Action and Limit Levels for construction noise are provided in Table 3.2
3.2.3. The event and action plan is provided in Appendix D.
Table 3.2 Action and Limit Levels for Construction Noise
Parameter |
Action Level |
Limit Level |
07:00 – 19:00 hours on normal weekdays |
When one documented complaint is received |
75 dB(A)* |
Notes: |
||
If works are to be carried out during restricted hours, the conditions stipulated in the construction noise permit issued by the Noise Control Authority have to be followed. |
||
* Reduce to 70 dB(A) for schools and 65 dB(A) during school examination period. |
3.2.4. If exceedance(s) at these stations is/are recorded by the ET of the Contract or referred by the other ET under the HZMB project to the Contract, the ET of the Contract will carry out an investigation and findings will be reported in the monthly EM&A Report.
3.3. Monitoring Results
3.3.1 The monitoring results for NMS2 and NMS3B are reported in the monthly EM&A Reports prepared for Contract No. HY/2013/01. There was no exceedance for noise recorded at station NMS2 and station NMS3B by the Environmental Team of Contract No. HY/2013/01 during the reporting period.
4.1. Monitoring Locations
The water monitoring works for the Contract are covered by Contract No. HY/2013/01 Hong Kong-Zhuhai-Macao Bridge HKBCF – Passenger Clearance Building. The ET of the Contract or another ET of the HZMB project is required to conduct water quality monitoring at twenty one stations (9 Impact Stations, 7 Sensitive Receiver Stations and 5 Control/Far Field Stations). Due to topographical conditions of SR3, SR10A and SR10B(N), the water quality monitoring (WQM) stations was proposed to be monitored at alternative WQM stations named as SR3(N), SR10A (N) and SR10B(N2). The proposal for alternation of water quality monitoring stations for HZMB HKBCF was justified by the ET Leader for Contract No. HY/2013/01 on 08 November 2017 and verified by the IEC on 13 November 2017; and submitted to EPD on 29 November 2017, and it was approved by EPD on 22 December 2017. Table 4.1 and Figure 2 shows the locations of water quality monitoring stations.
Table 4.1 Water Quality Monitoring Stations (construction phases)
Station |
Description |
East |
North |
IS5 |
Impact Station (Close to HKBCF construction site) |
811579 |
817106 |
IS(Mf)6 |
Impact Station (Close to HKBCF construction site) |
812101 |
817873 |
IS7 |
Impact Station (Close to HKBCF construction site) |
812244 |
818777 |
IS8 |
Impact Station (Close to HKBCF construction site) |
814251 |
818412 |
IS(Mf)9 |
Impact Station (Close to HKBCF construction site) |
813273 |
818850 |
IS10(N) |
Impact Station (Close to HKBCF construction site) |
812942 |
820881 |
IS(Mf)11 |
Impact Station (Close to HKBCF construction site) |
813562 |
820716 |
IS(Mf)16 |
Impact Station (Close to HKBCF construction site) |
814328 |
819497 |
IS17 |
Impact Station (Close to HKBCF construction site) |
814539 |
820391 |
SR3(N)[3] |
Sensitive receivers (San Tau SSSI) |
810689 |
816591 |
SR4(N) |
Sensitive receivers (Tai Ho) |
814705 |
817859 |
SR5(N) |
Sensitive receiver (Artificial Reef in NE Airport) |
812569 |
821475 |
SR6 |
Sensitive receivers (Sha Chau and Lung Kwu Chau Marine Park) |
805837 |
821818 |
SR7 |
Sensitive receivers (Tai Mo Do) |
814293 |
821431 |
SR10A(N) [1][3] |
Sensitive receivers (Ma Wan FCZ)1 |
823644 |
823484 |
SR10B(N2) [1][3] |
Sensitive receivers (Ma Wan FCZ)2 |
823689 |
823159 |
CS(Mf)3(N) |
Control Station |
808814 |
822355 |
CS(Mf)5 |
Control Station |
817990 |
821129 |
CS4 |
Control Station |
810025 |
824004 |
CS6 |
Control Station |
817028 |
823992 |
CSA[2] |
Control Station |
818103 |
823064 |
Note: |
|||
(1) Additional monitoring station for Ma Wan FCZ. |
|||
(2) Additional control monitoring station for Ma Wan FCZ (3) Alternative WQM Stations with effect from 22 December 2017 |
|||
Remarks: |
|||
The ET of this Contract should conduct impact water quality monitoring at the WQMS listed in the table as part of EM&A programme according to latest notification from ENPO when the monitoring station(s) is/are no longer covered by another ET of the HZMB project. The ET of the Contract shall communicate and share the monitoring data to the ET(s) of other works contracts if the water quality monitoring station(s) is/are as part of EM&A programme. |
4.2 Monitoring Requirements
The monitoring requirements, monitoring equipment, monitoring parameters, frequency and duration, monitoring methodology, monitoring schedule, meteorological information are detailed in the monthly EM&A Reports prepared for Contract No. HY/2013/01.
4.2.1 The event and action plan is provided in Appendix D.
4.2.2 The Action and Limit Levels for Water Quality are provided in Table 4.2
Table 4.2 Action and Limit Levels for Water Quality
Parameters |
Action |
Limit |
DO in mg/L (Surface, Middle & Bottom) |
Surface and Middle 5.0 Bottom 4.7 |
Surface and Middle 4.2 (except 5 mg/L for FCZ) Bottom 3.6 |
SS in mg/L (depth-averaged) at all monitoring stations and control stations |
23.5 and 120% of upstream control station's SS at the same tide of the same day* |
34.4 and 130% of upstream control station's SS at the same tide of the same day and 10mg/L for WSD Seawater intakes* |
Turbidity in NTU (depth-averaged) |
27.5 and 120% of upstream control station's turbidity at the same tide of the same day* |
47.0 and 130% of upstream control station's turbidity at the same tide of the same day* |
* Remarks: Reference is made to EPD approval of adjustment of water quality assessment criteria issued and became effective on 18 February 2013. |
||
Notes: 1. "depth-averaged" is calculated by taking the arithmetic means of reading of all three depths. |
||
2. For DO, non-compliance of the water quality limits occurs when monitoring result is lower than the limits. |
||
3. For turbidity, SS, non-compliance of the water quality limits occurs when monitoring result is higher than the limits. |
||
4. All the figures given in the table are used for reference only and the EPD may amend the figures whenever it is considered as necessary. |
||
5. The 1%-ile of baseline data for dissolved oxygen (surface and middle) and dissolved oxygen (bottom) are 4.2mg/L and 3.6mg/L respectively.
|
4.2.3 If exceedance(s) at these stations is/are recorded by the ET of the Contract or referred by the other ET under the HZMB project to the Contract, the ET of the Contract will carry out an investigation and findings will be reported in the monthly EM&A Report.
4.3 Monitoring Result
4.3.1 The monitoring results for the monitoring stations showed in Table 4.1 are reported in the monthly EM&A Report prepared for Contract No. HY/2013/01. During July 2018, there were 39 action level exceedances and 18 limit level exceedance of dissolved oxygen, 1 action level exceedance of turbidity and 6 action level exceedance of suspended solid. The following table summarized the number of exceedance on each sampling data.
Sampling Date |
No. of Exceedances |
|||||
DO |
Turbidity |
SS |
||||
Action |
Limit |
Action |
Limit |
Action |
Limit |
|
02/07/2018 |
6 |
0 |
0 |
0 |
0 |
0 |
04/07/2018 |
5 |
0 |
0 |
0 |
0 |
0 |
06/07/2018 |
8 |
5 |
0 |
0 |
0 |
0 |
09/07/2018 |
12 |
9 |
0 |
0 |
0 |
0 |
11/07/2018 |
2 |
0 |
1 |
0 |
0 |
0 |
13/07/2018 |
4 |
2 |
0 |
0 |
3 |
0 |
16/07/2018 |
2 |
2 |
0 |
0 |
2 |
0 |
27/07/2018 |
0 |
0 |
0 |
0 |
1 |
0 |
Total: |
39 |
18 |
1 |
0 |
6 |
0 |
4.3.2 Since the removal of temporary loading and unloading point by Contract No. HY/2013/02, which involved marine work, was completed on 10 September 2017 and the area was handed back to Reclamation Contractor with Contract No. HY/2010/02 on 11 September 2017 for subsequent seawall construction as confirmed by RSS, there was no marine works or barge of this Contract worked at HKBCF reclamation site near the sea area or area near the monitoring station under Contract No. HY/2013/02 during July 2018. Hence, specific investigation shall be referred to other ET’s report(s) under the HZMB Projects in which the respective contract(s) with remaining marine works on-going for the exceedances recorded in water quality monitoring during this reporting month. There was no Action and Limit Level exceedance recorded on other monitoring date at the monitoring stations showed at Table 4.1 by the Environmental Team of Contract No. HY/2013/01 during the reporting period.
4.3.3 Although the exceedances were not relevant to this Contract, the Contractor was reminded to provide appropriate water pollution mitigation measures, such as ensure all construction activities that would deteriorate the water quality was collected by sedimentation tanks or package treatment systems for proper treatment prior to disposal.
5. DOLPHIN MONITORING
5.1. Monitoring Locations
The dolphin monitoring works for the Contract are covered by Contract No. HY/2013/01 Hong Kong-Zhuhai-Macao Bridge HKBCF – Passenger Clearance Building. The ET of the Contract or another ET of the HZMB project is required to conduct dolphin monitoring at 24 transects as part of EM&A programme if these transects are no longer covered under Contract No. HY/2013/01. The dolphin monitoring should adopt line-transect vessel survey method. The survey follows pre-set and fixed transect lines in the two areas defined by AFCD as: Northeast Lantau survey area; and Northwest Lantau survey area. Figure 3 shows the co-ordinates for the transect lines and layout map.
5.2. Monitoring Requirements
The monitoring requirements, monitoring equipment, monitoring parameters, frequency and duration, monitoring methodology, monitoring schedule, meteorological information are detailed in the monthly EM&A Reports prepared for Contract No. HY/2013/01.
5.2.1. The event and action plan is provided in Appendix D.
5.2.2. The Action and Limit Levels for Chinese White Dolphin Monitoring are provided in Table 5.1a & Table 5.1b
Table 5.1a Action and Limit Levels for Chinese White Dolphin Monitoring – Approach to
Define Action Level (AL) and Limit Level (LL)
|
North Lantau Social Cluster |
|
NEL |
NWL |
|
Action Level |
(STG < 70% of baseline) & (ANI < 70% of baseline) |
(STG < 70% of baseline) & (ANI < 70% of baseline) |
Limit Level |
[(STG < 40% of baseline) & (ANI < 40% of baseline)] AND [(STG < 40% of baseline) & (ANI < 40% of baseline)] |
For North Lantau Social Cluster, action level will be trigger if either NEL or NWL fall below the criteria; limit level will be triggered if both NEL and NWL fall below the criteria.
Table 5.1b Derived Value of Action Level (AL) and Limit Level (LL) for Chinese White
Dolphin Monitoring
|
North Lantau Social Cluster |
|
NEL |
NWL |
|
Action Level |
(STG < 4.2) & (ANI < 15.5) |
(STG < 6.9) & (ANI < 31.3) |
Limit Level |
[(STG < 2.4) & (ANI < 8.9)] AND [(STG < 3.9) & (ANI < 17.9)] |
5.2.3. If exceedance(s) at these transects is/are recorded by the ET of the Contract or referred by the other ET under the HZMB project to the Contract, the ET of the Contract will carry out an investigation and findings will be reported in the monthly EM&A Report.
5.3 Monitoring Result
The dolphin survey results for all transects are reported in the monthly EM&A Reports prepared for Contract No. HY/2013/01.
6. ENVIRONMENTAL SITE INSPECTION AND AUDIT
6.1. Site Inspection
6.1.1. Site Inspections were carried out on a weekly basis to monitor the implementation of proper environmental pollution control mitigation measures for the project. During the reporting period, site inspections were carried out on 05, 12, 19 & 26 July 2018.
6.1.2. As confirmed by RSS on 16 January 2018, the landscape construction works including planting (Shrubs & Grass), installation of irrigation pipe and soiling (Sub & Top soil) for Contract No. HY/2013/02 were commended on 04 November 2017. The landscape inspections were conducted on 12 and 26 July 2018 on a bi-weekly basis during the weekly environmental site inspection. The weekly site inspection checklists including the landscape inspection items would be submitted to IEC for checking within the reporting period.
6.1.3. During the site inspections in July 2018, there was no conflict occurred regarding to the Landscape & Visual mitigation measures stated in Contract Specific EM&A Manual. The work site was found to be confined within site boundaries and grass-hydroseed was provided for bare soil surface and stock pile areas. Landscape & Visual mitigate measures during construction would be checked to ensure compliance with the intended aims of the measures.
6.1.4. Particular observations during the site inspections are described below:
05 July 2018
(a) Improper disposal of general refuse was obseved at Portion C. General refuse was collected at Portion C. The observation was closed on 12 July 2018.
(b) Chemical container without drip tray was observed at Portion C. Chemical container was removed at Portion C. The observation was closed on 12 July 2018.
12 July 2018
(a) Missing / Damaged water barrier was observed at Portion D. Damaged water barrier was replaced at Portion D. The observation was closed on 19 July 2018.
(b) Improper disposal of general refuse was observed at Portion D. General refuse was collected at Portion D. The observation was closed on 19 July 2018.
19 July 2018
(a) Oil stain was observed in stagnant pool at Portion WA3. Oil stain was cleared at Portion WA3. The observation was closed on 26 July 2018.
26 July 2018
(a) Improper disposal of general refuse was observed at Portion D. Follow-actions for outstanding observation will be inspected during the next site inspection.
6.2. Advice on the Solid and Liquid Waste Management Status
6.2.1. The Contractor registered as a chemical waste producer for the Contract. Sufficient numbers of receptacles were available for general refuse collection and sorting. The quantities of waste for disposal in this reporting period are summarized in Table 6.1 and Table 6.2 and monthly summary waste flow table is shown in Appendix E.
Table 6.1 Summary of Quantities of Inert C&D Materials
Type of Waste |
Quantity |
Hard Rock and Large Broken Concrete (Inert) (m3) |
0 |
Reused in this Contract (Inert) (m3) |
0 |
Reused in other Projects (Inert) (m3) |
0 |
Disposed as Public Fill (Inert) (m3) |
124 |
Imported Fill (Inert) (m3) |
0 |
Table 6.2 Summary of Quantities of C&D Materials
Type of Waste |
Quantity |
Recycled Metal (kg) |
0 |
Recycled Paper / Cardboard Packing (kg) |
920 |
Recycled Plastic (kg) |
0 |
Chemical Wastes (kg) |
0 |
General Refuses (m3) |
116 |
6.2.2. There was no excavated marine sediment generated in this reporting period. Since the disposal of excavated marine sediments has been completed with the last batch disposal on 30 August 2017 as confirmed by RSS, no excavated marine sediment was still remained and stored on site awaiting disposal during this reporting period under Contract No. HY/2013/02.
6.3. Environmental Licenses and Permits
6.3.1. The valid environmental licenses and permits during the reporting period are summarized in Appendix F.
6.4. Implementation Status of Environmental Mitigation Measures
6.4.1. In response to the site audit findings, the Contractor carried out corrective actions.
6.4.2. The Contractor waters 8 times per day on all exposed soil within the project site and associated works areas when construction activities are being undertaken.
6.4.3. As confirmed by RSS, the capital works were substantially completed on 28 March 2018. The establishment of landscape works with mitigation code G1, G2, G4, G6, G7 & G9 were conducted around the site while landscape works with mitigation code G5 was mainly conducted at Portion D. The Contractor was reminded to resolve the potential conflicts between the proposed landscape measures and any other works of the project. The implementation status of Landscape and Visual Mitigation Measures is presented in Appendix G.
6.4.4. The Contractor was reminded to provide well-maintained plant operated on-site and plant served regularly;
6.4.5. The Contractor was reminded to switch off vehicles and equipment while not in use;
6.4.6. The Contractor was reminded to schedule the construction works to minimize noise nuisance etc.
6.4.7. A summary of the implementation Schedule of Environmental Mitigation Measures (EMIS) is presented in Appendix G. Most of the necessary mitigation measures were implemented properly.
6.5. Summary of Exceedance of the Environmental Quality Performance Limit
6.5.1. Summary of Action and Limit Level exceedance of 1-hr TSP level and 24-hr TSP level at AMS6 shall be referred to the monthly EM&A report prepared by Contract No. HY/2011/03.
6.5.2. There was no Action and Limit Level exceedance of 1-hr TSP level and 24-hr TSP level recorded at station AMS7B by the Environmental Team of Contract No. HY/2013/01 during the reporting period.
6.5.3. There was no Action and Limit Level exceedance for noise recorded at station NMS2 and station NMS3B by the Environmental Team of Contract No. HY/2013/01 during the reporting period.
6.5.4. The monitoring results for the monitoring stations showed in Table 4.1 are reported in the monthly EM&A Report prepared for Contract No. HY/2013/01. During July 2018, there were 39 action level exceedances and 18 limit level exceedance of dissolved oxygen, 1 action level exceedance of turbidity and 6 action level exceedance of suspended solid. The following table summarized the number of exceedance on each sampling data.
Sampling Date |
No. of Exceedances |
|||||
DO |
Turbidity |
SS |
||||
Action |
Limit |
Action |
Limit |
Action |
Limit |
|
02/07/2018 |
6 |
0 |
0 |
0 |
0 |
0 |
04/07/2018 |
5 |
0 |
0 |
0 |
0 |
0 |
06/07/2018 |
8 |
5 |
0 |
0 |
0 |
0 |
09/07/2018 |
12 |
9 |
0 |
0 |
0 |
0 |
11/07/2018 |
2 |
0 |
1 |
0 |
0 |
0 |
13/07/2018 |
4 |
2 |
0 |
0 |
3 |
0 |
16/07/2018 |
2 |
2 |
0 |
0 |
2 |
0 |
27/07/2018 |
0 |
0 |
0 |
0 |
1 |
0 |
Total: |
39 |
18 |
1 |
0 |
6 |
0 |
6.5.5. Since the removal of temporary loading and unloading point by Contract No. HY/2013/02, which involved marine work, was completed on 10 September 2017 and the area was handed back to Reclamation Contractor with Contract No. HY/2010/02 on 11 September 2017 for subsequent seawall construction as confirmed by RSS, there was no marine works or barge of this Contract worked at HKBCF reclamation site near the sea area or area near the monitoring station under Contract No. HY/2013/02 during June 2018. Hence, specific investigation shall be referred to other ET’s report(s) under the HZMB Projects in which the respective contract(s) with remaining marine works on-going for the exceedances recorded in water quality monitoring during this reporting month. There was no Action and Limit Level exceedance recorded on other monitoring date at the monitoring stations showed at Table 4.1 by the Environmental Team of Contract No. HY/2013/01 during the reporting period.
6.5.6. Impact dolphin monitoring results at all transects are reported in the EM&A Reports prepared for Contract No. HY/2013/01.
6.6. Summary of Complaints, Notification of Summons and Successful Prosecution
6.6.1. Follow-up action to the complaint received by Highways Department on 13 June 2018 and referred to the ENPO on 22 June 2018. Then the ENPO forwarded the complaint by email to the R.E. (AECOM), the Contractor (China Harbour) and the ET (ETS-Testconsult Ltd.) of Contract No. HY/2013/02 at 10:42 on 25 June 2018. After received the details of the complaint from the ENPO on 25 June 2018, a related follow-up inspection was conducted by ET and the Contractor of Contract No. HY/2013/02 to investigate this event. The inspection was concentrated to check if there is any improper discharged by Contract No. HY/2013/02. After checked with the Contractor of Contract No. HY/2013/02, only Box Culvert A is within our site boundary. There was no any muddy water discharge observed during inspection on 25 June 2018. Besides, during weekly environmental site inspection on 27 June 2018, Box Culvert A was checked and inspected. No muddy water discharge was observed. Besides, the capital works were substantially completed on 28 March 2018 and no construction activities that would generate wastewater with high concentrations of suspended solid were conducted on 13 June 2018. Moreover, as discussed with the contractor, all the washing/de-silting/removal of grit works inside manholes has been completed before 30 April 2018 and no exposed earth ground was observed during the inspection. Hence, the complaint received on 13 June 2018 was found non-related to Contract No. HY/2013/02. The complaint investigation report (Log No. 019) was provided in Appendix J.
6.6.2. There were no notifications of summons or prosecutions received during the reporting period.
6.6.3. Statistics on environmental complaints, notifications of summons and successful prosecutions are summarized in Appendix H.
7.1 Construction Programme for the Coming Months
7.1.1 As confirmed by RSS, the capital works were substantially completed on 28 March 2018. Major construction activities for July 2018 as informed by the Contractor:
- Establishment work for Landscape
7.2 Environmental Site Inspection Schedule for the Coming Month
7.2.1 The tentative schedule for weekly site inspections for August 2018 is provided in Appendix I.
8.1 Conclusions
8.1.1 The site preparation work of the Contract was started on 25 July 2014 and the construction works of the Contract commenced on 24 November 2014.
8.1.2 Summary of Action and Limit Level exceedance of 1-hr TSP level and 24-hr TSP level at AMS6 shall be referred to the monthly EM&A report prepared by Contract No. HY/2011/03.
8.1.3 There was no Action and Limit Level exceedance of 1-hr TSP level and 24-hr TSP level recorded at station AMS7B by the Environmental Team of Contract No. HY/2013/01 during the reporting period.
8.1.4 There was no Action and Limit Level exceedance for noise recorded at station NMS2 and station NMS3B by the Environmental Team of Contract No. HY/2013/01 during the reporting period.
8.1.5 The monitoring results for the monitoring stations showed in Table 4.1 are reported in the monthly EM&A Report prepared for Contract No. HY/2013/01. During July 18, there were 39 action level exceedances and 18 limit level exceedance of dissolved oxygen, 1 action level exceedance of turbidity and 6 action level exceedance of suspended solid. The following table summarized the number of exceedance on each sampling data.
Sampling Date |
No. of Exceedances |
|||||
DO |
Turbidity |
SS |
||||
Action |
Limit |
Action |
Limit |
Action |
Limit |
|
02/07/2018 |
6 |
0 |
0 |
0 |
0 |
0 |
04/07/2018 |
5 |
0 |
0 |
0 |
0 |
0 |
06/07/2018 |
8 |
5 |
0 |
0 |
0 |
0 |
09/07/2018 |
12 |
9 |
0 |
0 |
0 |
0 |
11/07/2018 |
2 |
0 |
1 |
0 |
0 |
0 |
13/07/2018 |
4 |
2 |
0 |
0 |
3 |
0 |
16/07/2018 |
2 |
2 |
0 |
0 |
2 |
0 |
27/07/2018 |
0 |
0 |
0 |
0 |
1 |
0 |
Total: |
39 |
18 |
1 |
0 |
6 |
0 |
8.1.6 Since the removal of temporary loading and unloading point by Contract No. HY/2013/02, which involved marine work, was completed on 10 September 2017 and the area was handed back to Reclamation Contractor with Contract No. HY/2010/02 on 11 September 2017 for subsequent seawall construction as confirmed by RSS, there was no marine works or barge of this Contract worked at HKBCF reclamation site near the sea area or area near the monitoring station under Contract No. HY/2013/02 during July 2018. Hence, specific investigation shall be referred to other ET’s report(s) under the HZMB Projects in which the respective contract(s) with remaining marine works on-going for the exceedances recorded in water quality monitoring during this reporting month. There was no Action and Limit Level exceedance recorded on other monitoring date at the monitoring stations showed at Table 4.1 by the Environmental Team of Contract No. HY/2013/01 during the reporting period.
8.1.7 Impact dolphin monitoring results at all transects are reported in the EM&A Reports prepared for Contract No. HY/2013/01.
8.1.8 Follow-up action to the complaint received by Highways Department on 13 June 2018 and referred to the ENPO on 22 June 2018. Then the ENPO forwarded the complaint by email to the R.E. (AECOM), the Contractor (China Harbour) and the ET (ETS-Testconsult Ltd.) of Contract No. HY/2013/02 at 10:42 on 25 June 2018. After received the details of the complaint from the ENPO on 25 June 2018, a related follow-up inspection was conducted by ET and the Contractor of Contract No. HY/2013/02 to investigate this event. The inspection was concentrated to check if there is any improper discharged by Contract No. HY/2013/02. After checked with the Contractor of Contract No. HY/2013/02, only Box Culvert A is within our site boundary. There was no any muddy water discharge observed during inspection on 25 June 2018. Besides, during weekly environmental site inspection on 27 June 2018, Box Culvert A was checked and inspected. No muddy water discharge was observed. Besides, the capital works were substantially completed on 28 March 2018 and no construction activities that would generate wastewater with high concentrations of suspended solid were conducted on 13 June 2018. Moreover, as discussed with the contractor, all the washing/de-silting/removal of grit works inside manholes has been completed before 30 April 2018 and no exposed earth ground was observed during the inspection. Hence, the complaint received on 13 June 2018 was found non-related to Contract No. HY/2013/02. The complaint investigation report (Log No. 019) was provided in Appendix J.
8.1.9 There were no notifications of summons or prosecutions received during the reporting period.
- END OF REPORT -
