TABLE OF
CONTENTS
Page |
|||
1 |
1-2 |
||
1.1 |
Basic Project Information |
1 |
|
1.2 |
Project Organization |
1 |
|
1.3 |
Construction Programme |
2 |
|
1.4 |
Construction
Works Undertaken During the Reporting Period |
2 |
|
|
|
|
|
2 |
3-6 |
||
2.1 |
Summary of EM&A Requirements |
3-4 |
|
2.2 |
Monitoring Requirements |
4 |
|
2.3 |
Action and Limit Levels |
4-6 |
|
2.4 |
Event Action plans |
6 |
|
2.5 |
Mitigation Measures |
6 |
|
|
|
|
|
3 |
7-10 |
||
3.1 |
Air Quality Monitoring Result |
7 |
|
3.2 |
Noise Monitoring Results |
7 |
|
3.3 |
Water Quality Monitoring Results |
7-8 |
|
3.4 |
Dolphin Monitoring |
8 |
|
3.5 |
Implementation Status of
Environmental Mitigation Measures |
8-9 |
|
3.6 |
Advice on the
Solid and Liquid Waste Management Status |
9-10 |
|
3.7 |
Environmental
Licenses and Permits |
10 |
|
|
|
|
|
4 |
Summary of Exceedance,
Complaint, notification of summons and sucessful prosecution |
11-13 |
|
4.1 |
Summary of Exceedance of the
Environmental Quality Performance Limit |
11 |
|
4.2 |
Summary
of Complaints, Notification of Summons and Successful Prosecution |
11-13 |
|
|
|
|
|
5 |
14-15 |
||
5.1 |
Comments |
14 |
|
5.2 |
Recommendations |
14 |
|
5.3
|
Conclusions |
14-15 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
Figure 1 |
Air Quality and Noise Monitoring Stations for HKBCF |
|
|
Figure 2 |
Water Quality Monitoring
Stations(construction phases) |
|
|
Figure 3 |
Dolphin Monitoring TransectLine and Layout Map |
|
|
|
|
|
|
TABLE |
|
Table 1.1 |
Contact Information of Key Personnel |
Table 2.1 |
Air Quality and Noise Monitoring Locations |
Table 2.2 |
Water Quality Monitoring Stations (construction phases) |
Table 2.3 |
Action and Limit Levels for 1-hour TSP |
Table 2.4 |
Action and Limit Levels for 24-hour TSP |
Table 2.5 |
Action and Limit Levels for Construction Noise |
Table 2.6 |
Action and Limit Levels for Water Quality |
Table 2.7 |
Action and Limit Levels for Chinese White Dolphin Monitoring ¡V
Approach to Define Action |
|
Level (AL) and Limit Level (LL) |
Table 2.8 |
Derived Value of Action Level (AL) and Limit Level (LL) for Chinese
White Dolphin Monitoring |
Table 3.1 |
Summary of marine sediment disposed to dumping site via Contract
No. HY/2013/03 |
APPENDIX |
|
Location of Works Areas |
|
Project Organization for Environmental Works |
|
Construction Programme |
|
Event and Action Plan |
|
Implementation
Schedule for Environmental Mitigation Measures(EMIS) |
|
Site Audit Findings and Corrective Actions |
|
Waste
Flow Table |
|
Environmental
Licenses and Permits |
|
Statistics
on Environmental Complaints, Notification of Summons and Successful
Prosecutions |
|
Investigation Reports on Action Level
or Limit Level Non-compliance |
|
Complaint Investigation Report |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
This QuarterlyEnvironmental Monitoring and Audit (EM&A) Report is prepared for Contract HY/2013/02
Hong Kong-Zhuhai-Macao Bridge Hong Kong Boundary Crossing Facilities (HKBCF) ¡V
Infrastructure Works Stage I (Western Portion) (hereafter referred to as ¡§the
Contract¡¨) for the Highways Department of Hong Kong Special Administrative
Region (HKSAR). The Contract was awarded to China Harbour Engineering Co., Ltd.
(hereafter referred to as ¡§the Contractor¡¨) and ETS-Testconsult Limited was
appointed as the Environmental Team (ET) by the Contractor.
The Contract is part of Hong Kong ¡V Zhuhai ¡V Macao
Bridge HKBCF which is a ¡§Designated Project¡¨, under Schedule 2 of the
Environmental Impact Assessment Ordinance (EIAO) (Cap 499) and Environmental
Impact Assessment (EIA) Report (Register No. AEIAR-145/2009) was prepared for
the Project. The current Environmental Permit (EP) No. EP-353/2009/K for HKBCF
was issued on 11 April 2016. These documents are available through the EIA
Ordinance Register. Site preparation works of the Contract was started on 25
July 2014 and the construction works of the Contract commenced on 24 November
2014.
ETS-Testconsult Limited has been appointed by the
Contractor to implement the Environmental Monitoring & Audit (EM&A)
programme for the Contract in accordance with the Updated EM&A Manual for
HKBCF (Version 1.0) and provide environmental team services to the Contract.
This is
the EleventhQuarterly Environmental Monitoring and Audit (EM&A) Report for the Contractwhich
summaries findings of the EM&A works conducted during the reporting
period from 01June
to 31 August2017.
Environmental Monitoring and Audit Progress
The EM&A programme was undertaken in
accordance with the Updated EM&A Manual for HKBCF (Version 1.0). It should
be noted that the air quality and noise monitoring works for the Contract are
covered by Contract No. HY/2010/02 ¡§Hong Kong-Zhuhai-Macao Bridge HKBCF ¡V
Reclamation Works¡¨ and Contract No. HY/2011/03 ¡§Hong Kong-Zhuhai-Macao Bridge
Hong Kong Link Road ¡V Section between Scenic Hill and HKBCF¡¨. The ET of the
Contract or another ET of the HZMB project is required to conduct impact air
quality monitoring at AMS6 and AMS7 andnoise monitoring at NMS2 and
NMS3B show in Figure 1, water
quality monitoring show in Figure 2
and dolphinmonitoring show in Figure 3as part of EM&A programme
if these monitoring stations are no longer covered under Contract No.
HY/2010/02 and HY/2011/03. However, this is subject to ENPO¡¦s final decision on
which ET should carry out the monitoring works at these stations.
The dates of environmental site inspections
during the reporting period are listed below:
Environmental Site Inspection Date |
||
June 2017 |
July 2017 |
August 2017 |
01,
08, 15,
22 and 29 |
06,
13, 20
and 27 |
03,
10, 17,
24 and 31 |
Breaches of Action and Limit
Levels
Summary
of Action and Limit Level exceedance of 1-hr TSP level and 24-hr TSP level at
AMS6 shall be referred to the monthly EM&A report prepared by Contract No.
HY/2011/03.
There was no Action and Limit Level exceedance
of 1-hr TSP level and 24-hr TSP level
recorded at station AMS7 by the Environmental Team of Contract No. HY/2010/02 during the reporting period.
There was no Action and Limit Level exceedance
for noise recorded at
station NMS2 and station NMS3B by the Environmental Team of Contract No.
HY/2010/02 during the reporting period.
For water quality monitoring,there
were twoaction level
exceedances of suspended
solid on impact water quality monitoring at
station SR3 during mid-ebb tide and IS7
during mid-flood tide recorded on 12 July 2017 and 14 July 2017 respectively. After investigation, there was concluded that the exceedances were not relevant to this Contract since there was no marine works or barge of this Contract worked at HKBCF
reclamation site near the sea area or area near the monitoring station SR3 and IS7 from 12 July 2017 to 14July
2017which was unlikely
to generate suspended solid to cause the suspended solid exceedances recorded at the monitoring station SR3 during mid-ebb tide and IS7 during mid-flood
tide recorded on 12 July 2017 and 14
July 2017 respectively.The Investigation Reports No. 017 and 018(including the causes of exceedance, action taken and recommendation for
mitigation) for Action or Limit Level Non-compliance were provided in AppendixJ.There was no Action and Limit Level exceedance recorded on other monitoring date at the
monitoring stationsshowed at Table 2.2by the Environmental
Team of Contract No. HY/2010/02 during the reporting period.
Impact dolphin monitoring results at all transects are reported in the
EM&A Report prepared for Contract No.HY/2010/02.
Implementation of Environmental Measures
Site inspections
were carried out on a weekly basis to monitor the implementation of proper
environmental pollution control and mitigation measures for the Project.
Potential environmental impacts due to the construction activities were
monitored and reviewed.
Complaint Log
There were two complaints received during the reporting period.
1. One complaint
was received by Environmental Protection Department on
02 June 2017 from a construction worker
and referred to the ENPO.
Then the ENPO forwarded the complaint by email to the R.E. (AECOM), the
Contractor (China Harbour) and the ET (ETS-Testconsult Ltd.) of Contract No.
HY/2013/02 at 13:23 on 06
June 2017. The complaint detail was "¦a½L¤u¤HX¥ý¥Í§ë¶D´ä¯]¿D¤j¾ô¤H¤u®q¥X¤J¹Ò®ÈÀ˦a½L¨S¦³Åx¤ô¡A¾ÉP¦a½L©P³ò§Gº¡ªd¹Ð¡A¥O¤u¤H°·±d¨ü®`¡An¨DÀô«O¸p¶i¦æ¬ðÀ»¸ò¶i¨µ¬d¤~¥iµo²{°ÝÃD¤În¨D¦^ÂСC"
The follow-up inspection for the above mentioned complaint on 02 June 2017 was performed by the ET of Contract No. HY/2013/02 on 08 June 2017. The complaint investigation report
(Log No. 013) was further issued by the ET of Contract No. HY/2013/02on 05 July
2017.
According to the site inspection between 14:30
to 15:30 on 08 June 2017, the worksite was
wetted with water near¥X¤J¹Ò®ÈÀ˦a½L. Besides,¥X¤J¹Ò®ÈÀ˦a½Lwas not managed by Contract No. HY/2013/02. Hence, the complaint was found non-related
to Contract No. HY/2013/02. The complaint investigation report (Log No.013)for the above mentioned
complaint on 02 June 2017was provided in Appendix K.
2. One complaint
was received by Environmental Protection Department on
05 June 2017 from a construction worker
and referred to the ENPO.
Then the ENPO forwarded the complaint by email to the R.E. (AECOM), the
Contractor (China Harbour) and the ET (ETS-Testconsult Ltd.) of Contract No.
HY/2013/02 at 13:24 on 06
June 2017. The complaint detail was "¦a½L¤u¤H§ë¶D´ä¯]¿D¤j¾ô¤H¤u®q¥X¤J¹Ò®ÈÀ˦a½L¨S¦³Åx¤ô¡A¾ÉP¦a½L©P³ò§Gº¡ªd¹Ð¡A¥O¤u¤H°·±d¨ü®`¡An¨DÀô«O¸p¸ò¶i¤Î¦^ÂСC"
The follow-up inspections for the above mentioned complaint on 05 June 2017 was performed by the ET of Contract No. HY/2013/02 on 08 June 2017. The complaint investigation report
(Log No. 014) was further issued by the ET of Contract No. HY/2013/02on 05 July
2017.
According to the site
inspection between 14:30 to 15:30 on 08 June 2017,
the worksite was wetted with water near¥X¤J¹Ò®ÈÀ˦a½L. Besides, ¥X¤J¹Ò®ÈÀ˦a½Lwas not managed by Contract No. HY/2013/02. Hence, the complaint was found non-related to Contract No. HY/2013/02.
The complaint
investigation report (Log No.014)for
the above mentioned complaint on 05 June 2017was provided
in Appendix K.
Notifications of Summons and Successful
Prosecutions
There were no
notification of summon or prosecution received during thereporting period.
Reporting Change
There were no reporting changes during the reporting period.
1.1
Basic Project Information
1.1.1
This QuarterlyEnvironmental
Monitoring and Audit (EM&A) Report is
prepared for Contract HY/2013/02 Hong Kong¡VZhuhai-Macao Bridge Hong Kong
Boundary Crossing Facilities (HKBCF) ¡V Infrastructure Works Stage I (Western
Portion) (hereafter referred to as ¡§the Contract¡¨) for the Highways Department
of Hong Kong Special Administrative Region (HKSAR). The Contract was awarded to
China Harbour Engineering Co., Ltd. (hereafter referred to as ¡§the Contractor¡¨)
and ETS-Testconsult Limited was appointed as the Environmental Team (ET) by the
Contractor.
1.1.2
The Contract is part of
Hong Kong ¡V Zhuhai ¡V Macao Bridge HKBCF which is a ¡§Designated Project¡¨, under
Schedule 2 of the Environmental Impact Assessment Ordinance (EIAO) (Cap 499)
and an Environmental Impact Assessment (EIA) Report (Register No.
AEIAR-145/2009) was prepared for the Project. The current Environmental Permit
(EP) No. EP-353/2009/K for HKBCF was issued on 11 April 2016. These documents
are available through the EIA Ordinance Register. Site preparation works of the
Contract started on 25 July 2014 and the construction works of the Contract
commenced on 24 November 2014. The works area of the Contract is shown in Appendix
A.
1.1.3
This is the Eleventh Quarterly Environmental Monitoring and Audit (EM&A) Report for the
Contract which summaries the audit findings of the EM&A programme during
the reporting period from 01June to 31August 2017.
1.2
Project Organization
1.2.1
The project
organisation structure and lines of communication with respect to the
on-siteenvironmental management structure is shown in Appendix B. The key personnel contact
names and numbers are summarized in Table
1.1.
Table 1.1Contact Information of Key Personnel
Party |
Position |
Name of Key Staff |
Tel. No. |
Fax No. |
Engineer or Engineer¡¦s Representative
(AECOM Asia Co. Ltd.) |
Resident Engineer |
Mr. Winston Wong |
6330 8293 |
3152 5116 |
Environmental Project Office / Independent Environmental Checker
(Ramboll Environ Hong Kong Limited)
|
Environmental Project Office Leader |
Mr. Y. H. Hui |
34652888 |
34652899 |
Independent Environmental Checker |
Mr. Raymond Dai |
3465 2888 |
3465 2899 |
|
Environmental Site Supervisor |
Mr. Ray Yan |
5181 8165 |
3465 2899 |
|
Contractor (China Harbour Engineering
Co., Ltd.) |
EnvironmentalOfficer |
Mr. Richard Ng |
5977 0593 |
3915 0300 |
EnvironmentalOfficer |
Mr. Paper Chan |
6486 8967 |
39150300 |
|
Environmental Supervisor |
Mr. Endy Tse |
5512 2662 |
39150300 |
|
Environmental
Team (ETS-Testconsult Ltd.) |
Environmental
Team Leader |
Mr. C. L. Lau |
2946
7791 |
2695
3944 |
|
1.3
Construction Programme
1.3.1
A copy of the Contractor¡¦s construction
programme is provided in Appendix C.
1.4
Construction Works Undertaken During the Reporting Period
1.4.1
A
summary of the construction activities undertaken during this reporting period is
shown below:
l
Road and Bituminous works
l
Storm, sewer
drainage and water main construction;
l
Retaining wall,
slop and earth works
l
Construction
of signs gantries, cable trench and ducting;
l
Demolition of temporary
loading and unloading point
(Marine-based activity);
l
Construction of bridge deck
in Portion D, A, E, C & F
2.1
Summary of EM&A Requirements
2.1.1 The monthly
EM&A programme was undertaken in accordance with the Updated EM&A
Manual for HKBCF (Version 1.0). It should be noted that the air quality and
noise monitoring works for the Contract are covered by Contract No. HY/2010/02
Hong Kong-Zhuhai-Macao Bridge HKBCF ¡V Reclamation Works and Contract No. HY/2011/03
Hong Kong-Zhuhai-Macao Bridge Hong Kong Link Road ¡V Section between Scenic Hill
and HKBCF. The ET of the Contract or another ET of the HZMB project is required
to conduct impact air quality monitoring at AMS6
and AMS7, noise monitoring at NMS2 and NMS3B
show at Figure 1 andTable 2.1,
water quality monitoring stations show at Figure
2 and Table 2.2 and
dolphinmonitoring show at Figure 3as part of
EM&A programme if these monitoring stations are no longer covered under
Contract No. HY/2010/02 and HY/2011/03. However, this is subject to ENPO¡¦s
final decision on which ET should carry out the monitoring works at these
stations.
The ET of the Contract or another ET of the HZMB
project is required to conduct dolphin monitoring at 24
transects as part of EM&A programme if these
transects are no longer covered under Contract No. HY/2010/02. The dolphin monitoring should adopt
line-transect vessel survey method. The survey follows pre-set and fixed
transect lines in the two areas defined by AFCD as: Northeast Lantau survey
area; and Northwest Lantau survey area.
Figure 3shows the co-ordinates for the transect lines and layout map.
2.1.2 A summary of air and
noise monitoring locations are presented in Table 2.1. The location of
air quality and noise monitoring stations are shown as in Figure 1.
Table 2.1Air Quality and Noise Monitoring Locations
Environmental Monitoring |
IdentificationNo. |
LocationDescription |
|
Air Quality |
AMS6(1) |
Dragonair / CNAC (Group)
Building |
|
AMS7(1)(2) |
Hong Kong SkyCity Marriott
Hotel |
||
Noise |
NMS2(3) |
Seaview Crescent |
|
NMS3B(3)(4) |
Site Boundary of Site Office Area at
Works Area WA2 |
||
Remarks: |
|
||
(1) The ET of this Contract should
conduct impact air quality monitoring at the AMS listed in the table as part
of EM&A programme according to latest notification from ENPO when the monitoring
station(s)is/are no longer covered by another ET of the HZMB project. |
|
||
(2) The
air quality monitoring location AMS |
|
||
(3) ET of this Contract should
conduct impact noise monitoring at the NMS listed in the table as part of
EM&A programme according to latest notification from ENPO when the
monitoring station(s) is/are no longer covered by another ET of the HZMB
project. |
|
||
(4) The Action and Limit Levels for
schools will be applied for this alternative monitoring location. |
|
||
2.1.3 The water monitoring works for the
Contract are covered by Contract No. HY/2010/02 Hong Kong-Zhuhai-Macao Bridge
HKBCF ¡V Reclamation Works. The ET of the Contract or another ET of the HZMB
project is required to conduct waterquality monitoring at twenty one stations (9 Impact Stations, 7 Sensitive Receiver
Stations and 5 Control/Far Field Stations). Table 2.2and Figure
2shows the locations
of water quality monitoring stations.
Table 2.2 Water Quality Monitoring
Stations (construction phases)
Station |
Description |
East |
North |
IS5 |
Impact
Station (Close to HKBCF construction site) |
811579 |
817106 |
IS(Mf)6 |
Impact
Station (Close to HKBCF construction site) |
812101 |
817873 |
IS7 |
Impact
Station (Close to HKBCF construction site) |
812244 |
818777 |
IS8 |
Impact
Station (Close to HKBCF construction site) |
814251 |
818412 |
IS(Mf)9 |
Impact
Station (Close to HKBCF construction site) |
813273 |
818850 |
IS10(N) |
Impact Station (Close to HKBCF
construction site) |
812942 |
820881 |
IS(Mf)11
|
Impact
Station (Close to HKBCF construction site) |
813562 |
820716 |
IS(Mf)16 |
Impact
Station (Close to HKBCF construction site) |
814328 |
819497 |
IS17 |
Impact Station
(Close to HKBCF construction site) |
814539 |
820391 |
SR3 |
Sensitive
receivers (San Tau SSSI) |
810525 |
816456 |
SR4(N) |
Sensitive
receivers (Tai Ho) |
814705 |
817859 |
SR5(N) |
Sensitive receiver (Artificial
Reef in NE Airport) |
812569 |
821475 |
SR6 |
Sensitive
receivers (Sha Chau and Lung Kwu Chau Marine Park) |
805837 |
821818 |
SR7 |
Sensitive
receivers (Tai Mo Do) |
814293 |
821431 |
SR10A[1] |
Sensitive
receivers (Ma Wan FCZ)1 |
823741 |
823495 |
SR10B(N)[1] |
Sensitive
receivers (Ma Wan FCZ)2 |
823683 |
823187 |
CS(Mf)3(N) |
Control Station |
808814 |
822355 |
CS(Mf)5 |
Control
Station |
817990 |
821129 |
CS4 |
Control
Station |
810025 |
824004 |
CS6 |
Control
Station |
817028 |
823992 |
CSA[2] |
Control
Station |
818103 |
823064 |
Note: |
|||
(1) Additional monitoring station for Ma Wan
FCZ. |
|||
(2)
Additional
control monitoring station for Ma Wan FCZ |
|||
Remarks: |
|||
The ET of this Contract should conduct impact water quality
monitoring at the WQMS listed in the table as part of EM&A programme
according to latest notification from ENPO when the monitoring station(s)
is/are no longer covered by another ET of the HZMB project. The ET of the Contract
shall communicate and share the monitoring data to the ET(s) of other works
contracts if the water quality monitoring station(s) is/are as part of
EM&A programme. |
2.1.4
The dolphin monitoring works for the Contract are covered by
Contract No. HY/2010/02 Hong Kong-Zhuhai-Macao Bridge HKBCF ¡V Reclamation
Works. Figure 3shown
the layout mapfor
the vessel-based
transect lines.
2.2
Monitoring Requirements
2.2.1
The monitoring requirements, monitoring
equipment, monitoring parameters, frequency and duration, monitoring
methodology, monitoring schedule, meteorological information are detailed in
the monthly EM&A Reports prepared for Contract Nos. HY/2010/02 and
HY/2011/03.
2.3
Action and
Limit Levels
2.3.1
TheAction and
Limit Levels for 1-hr TSP and 24-hr TSP are provided in Table 2.3 and Table
2.4respectively.
Table
2.3Action
and Limit Levels for 1-hour TSP
Monitoring Station |
Action Level,mg/m3 |
Limit Level,mg/m3 |
AMS6 ¡V Dragnair / SNAC
(Group) Building (HKIA) |
360 |
500 |
AMS7 ¡VHong Kong SkyCity Marriott Hotel |
370 |
500 |
Table 2.4Action and Limit Levels for 24-hour TSP
Monitoring Station |
Action Level, mg/m3 |
Limit Level,mg/m3 |
AMS6 ¡V Dragnair / SNAC (Group) Building (HKIA) |
173 |
260 |
AMS7 ¡VHong Kong
SkyCity Marriott Hotel |
183 |
260 |
2.3.2
If exceedance(s)
at these station(s) is/are recorded by the ET of the Contract or referred bythe
other ET under the HZMB project to the Contract, the ET of the Contract will
carry out an investigation and findings will be reported in the quarterly
EM&A Report.
2.3.3
The Action and Limit Levels for construction noise are provided in Table 2.5
Table
2.5Action and Limit Levels for Construction Noise
Parameter |
Action Level |
Limit Level |
||
07:00 ¡V 19:00 hours on normal weekdays |
When
one documented complaint is received |
75
dB(A)* |
||
Notes: |
|
|||
Ifworksaretobecarriedout duringrestrictedhours,theconditionsstipulatedintheconstruction noisepermitissuedbytheNoiseControlAuthorityhavetobefollowed. *Reduce to70dB(A) for schools and65 dB(A)duringschoolexaminationperiod. |
|
|||
2.3.4
If exceedance(s)
at these station(s) is/are recorded by the ET of the Contract or referred bythe
other ET under the HZMB project to the Contract, the ET of the Contract will
carryout an investigation and findings will be reported in the quarterly
EM&A Report.
2.3.5
The Action and Limit Levels for Water Quality are provided in Table 2.6
Table 2.6Action and Limit Levels
for Water Quality
Parameters |
Action |
Limit |
|
DO in mg/L (Surface,Middle & Bottom) |
Surface and Middle 5.0 Bottom 4.7 |
Surface and Middle 4.2(except 5 mg/L for FCZ) Bottom 3.6 |
|
SS in mg/L(depth-averaged) at all monitoring
stations andcontrol stations |
23.5 and 120% ofupstream control station's SS at
the same tide of thesame day* |
34.4 and 130% ofupstream control station'sSS at
the same tide of thesame day and 10mg/L forWSD Seawater intakes* |
|
Turbidity in NTU (depth-averaged) |
27.5 and 120% of upstream control
station'sturbidity at the same tide ofthe same day* |
47.0 and 130% of upstream control station's
turbidity at the same tide of the same day* |
|
*Remarks: |
Reference is made to EPD
approval of adjustment of water quality assessmentcriteria |
||
|
issued and became effective on 18 February 2013. |
||
Notes: |
1.
"depth-averaged" is calculated by taking the arithmetic
means of reading of all threedepths. |
||
|
2.
For DO, non-compliance of the water quality limits occurs when
monitoring result islower than the limits. |
||
|
3.
For turbidity, SS, non-compliance of the water quality limits occurs
when monitoringresult is higher than the limits. |
||
|
4.
All the figures given in the table are used for reference only and the
EPD mayamend the figures whenever it is considered as necessary. |
||
|
5.
The 1%-ile of baseline data for dissolved oxygen (surface and middle)
and dissolved oxygen (bottom) are 4.2mg/L and 3.6mg/L respectively. |
||
2.3.6 If exceedance(s) at these station(s) is/are recorded
by the ET of the Contract or referred bythe other ET under the HZMB project to
the Contract, the ET of the Contract will carryout an investigation and
findings will be reported in the quarterly EM&A Report.
2.3.7 The Action and Limit Levels for Chinese White Dolphin
Monitoring are provided in Table 2.7& Table 2.8
Table 2.7Action and Limit Levels
for Chinese White Dolphin Monitoring ¡V Approach to Define Action Level (AL) and
Limit Level (LL)
|
North Lantau Social Cluster |
|
NEL |
NWL |
|
Action Level |
(STG < 70% of baseline) & (ANI < 70% of baseline) |
(STG < 70% of baseline) & (ANI < 70% of baseline) |
Limit Level |
[(STG < 40% of baseline) & (ANI < 40%
of baseline)] AND [ (STG < 40% of baseline) & (ANI <
40% ofbaseline)] |
For North Lantau Social Cluster, action level will
be trigger if either NEL or NWL fall below thecriteria; limit level will be
triggered if both NEL and NWL fall below the criteria.
Table 2.8Derived Value of Action
Level (AL) and Limit Level (LL) for Chinese White Dolphin Monitoring
|
North Lantau Social Cluster |
|
NEL |
NWL |
|
Action Level |
(STG < 4.2) & (ANI < 15.5 ) |
(STG < 6.9) & (ANI < 31.3) |
Limit Level |
[(STG < 2.4) & (ANI < 8.9)] AND [(STG
< 3.9) & (ANI < 17.9)] |
The ET
of this Contract should conduct impact dolphin monitoringas part of EM&A
programme according to latest notification from ENPO when the monitoring transect(s)is/are no longer covered by
another ET of the HZMB project.
2.3.8
If exceedance(s)
at these transect(s) is/are recorded by the ET of the Contract or referred
bythe other ET under the HZMB project to the Contract, the ET of the Contract
will carryout an investigation and findings will be reported in the quarterly
EM&A Report.
2.4
Event Action
Plans
2.4.1
The event and
action plan is provided in Appendix D.
2.5
Mitigation
Measures
2.5.1
Environmental
mitigation measures for the Contract were recommended in the Approved EIA Report.
Appendix E lists the recommendedmitigation measures and the implementation status.
3
Environmental Monitoring and Audit
3.1
Air Quality Monitoring
Results
3.1.1 The monitoring results for AMS6 and AMS7
are reported in the monthly EM&A Reports(June 2017, July 2017 and August 2017)prepared for Contract Nos. HY/2011/03 and
HY/2010/02 respectively.
3.1.2 Summary of Action and Limit Level exceedance of 1-hr TSP level and 24-hr
TSP level at AMS6 shall be referred to the monthly EM&A report prepared by
Contract No. HY/2011/03.
3.1.3 There was no Action and Limit Level exceedance
of 1-hr TSP level and 24-hr TSP level
recorded at station AMS7 by the Environmental Team of Contract No. HY/2010/02 during the reporting period.
3.2
Noise
Monitoring Results
3.2.1 Themonitoring results for NMS2 and NMS3B were
reported in the monthly EM&A Reports(June 2017, July 2017 and August 2017) prepared by Contract No. HY/2010/02.
3.2.2 There was no exceedance of noise recorded at station NMS2 and
station NMS3B by the Environmental Team of Contract No. HY/2010/02 during the reporting period.
3.3
Water
Quality Monitoring Result
3.3.1 Themonitoring results for the monitoring stations showed in Table 2.2 are reported in the monthly
EM&A Reports (June
2017, July 2017 and August 2017)prepared for
Contract No. HY/2010/02. There were twoaction level exceedances of suspended solid on impact water
quality monitoring at station SR3 during
mid-ebb tide and IS7 during mid-flood tide recorded on 12 July 2017 and 14 July 2017 respectively.After investigation, there was concluded that the exceedances were not relevant to this Contract since there was no marine works or barge of this Contract worked at HKBCF
reclamation site near the sea area or area near the monitoring station SR3 and IS7 from 12 July 2017 to 14July
2017which was unlikely
to generate suspended solid to cause the suspended solid exceedances recorded at the monitoring station SR3 during mid-ebb tide and IS7 during mid-flood
tide recorded on 12 July 2017 and 14
July 2017 respectively.
3.3.2 There was no Action and Limit Level exceedance recorded on other monitoring date at the monitoring stationsshowed at Table 2.2by the Environmental Team of Contract No. HY/2010/02 during the reporting period.
3.3.3
Although the above mentioned exceedances were not relevant to this
Contract, the Contractor was reminded to ensure all construction activities
that generate wastewater with high concentrations of suspended solid (SS)
should be collected to sedimentation tanks or package treatment systems for
proper treatment prior to disposal. The Contractor was also reminded to ensure
that all silt removal facilities, channels and manholes shall be maintained and
any deposited silt and grit shall be removed regularly.
3.4
Dolphin monitoring Result
3.4.1
Impact dolphin
monitoring results at all transects were reported in the EM&A Report
prepared for Contract No. HY/2010/02. One limit level exceedance was recorded
in the monitoring period (June 2017 ¡V August 2017).
3.4.2
During this
reporting period, only one marine
based activity which is demolition of temporary loading and unloading
point workedby Contract No. HY/2013/02.The demolition of temporary loading and unloading point was started from
18 July 2017. The major marine based activity was the removal of marine piling
of temporary loading and unloading point. All marine based activities were carried out within the silt curtain and
no defect of silt curtain was recorded by Contract No. HY/2010/02 from 18 July 2017 to 31August 2017.
3.4.3
After checked the
Contractor¡¦s Marine Travel Route
record, there werefourteen trips of dry cargo barge recorded in June 2017and
no other vessel under Contract
No. HY/2013/02 in or out the HKBCF perimeter silt curtain
duringJuly 2017 and
August 2017. All trips of dry cargo barge recorded were restricted and followed the Regular Marine
Travel Routes Plan. The RMTRP training was
provided for the Captain since 21 July 2016 and allbarges recorded during the
reporting period were travelled in regular travel routes. No bargeexceeded the speed limit was recorded.
3.4.4
The exceedance is still under investigation
by Contract No. HY/2010/02. The Investigation Report (including the causes of
exceedance, action taken and recommendation for mitigation) for Action or Limit
Level Non-compliance will be prepared by the ET of Contract No. HY/2010/02 and
detailed in the quarterly EM&A Report prepared for Contract No. HY/2010/02. The implementation of
Regular Marine Travel Route Plan (RMTRP) for the above mentioned dry cargo barges of marine transportation undertaken by Contract
No. HY/2013/02 during the reporting period were checked by the ET. The Regular Marine
Travel Route Plan were prepared and given to the Caption to use in order to minimize
the chance ofvessel collision and the routes would not go through the dolphin
hotspot in BrothersIslands.
3.4.5
Although the exceedance was not relevant to
this Contract, the Contractor was reminded to ensure provision of ongoing
maintenance to the silt curtains and to carry out maintenance work by the
Contractor of Contract No. HY/2010/02 once defects were found.
3.5
Implementation
of Environmental Measures
3.5.1
In response to the site
audit findings, the Contractor carried out corrective actions.Details of site
audit findings and the corrective actions during the reporting period are
presented in Appendix F.
3.5.2
The Contractor waters 8
times per day on all exposed soil within the project site and associated works
areas when construction activities are being undertaken.
3.5.3
The Contractor
wasreminded to provide well-maintained plant operated on-site and
plant served regularly;
3.5.4
TheContractor wasreminded
to switch off vehicles and equipment while not in use;
3.5.5
TheContractor wasreminded
to schedule the construction works to minimize noise nuisance etc.
3.5.6
The
Contractor was reminded to ensure all construction activities that generate
wastewater with high concentrations of suspended solid (SS) should be collected
to sedimentation tanks or package treatment systems for proper treatment prior
to disposal.
3.5.7 The
implementation status of Regular Marine Travel Route Plan (RMTRP) was checked
by ET. Training material of Regular Marine Travel Route Plan was prepared and
given to relevant staff. Those records were kept properly. Since the marine
delivery of precast segments was completed in July 2017, no
marine traffic records and geographical plots of the vessels tracks to
demonstrate the conformance of the vessel to the proposed route in July 2017
and August 2017 would be provided to ER, ETL, IEC/ENPO for checking within the
month of August 2017 and September 2017. The marine traffic records and
geographical plots of all the vessels tracks to demonstrate the conformance of
the vessel to the proposed route in June2017 would be provided to ER, ETL,
IEC/ENPO for checking within the month of July 2017.The implementation
status of silt curtain deployment and dolphin watching plan was also checked by
ET that silt curtain was deployed and MMO was provided by Contract No.
HY/2010/02.
3.5.8
The tool box training of
dolphin was carried out in Dec 2015. According to the action plan and
communication flow chart of dolphin instruction, if any dolphin intruded BCF
perimeter silt curtain, ETL should be informed. There was no notification
received on any dolphin intrusion the site area of Contract No. HY/2013/02 during
the reporting period.
3.5.9
A summary of the Implementation
Schedule of Environmental Mitigation Measures (EMIS) is presented in Appendix
E. Most of the necessary mitigation measures were implemented properly.
3.6
Advice on the Solid and Liquid Waste Management
Status
3.6.1
TheContractor registered
as a chemical waste producer for the Contract. Sufficient numbers of
receptacles were available for general refuse collection and sorting.
3.6.2
1432 m3 of excavated marine sediment was
generated in this reporting period. The excavated marine sediment was stored
properly on site during this reporting period until further instruction by the
Engineer. The disposal of excavated sediment as per EP-353/2009/K to be
implemented subject to confirmation.
3.6.3
The summary of waste flow
table is detailed in Appendix G.
3.6.4
Disposal of Marine Sediment
3.6.4.1
For
the marine sediment disposal, after the acceptance of the review of the
approved Sediment Quality Report (SQR) for this Project under EPD letter dated
19 August 2015, an approval to dispose the marine sediment extracted from bored
piling for this Project was then approved under memo from Secretary, Marine
Fill Committee of CEDD dated 20 August 2015 for the disposal of marine sediment
extracted from bored piling works. The disposal sites allocated to this Project
are the Mud Pit CMP2 of the Confined Marine Sediment Disposal Facility to the
South of The Brothers (or at the East of Sha Chau). As advised by CEDD in the
memo dated 19 February 2016, from 00:00 on 22 March 2016 onward, the disposal
space at CMP2 of the South of The Brothers is closed and all disposal of
contaminated sediment is to be carried out at CMP Vd to the East of Sha Chau
(ESC). As a practical means, the disposal operation is managed by one
contractor who is also responsible for applying dumping permit and its
subsequent extension applications from EPD. Contract No. HY/2013/03 hasbeen
assigned to coordinate and arrange for disposal of extracted marine sediment
from Contract Nos. HY/2013/02, HY/2013/03 and HY/2013/04.
3.6.4.2
For
the dumping arrangement, the barge for disposal of marine sediment will moor at
the temporary loading and unloading at the east shore of the HKBCF Island,
which has been being used by contractor Contract No. HY/2010/02 for reclamation
activities. In terms of safety consideration and to avoid mixing of sediment
between contracts, each dumping date will be allocated to one Contract. The
quantity of marine sediment disposed on each date is from one Contract.
3.6.4.3
During
dumping, HY/2013/02 is responsible for transporting the marine sediment from
his site area to the barge by Land transportation. The estimated quantity of
marine sediment in each truck is confirmed by Resident Site Staff of each
Contract. The trip tickets for transportation and disposal of marine sediment
are collected and checked. Contract No. HY/2013/03 as the dumping permit holder
is responsible for reporting to EPD the quantity disposed of as the condition
stipulated in the dumping permit.
3.6.5
Marine
sediment extracted from bored piling in this Contract
was disposed to allocated dumping site via Contract No. HY/2013/
Table 3.1Summary of marine sediment disposed to dumping site via
Contract No. HY/2013/03
Month/Year |
Quantity disposed (m3) |
January 2016 |
1272 |
February 2016 |
2816 |
March 2016 |
600 |
April 2016 |
5128 |
May 2016 |
0 |
June 2016 |
1200 |
July 2016 |
728 |
August 2016 |
1784 |
September 2016 |
2328 |
October 2016 |
1096 |
November 2016 |
0 |
December 2016 |
1568 |
January 2017 |
0 |
February 2017 |
88 |
March 2017 |
0 |
April 2017 |
624 |
May 2017 |
0 |
June 2017 |
1432 |
July 2017 |
0 |
August 2017 |
0 |
Total = |
20664 |
3.6.6 The Contractor shall ensure no
spilling and overflowing of materials during loading / unloading /
transportation is allowed.
3.6.7 The Contractor was reminded that chemical waste
containers should be properly treated and stored temporarily in designated
chemical waste storage area on site in accordance with the Code of Practice on
the Packing, Labelling and Storage of Chemical Waste.
3.7
Environmental Licenses and Permits
3.7.1 The valid environmental licenses and permits during
the reporting period are summarized in Appendix H.
4
Summary of exceedance, complaint, notification of
summons and successful prosecution
4.1
Summary of Exceedance of
the Environmental Quality Performance Limit
4.1.1 Summary of Action and Limit Level exceedance of 1-hr TSP level and 24-hr
TSP level at AMS6 shall be referred to the monthly EM&A report prepared by
Contract No. HY/2011/03.
4.1.2 There was no Action and Limit Level exceedance
of 1-hr TSP level and 24-hr TSP level
recorded at station AMS7 by the Environmental Team of Contract No. HY/2010/02 during the reporting period.
4.1.3 There was no Action and Limit Level exceedance
of noise recorded at
station NMS2 and station NMS3B by the Environmental Team of Contract No.
HY/2010/02 during the reporting period.
4.1.4 For water quality monitoring,there
were twoaction level
exceedances of suspended
solid on impact water quality monitoring at
station SR3 during mid-ebb tide and IS7
during mid-flood tide recorded on 12 July 2017 and 14 July 2017 respectively. After investigation, there was concluded that the exceedances were not relevant to this Contract since there was no marine works or barge of this Contract worked at HKBCF
reclamation site near the sea area or area near the monitoring station SR3 and IS7 from 12 July 2017 to 14July
2017which was unlikely
to generate suspended solid to cause the suspended solid exceedances recorded at the monitoring station SR3 during mid-ebb tide and IS7 during mid-flood
tide recorded on 12 July 2017 and 14
July 2017 respectively.The Investigation Reports No. 017 and 018(including the causes of exceedance, action taken and recommendation for
mitigation) for Action or Limit Level Non-compliance were provided in AppendixJ.There was no Action and Limit Level exceedance recorded on other monitoring date at the
monitoring stationsshowed at Table 2.2by the
Environmental Team of Contract No. HY/2010/02 during the reporting period.
4.1.5 Impact dolphin monitoring results at all transects
are reported in the EM&A Report prepared for Contract No.HY/2010/02.
4.2
Summary of Complaints,
Notification of Summons and Successful Prosecution
4.2.1
There were two complaints received
during the reporting period.
1. One complaint
was received by Environmental Protection Department on
02 June 2017 from a construction worker
and referred to the ENPO.
Then the ENPO forwarded the complaint by email to the R.E. (AECOM), the
Contractor (China Harbour) and the ET (ETS-Testconsult Ltd.) of Contract No.
HY/2013/02 at 13:23 on 06
June 2017. The complaint detail was "¦a½L¤u¤HX¥ý¥Í§ë¶D´ä¯]¿D¤j¾ô¤H¤u®q¥X¤J¹Ò®ÈÀ˦a½L¨S¦³Åx¤ô¡A¾ÉP¦a½L©P³ò§Gº¡ªd¹Ð¡A¥O¤u¤H°·±d¨ü®`¡An¨DÀô«O¸p¶i¦æ¬ðÀ»¸ò¶i¨µ¬d¤~¥iµo²{°ÝÃD¤În¨D¦^ÂСC"
4.2.2 The follow-up inspection for the above mentioned complaint on 02 June 2017 was performed by the ET of Contract No. HY/2013/02 on 08 June 2017. The complaint investigation report
(Log No. 013) was further issued by the ET of Contract No. HY/2013/02on 05 July
2017.
4.2.3
According to the site
inspection between 14:30 to 15:30 on 08 June 2017,
the worksite was wetted with water near¥X¤J¹Ò®ÈÀ˦a½L. Besides,¥X¤J¹Ò®ÈÀ˦a½Lwas not managed by Contract No.
HY/2013/02. Hence, the complaint was found non-related to Contract No. HY/2013/02.
The complaint investigation report (Log No.013)for the above mentioned complaint on 02 June 2017was provided in Appendix K.
2.
One complaint was received by Environmental Protection Department on 05 June 2017 from a construction worker and referred to the ENPO.
Then the ENPO forwarded the complaint by email to the R.E. (AECOM), the
Contractor (China Harbour) and the ET (ETS-Testconsult Ltd.) of Contract No.
HY/2013/02 at 13:24 on 06 June 2017.
The complaint detail was "¦a½L¤u¤H§ë¶D´ä¯]¿D¤j¾ô¤H¤u®q¥X¤J¹Ò®ÈÀ˦a½L¨S¦³Åx¤ô¡A¾ÉP¦a½L©P³ò§Gº¡ªd¹Ð¡A¥O¤u¤H°·±d¨ü®`¡An¨DÀô«O¸p¸ò¶i¤Î¦^ÂСC"
4.2.4 The follow-up inspections for the above
mentioned complaint on 05 June 2017 was performed by the ET of Contract No. HY/2013/02
on 08 June 2017. The complaint investigation report (Log No.
014) was further issued by the ET of Contract No. HY/2013/02on 05 July 2017.
4.2.5 According to the site inspection between 14:30 to 15:30 on 08 June 2017,
the worksite was wetted with water near¥X¤J¹Ò®ÈÀ˦a½L. Besides, ¥X¤J¹Ò®ÈÀ˦a½Lwas not managed by Contract No. HY/2013/02. Hence, the complaint was found non-related to
Contract No. HY/2013/02. The complaint investigation report (Log No.014)for the above mentioned
complaint on 05 June 2017was provided in Appendix K.
4.2.6
Although the complaints were
non-related to Contract No. HY/2013/02, the Contractor of Contract No.
HY/2013/02 was reminded to provide appropriate mitigation measures such as:
1.
Wet the worksites with water regularly;
2.
Keep the watering record for inspection;
3.
Cover the dusty materials with impervious sheeting;
4.
Spray water during demolition activities;
4.2.7
There were no notifications of summons
or prosecutions received during thereporting period.
4.2.8
Statistics
on environmentalcomplaints, notifications of summons and successful
prosecutions are summarized in Appendix I.
5
Comments, recommendations and conclusion
5.1
Comments
5.1.1
According to the environmental site inspection undertaken during the
reporting period, the following recommendations were provided:
l The
Contractor was reminded to cover the cement stock by impervious sheet;
l The
Contractor was remindedto collect the general refuse properly;
l The
Contractor was remindedtosort the C & D materials and general
refuse;
l The
Contractor was reminded to provide drip tray for the chemical
containers;
l The
Contractor was reminded to treat the muddy water properly before discharge;
l The
Contractor was reminded to switch off the equipment while not in use;
l The
Contractor was reminded to clear the stagnant water pool;
l The
Contractor was reminded to provide appropriate
NRMM label for the machines;
5.1.2 A summary of the Implementation Schedule of
Environmental Mitigation Measures (EMIS) is presented in Appendix E.
Most of the necessary mitigation measures were implemented properly.
5.2
Recommendations
5.2.1 With implementation of
the recommended environmental mitigation measures, the contract¡¦s environmental
impacts were considered environmentally acceptable. The weekly environmental
site inspections ensured that all the environmental mitigation measures
recommended were effectively implemented.
5.2.2 The recommended
environmental mitigation measures, as included in the EM&A programme,
effectively minimize the potential environmental impacts from the Contract.
Also, the EM&A programme effectively monitored the environmental impacts
from the construction activities and ensure the proper implementation of
mitigation measures. No particular recommendation was advised for the
improvement of the programme.
5.3
Conclusions
5.3.1
The site preparation work of the Contract was started on 25 July 2014 and
the construction works of the Contract commenced on 24 November 2014. This is
the Eleventh Quarterly EM&A Report which summaries findings of the EM&A
work during the reporting period from 01 June 2017 to 31 August 2017.
5.3.2
Summary of Action and
Limit Level exceedance of 1-hr TSP level and 24-hr TSP level at AMS6 shall be
referred to the monthly EM&A report prepared by Contract No. HY/2011/03.
5.3.3
There was no
Action and Limit Level
exceedance of 1-hr TSP level and 24-hr TSP
level recorded at station AMS7 by the Environmental Team of Contract
No. HY/2010/02 during the reporting period.
5.3.4
There was no
Action and Limit Level
exceedance of noise recorded at
station NMS2 and station NMS3B by the Environmental Team of Contract No.
HY/2010/02 during the reporting period.
5.3.5
There were twoaction level exceedances of suspended solid on impact water
quality monitoring at station SR3 during
mid-ebb tide and IS7 during mid-flood tide recorded on 12 July 2017 and 14 July 2017 respectively. After investigation, there was concluded that the exceedances were not relevant to this Contract since there was no marine works or barge of this Contract worked at HKBCF
reclamation site near the sea area or area near the monitoring station SR3 and IS7 from 12 July 2017 to 14July
2017which was unlikely
to generate suspended solid to cause the suspended solid exceedances recorded at the monitoring station SR3 during mid-ebb tide and IS7 during mid-flood
tide recorded on 12 July 2017 and 14
July 2017 respectively.The Investigation Reports No. 017 and 018(including the causes of exceedance, action taken and recommendation for
mitigation) for Action or Limit Level Non-compliance were provided in AppendixJ.There was no Action and Limit Level exceedance recorded on other monitoring date at the
monitoring stationsshowed at Table 2.2by the
Environmental Team of Contract No. HY/2010/02 during the reporting period.
5.3.6
Impact
dolphin monitoring results at all transects are reported in the EM&A Report
prepared for Contract No.HY/2010/02.
5.3.7
Environmental site inspections were carried out on 01, 08, 15, 22and29
June 2017, 06, 13, 20 and27July
2017 and 03, 10, 17, 24
and31August 2017. Recommendations on remedial actions were given to the Contractors for
the deficiencies identified during the site inspections.
5.3.8
There were two complaints received in relation to the environmental impact during thereporting period. The complaints were found non-related to Contract No. HY/2013/02. The
complaint investigation reports (Log No. 013 and 014) were provided in Appendix K.
5.3.9
There was no notification of summons and
successful prosecution received during the reporting period.
- END OF REPORT -
