TABLE OF CONTENTS
Page |
|||
1 |
1-2 |
||
1.1 |
Basic
Project Information |
1 |
|
1.2 |
Project
Organization |
2 |
|
1.3 |
Construction Programme |
2 |
|
1.4 |
Construction Works
Undertaken During the Reporting Period |
2 |
|
|
|
|
|
2 |
3-6 |
||
2.1 |
Summary of EM&A Requirements |
3-4 |
|
2.2 |
Monitoring Requirements |
4 |
|
2.3 |
Action and Limit Levels |
4-6 |
|
2.4 |
Event
Action plans |
6 |
|
2.5 |
Mitigation Measures |
6 |
|
|
|
|
|
3 |
6-10 |
||
3.1 |
Air Quality Monitoring Result |
6 |
|
3.2 |
Noise Monitoring Results |
7 |
|
3.3 |
Water
Quality Monitoring
Results |
7-8 |
|
3.4 |
Dolphin Monitoring |
8 |
|
3.5 |
Implementation Status of
Environmental Mitigation Measures |
8-9 |
|
3.6 |
Advice on the
Solid and Liquid Waste Management Status |
9-10 |
|
3.7 |
Environmental
Licenses and Permits |
10 |
|
|
|
|
|
4 |
Summary of Exceedance,
Complaint, notification of summons and sucessful prosecution |
11 |
|
4.1 |
Summary of Exceedance of the
Environmental Quality Performance Limit |
11 |
|
4.2 |
Summary
of Complaints, Notification of Summons and Successful Prosecution |
11 |
|
|
|
|
|
5 |
12-13 |
||
5.1 |
Comments |
12 |
|
5.2 |
Recommendations |
12 |
|
5.3
|
Conclusions |
13 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
Figure 1 |
Air Quality and Noise Monitoring Stations for HKBCF |
|
|
Figure 2 |
Water Quality Monitoring Stations(construction phases) |
|
|
Figure 3 |
Dolphin Monitoring Transect Line and Layout Map |
|
|
|
|
|
|
Table |
|
Table 1.1 |
Contact
Information of Key Personnel |
Table 2.1 |
Air
Quality and Noise Monitoring Locations |
Table 2.2 |
Water
Quality Monitoring Stations(construction phases) |
Table 2.3 |
Action
and Limit Levels for 1-hour TSP |
Table 2.4 |
Action
and Limit Levels for 24-hour TSP |
Table 2.5 |
Action
and Limit Levels for Construction Noise |
Table 2.6 |
Action
and Limit Levels for Water Quality |
Table 2.7 |
Action
and Limit Levels for Chinese White Dolphin Monitoring ¡V Approach to Define
Action |
|
Level ( |
Table 2.8 |
Derived
Value of Action Level ( |
Table 3.1 |
Summary
of marine sediment disposed to dumping site via Contract No. HY/2013/03 |
|
|
APPENDICES |
|
Location of Works Areas |
|
Project Organization for Environmental
Works |
|
Construction Programme |
|
Event and Action Plan |
|
Waste Flow Table & Marine Sediment |
|
Environmental Licenses and Permits |
|
Implementation Schedule for
Environmental Mitigation Measures (EMIS) |
|
Statistics on Environmental Complaints, Notification of Summons and Successful Prosecutions |
|
Environmental Site Inspection Schedule |
|
Investigation
Report on Action or Limit Level Non-compliance |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
This Quarterly Environmental Monitoring and Audit (EM&A) Report is prepared for Contract HY/2013/02
Hong Kong-Zhuhai-Macao Bridge Hong Kong Boundary Crossing Facilities (HKBCF) ¡V
Infrastructure Works Stage I (Western Portion) (hereafter referred to as ¡§the
Contract¡¨) for the Highways Department of Hong Kong Special Administrative
Region (HKSAR). The Contract was awarded to China Harbour Engineering Co., Ltd.
(hereafter referred to as ¡§the Contractor¡¨) and ETS-Testconsult Limited was
appointed as the Environmental Team (ET) by the Contractor.
The Contract is part of
ETS-Testconsult Limited has been appointed by the
Contractor to implement the Environmental Monitoring & Audit (EM&A)
programme for the Contract in accordance with the Updated EM&A Manual for
HKBCF (Version 1.0) and provide environmental team services to the Contract.
This is the Fifth Quarterly Environmental
Monitoring and Audit (EM&A) Report for the Contract which summaries
findings of the EM&A works conducted during the reporting
period from 01 December 2015 to 29 February 2016.
Environmental Monitoring and Audit Progress
The EM&A programme was
undertaken in accordance with the Updated EM&A Manual for HKBCF (Version
1.0). It should be noted that the air quality and noise monitoring works for
the Contract are covered by Contract No. HY/2010/02 ¡§Hong Kong-Zhuhai-
The dates of environmental site
inspections during the reporting period are listed below:
Environmental Site Inspection
Date |
||
December 2015 |
January 2016 |
February 2016 |
02, 10, 18, 24 and 31 |
06, 15, 21 and 27 |
04, 12, 19 and 25 |
Breaches of Action and
Limit Levels
Summary
of Action and Limit Level exceedance of 1-hr TSP level and 24-hr TSP level at
AMS6 shall be referred to the monthly EM&A report prepared by Contract No.
HY/2011/03.
There was no
Action and Limit Level exceedance of 1-hr
TSP level and 24-hr TSP level recorded at station AMS
There was no
Action and Limit Level exceedance of 1-hr
TSP level and 24-hr TSP level recorded at station AMS
There was no
Action and Limit Level exceedance for
noise recorded at station NMS2 and station NMS3B by the
Environmental Team of Contract No. HY/2010/02 during the reporting period.
Since the marine construction works of
temporary loading and unloading point was carried out from 02 Dec 2015 to 30
Dec 2015, water quality monitoring and impact dolphin monitoring are required
from this reporting month.
For water quality monitoring, there
were three exceedances recorded during the reporting period. One Action Level exceedance of SS at IS(Mf)11 during mid-flood tide was recorded
on 28 Dec 2015 and one Action Level exceedance of SS and
one Limit Level exceedance of Turbidity on impact water quality
monitoring at station SR4(N)
during mid-flood tide recorded on 05 Feb 2016. After investigation, there was
concluded that the exceedances were not relevant to this Contract. There was no
Action and Limit Level exceedance recorded on other monitoring date
at the monitoring stations showed in Table 2.2 by the
Environmental Team of Contract No. HY/2010/02 during the reporting period. The Investigation Report No. 002
(including the causes of exceedance, action taken and recommendation for
mitigation) on Action or Limit Level Non-compliance is provided in Appendix J.
Impact dolphin monitoring results at all transects are reported in the
EM&A Report prepared for Contract No. HY/2010/02. One limit level
exceedance was recorded in the Monitoring Period (Dec 2015 ¡V Feb 2016). The
investigation is undergoing and investigation results is referred in quarterly
report (Dec 2015 ¡V Feb 2016) of Contract No. HY/2010/02.
Implementation of Environmental
Measures
Site
inspections were carried out on a weekly basis to monitor the implementation of
proper environmental pollution control and mitigation measures for the Project.
Potential environmental impacts due to the construction activities were
monitored and reviewed.
Complaint Log
There
was no complaint received in relation to the environmental impact during the reporting period.
Notifications of Summons and
Successful Prosecutions
There
were no notification of summon or prosecution received during the reporting period.
Reporting
Change
The air quality monitoring station AMS
The application for
variation of Environmental Permit (EP) for the HZMB HKBCF Project was made on 18 February 2016 and granted by EPD on 25 February 2016, and
the latest EP No. for the HZMB HKBCF Project is EP-353/2009/J.
1.1 Basic Project
Information
1.2 Project Organization
Table 1.1 Contact Information of Key Personnel
Party |
Position |
Name of Key
Staff |
Tel. No. |
Fax No. |
Engineer or Engineer¡¦s
Representative (AECOM Asia
Co. Ltd.) |
Resident Engineer |
Mr.
Fred Yeung |
63308293 |
31525116 |
Environmental Project Office / Independent Environmental Checker
(Ramboll Environ Hong Kong Limited)
|
Environmental Project Office Leader |
Mr. Y. H. Hui |
34652888 |
34652899 |
Independent Environmental Checker |
Mr. Raymond Dai |
34652888 |
34652899 |
|
Environmental Site Supervisor |
Mr. Ray Yan |
51818165 |
34652899 |
|
Contractor (China Harbour Engineering
Co., Ltd.) |
Environmental Officer |
Mr. Richard Ng |
59770593 |
39150300 |
Environmental Supervisor |
Ms. Joy Chan |
54005086 |
39150300 |
|
Environmental Supervisor |
Ms. Selena Yang |
55122662 |
39150300 |
|
Environmental
Team (ETS-Testconsult Ltd.) |
Environmental
Team Leader |
Mr
C. L. Lau |
2946
7791 |
2695
3944 |
1.3 Construction
Programme
1.4 Construction
Works Undertaken During the Reporting Period
¡± Bored piles works in Portion A1 & D;
¡±
Pier /
Abutment in Portion H & D & Pile Cap in Portion D;
¡±
Installation
of Pre-bored Socketted Steel H-Pile in Portion D.
¡± Formwork and falsework for bridge deck construction at Portion H;
¡± Temporary marine loading and unloading point for
segment delivery in Portion A1;
¡± UU Detection Works in Portion I;
¡± Pit excavation work and duct laying in Portion I; and
¡±
Marine sediment excavation activities from the
land-based works and corresponding disposal at the designated disposal sites.
2.1 Summary of
EM&A Requirements
The ET of the Contract or another ET of the HZMB project is required to
conduct dolphin monitoring at 23 transects as part of EM&A programme if
these transects are no longer covered under Contract No. HY/2010/02. The dolphin monitoring should adopt line-transect
vessel survey method. The survey follows pre-set and fixed transect lines in the
two areas defined by AFCD as: Northeast Lantau survey area; and
Table 2.1 Air Quality and Noise Monitoring Locations
Environmental Monitoring |
Identification No. |
Location Description |
Air Quality |
AMS6(1) |
Dragonair / CNAC (Group) Buidling |
AMS |
|
|
AMS7(1) (2) |
Hong Kong SkyCity Marriott Hotel |
|
Noise |
NMS2(3) |
|
NMS3B(3)(4) |
Site Boundary
of Site Office Area at Works Area WA2 |
Remarks:
(1) The ET of this Contract should
conduct impact air quality monitoring at the AMS listed in the table as part of
EM&A programme according to latest notification from ENPO when the monitoring
station(s) is/are no longer covered by another ET of the HZMB project.
(2) The air quality
monitoring location AMS
(3) ET of this Contract should conduct impact
noise monitoring at the NMS listed in the table as part of EM&A programme
according to latest notification from ENPO when the monitoring station(s)
is/are no longer covered by another ET of the HZMB project.
(4) The Action and Limit Levels for schools
will be applied for this alternative monitoring location.
Table 2.2 Water Quality Monitoring Stations (construction phases)
Station |
Description |
East |
North |
IS7
|
Impact
Station (Close to HKBCF construction site) |
812244 |
818777 |
IS10
|
Impact
Station (Close to HKBCF construction site) |
812577 |
820670 |
IS(Mf)11
|
Impact
Station (Close to HKBCF construction site) |
813562 |
820716 |
SR3
|
Sensitive
receivers (San Tau SSSI) |
810525 |
816456 |
SR4(N)
|
Sensitive
receivers (Tai Ho) |
814705 |
817859 |
SR5
|
Sensitive
receivers (Artificial Reef in NE Airport) |
811489 |
820455 |
SR6
|
Sensitive
receivers (Sha Chau and |
805837 |
821818 |
SR7
|
Sensitive
receivers (Tai Mo Do) |
814293 |
821431 |
SR |
Sensitive
receivers (Ma Wan FCZ)1 |
823741 |
823495 |
SR10B(N)[1] |
Sensitive
receivers (Ma Wan FCZ)2 |
823683 |
823187 |
CS(Mf)3
|
Control
Station |
809989 |
821117 |
CS(Mf)5
|
Control
Station |
817990 |
821129 |
CS4
|
Control
Station |
810025 |
824004 |
CS6
|
Control
Station |
817028 |
823992 |
CSA
[2] |
Control
Station |
818103 |
823064 |
Note:
[1]: Additional monitoring station for Ma Wan
FCZ.
[2]: Additional control monitoring station
for Ma Wan FCZ
Remarks:
The ET of this
Contract should conduct impact water quality monitoring at the WQMS listed in
the table as part of EM&A programme according to latest notification from
ENPO when the monitoring station(s) is/are no longer covered by another ET of
the HZMB project. The ET of the
Contract shall communicate and share the monitoring data to the ET(s) of other
works contracts if the water quality monitoring station(s) is/are as part of
EM&A programme.
2.2 Monitoring
Requirements
2.3 Action
and Limit Levels
Table 2.3 Action and Limit Levels for 1-hour TSP
Monitoring Station. |
Action Level,mg/m3 |
Limit Level,mg/m3 |
AMS6 ¡V Dragnair / SNAC (Group) Building
(HKIA) |
360 |
500 |
AMS |
370 |
500 |
AMS7 ¡V Hong Kong SkyCity Marriott Hotel |
370 |
500 |
Table 2.4 Action and Limit Levels for 24-hour TSP
Monitoring Station. |
Action Level,mg/m3 |
Limit Level,mg/m3 |
AMS6 ¡V Dragnair / SNAC (Group) Building
(HKIA) |
173 |
260 |
AMS |
183 |
260 |
AMS7 ¡V Hong Kong SkyCity Marriott Hotel |
183 |
260 |
Table 2.5 Action and Limit Levels for Construction
Noise
Parameter |
Action Level |
Limit Level |
07:00 ¡V 19:00 hours
on normal weekdays |
When one documented
complaint is received |
75 dB(A)* |
|
Notes:
If works are to be carried out during restricted hours, the conditions stipulated in the construction noise permit issued by the Noise Control Authority have to be followed.
* Reduce to 70
dB(A)
for schools and 65 dB(A) during school examination period.
2.3.5
The Action and Limit Levels for Water Quality are provided in Table 2.6
Table 2.6 Action and Limit Levels for Water Quality
Parameters |
Action |
Limit |
DO in mg/L
(Surface, Middle & Bottom) |
Surface and Middle
5.0 Bottom 4.7 |
Surface and Middle
4.2 (except 5 mg/L for FCZ) Bottom 3.6 |
SS in mg/L (depth-averaged) at
all monitoring stations and control stations |
23.5 and 120% of upstream control
station's SS at the same tide of the same day* |
34.4 and 130% of upstream control
station's SS at the same tide of the same day and 10mg/L for WSD Seawater
intakes* |
Turbidity in NTU (depth-averaged) |
27.5 and 120% of upstream
control station's turbidity at the
same tide of the same day* |
47.0 and 130% of upstream
control station's turbidity at the
same tide of the same day* |
* Remarks: Reference is made to EPD approval of
adjustment of water quality assessment criteria issued and became effective on
18 February 2013.
Notes: 1 "depth-averaged"
is calculated by taking the arithmetic means of reading of all three depths.
2 For
DO, non-compliance of the water quality limits occurs when monitoring result is
lower than the limits.
3 For turbidity, SS, non-compliance of the water
quality limits occurs when monitoring result is higher than the limits.
4 All
the figures given in the table are used for reference only and the EPD may amend
the figures whenever it is considered as necessary.
5 The
1%-ile of baseline data for dissolved oxygen (surface and middle) and dissolved
oxygen (bottom) are 4.2mg/L and 3.6mg/L respectively.
Table 2.7 Action and Limit Levels for Chinese White
Dolphin Monitoring ¡V Approach to Define Action Level (
|
|
|
NEL |
NWL |
|
Action Level |
(STG < 70% of baseline) & (ANI < 70% of baseline) |
(STG < 70% of baseline) & (ANI < 70% of baseline) |
Limit Level |
[(STG < 40% of baseline) & (ANI <
40% of baseline)] AND [ (STG < 40% of baseline) & (ANI
< 40% of baseline)] |
For North Lantau Social Cluster, action level will be trigger if either
NEL or NWL fall below the criteria; limit level will be triggered if both NEL
and NWL fall below the criteria.
Table 2.8 Derived Value of
Action Level (
White
Dolphin Monitoring
|
|
|
NEL |
NWL |
|
Action Level |
STG < 4.2) & (ANI < 15.5 ) |
(STG < 6.9) & (ANI < 31.3) |
Limit Level |
[(STG < 2.4) & (ANI < 8.9)] AND [(STG
< 3.9) & (ANI < 17.9)] |
The ET
of this Contract should conduct impact dolphin monitoring as part of EM&A
programme according to latest notification from ENPO when the monitoring transect(s) is/are no longer covered by
another ET of the HZMB project.
2.4 Event
Action Plans
2.5 Mitigation Measures
3 Environmental
Monitoring and Audit
3.1 Air
Quality Monitoring Results
3.2 Noise Monitoring Results
3.3 Water
Quality Monitoring Result
3.3.3 28 Dec 2015
One Action Level exceedance of SS at
IS(Mf)11 during mid-flood tide was recorded on 28 Dec 2015. After
investigation, there is no adequate information to conclude the recorded
exceedance is related to this Contract. The Investigation Report No. 002 (including
the causes of exceedance, action taken and recommendation for mitigation) on
Action or Limit Level Non-compliance is provided in Appendix J.
3.3.4 05 Feb 2016
There were
one Action
Level exceedance of SS and one Limit Level exceedance of Turbidity on impact
water quality monitoring at station SR4 (N) during mid-flood tide recorded on
05 February 2016. Exceedance was not due to operation of the works under
Contract No. HY/2013/02 because there
was no marine works or barge of this Contract worked at HKBCF reclamation site
near the sea area or area near the monitoring station SR4(N) from 02 to 05
February 2016 which was unlikely to generate suspended solids in the marine
water. Secondly, the SS and Turbidity exceedances were recorded during flood
tide in which the monitoring station SR4(N) is located at upstream of the works
area of this Contract. Therefore, it is unlikely that the SS and Turbidity
exceedances recorded at SR4(N) during mid-flood tide on 05 February 2016 was
contributed by the works under Contract No. HY/2013/02. The water quality
mitigation measures as mentioned in EM&A Manual and EP was fully
implemented in this Contract which including maintenance of the silt curtain on
a daily basis etc. After investigation, there was concluded that the
exceedances were not relevant to this Contract due to the above mentioned
reasons. The Investigation Report (including the causes of exceedance, action
taken and recommendation for mitigation) for Action or Limit Level
Non-compliance was prepared by the ET of Contract No. HY/2010/02 and detailed
in the monthly EM&A Report prepared for Contract No. HY/2010/02. There was
no Action and Limit Level exceedance on other monitoring date was recorded by
the Environmental Team of Contract No. HY/2010/02 during the reporting period.
3.4
Dolphin monitoring
Result
3.4.2
Impact dolphin monitoring
results at all transects are reported in the EM&A Report prepared for
Contract No. HY/2010/02. One limit level exceedance was recorded in the
Monitoring Period (Dec 2015 ¡V Feb 2016).
3.4.3
Regarding to the marine
construction work, the steel piles installation works was carried out at the
temporary loading and unloading point in Portion A1 during the December
2015. All the installation was within the silt curtains and there was no any
Chinese White Dolphin (CWD) was found within the Dolphin Exclusion Zone during
the reporting period.
3.4.4
The Vibratory piler was
used for the installation of Tubular Steel Piling. The Vibratory piler is a silence
piling equipment and the noise generated is anticipated to be minimal the
acoustic disturbance to CWD
3.4.5
The speed of the vessels
for the construction work was strictly controlled within 10 knots within the
working area. After checked the Contractor¡¦s
3.4.6
After investigation, there was concluded that the
exceedances were not relevant to this Contract due to the above mentioned
reasons. The Investigation Report (including the causes of exceedance, action
taken and recommendation for mitigation) for Action or Limit Level
Non-compliance was prepared by the ET of Contract No. HY/2010/02 and detailed
in the quarterly EM&A Report prepared for Contract No.
HY/2010/02.
3.5
Implementation of Environmental Measures
3.6 Advice on
the Solid and Liquid Waste Management Status
Table 3.1
Summary of marine sediment disposed
to dumping site via Contract No. HY/2013/03
Month/Year |
Quantity disposed (m3) |
January 2016 |
1272 |
February 2016 |
2816 |
Total = |
4088 |
3.7 Environmental
Licenses and Permits
4 Summary
of exceedance, complaint, notification of summons and successful prosecution
4.1 Summary
of Exceedance of the Environmental Quality Performance Limit
4.1.4
For water
quality monitoring, there were three exceedances recorded during the reporting
period. One Action Level
exceedance of SS at IS(Mf)11 during mid-flood
tide was recorded on 28 Dec 2015 and one Action Level
exceedance of SS and one Limit Level exceedance
of Turbidity on impact
water quality monitoring at station SR4(N)
during mid-flood tide recorded on 05 Feb 2016. After investigation, there was concluded that the exceedances were not relevant to this
Contract. There was no Action and Limit Level exceedance
recorded on other monitoring
date at the monitoring stations showed in Table 2.2 by
the Environmental Team of Contract No. HY/2010/02 during the reporting period. The Investigation Report No. 002 (including the causes of exceedance,
action taken and recommendation for mitigation) on Action or Limit Level
Non-compliance is provided in Appendix J.
4.1.5
Impact
dolphin monitoring results at all transects are reported in the EM&A Report
prepared for Contract No. HY/2010/02. One limit level exceedance was recorded
in the Monitoring Period (Dec 2015 ¡V Feb 2016). The investigation is undergoing
and the investigation result is referred to quarterly report (Dec 2015 ¡V Feb
2016) of Contract No. HY/2010/02.
4.2 Summary
of Complaints, Notification of Summons and Successful Prosecution
4.2.1
There was no complaint received in relation
to the environmental impact during the reporting
period.
5 Comments,
recommendations and conclusion
5.1 Comments
n
The Contractor was reminded to provide drip tray for the
chemical container;
n
The Contractor was reminded to dispose the general waste
properly;
n
The Contractor was reminded to store the C&D waste properly;
n
The Contractor was reminded to clean the oil stain;
n
The contractor was reminded to seal the
plastic barrier;
n
The Contractor was reminded to provide additional watering for the
breaking works; and
n
The Contractor was reminded to provide water spraying for the haul road
regularly to prevent fugitive dust emission.
5.2 Recommendations
5.3
Conclusions
5.3.2
Summary of Action and
Limit Level exceedance of 1-hr TSP level and 24-hr TSP level at AMS6 shall be
referred to the monthly EM&A report prepared by Contract No. HY/2011/03.
5.3.3
There was no
Action and Limit Level
exceedance of 1-hr TSP level and 24-hr TSP
level recorded at station AMS
5.3.4
There was no
Action and Limit Level
exceedance of noise recorded at
station NMS2 and station NMS3B by the Environmental Team of Contract No.
HY/2010/02 during the reporting period.
5.3.5
For water
quality monitoring, there were three exceedances recorded during the reporting
period. One Action Level
exceedance of SS at IS(Mf)11 during
mid-flood tide was recorded on 28 Dec 2015 and one Action Level
exceedance of SS and one Limit Level exceedance
of Turbidity on impact
water quality monitoring at station SR4(N)
during mid-flood tide recorded on 05 Feb 2016. After investigation, there was concluded that the exceedances were not relevant to this
Contract. There was no Action and Limit Level exceedance
recorded on other monitoring date
at the monitoring stations showed in Table 2.2 by
the Environmental Team of Contract No. HY/2010/02 during the reporting period. The Investigation Report No. 002 (including the causes of exceedance,
action taken and recommendation for mitigation) on Action or Limit Level
Non-compliance is provided in Appendix J.
5.3.6
Impact
dolphin monitoring results at all transects are reported in the EM&A Report
prepared for Contract No. HY/2010/02. One limit level exceedance was recorded
in the Monitoring Period (Dec 2015 ¡V Feb 2016). The investigation is undergoing
and investigation results is referred in quarterly report (Dec 2015 ¡V Feb 2016) of
Contract No. HY/2010/02.
5.3.7
Environmental
site inspections were carried out on 02, 10, 18, 24 and
31 December 2015, 06, 15, 21 and 27 January 2016 and 04, 12, 19 and 25
February 2016. Recommendations on remedial actions were given to
the Contractors for the deficiencies identified during the site inspections.
5.3.8
There was no complaint received in relation to the environmental
impact during the reporting period.
5.3.9
There was no notification of summons and successful prosecution was
received during the reporting period.
