TABLE
OF CONTENTS
|
||
1 |
1-2 |
|
1.1 |
Basic Project
Information |
1 |
1.2 |
Project Organization |
2 |
1.3 |
Construction Programme |
2 |
1.4 |
Construction Works Undertaken During
the Reporting Period |
2 |
|
|
|
2 |
3-4 |
|
2.1 |
Monitoring Locations |
3 |
2.2 |
Monitoring Requirements |
3 |
2.3 |
Monitoring Results |
4 |
|
|
|
3 |
5 |
|
3.1 |
Monitoring Locations |
5 |
3.2 |
Monitoring Requirements |
5 |
3.3 |
Monitoring Results |
5 |
|
|
|
4
|
6-7 |
|
4.1 |
Monitoring Locations |
6 |
4.2 |
Monitoring Requirements |
6-7 |
4.3 |
Monitoring Results
|
7 |
|
|
|
5
|
8 |
|
5.1 |
Monitoring Locations |
8 |
5.2 |
Monitoring Requirements |
8 |
5.3 |
Monitoring Results
|
8 |
|
|
|
6 |
9-13 |
|
6.1 |
Site Inspection |
9 |
6.2 |
Advice on the Solid and
Liquid Waste Management Status |
9-10 |
6.3 |
Environmental Licenses and Permits |
10 |
6.4 |
Implementation
Status of Environmental Mitigation Measures |
10-11 |
6.5 |
Summary of
Exceedance of the Environmental Quality Performance Limit |
11 |
6.6 |
Summary of
Complaints, Notification of Summons and Successful Prosecution |
11-13 |
|
|
|
7 |
13 |
|
7.1 |
Construction
Programme for the Coming Months |
13 |
7.2 |
Environmental Site Inspection Schedule
for the Coming Month |
13 |
|
|
|
8 |
13-14 |
|
8.1 |
Conclusions |
13-14 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
||||||
Figure 1 |
Air Quality and Noise Monitoring Stations for HKBCF |
|
||||
Figure 2 |
Water Quality Monitoring Stations (construction phases) |
|
||||
Figure 3 |
Dolphin
Monitoring Transect Line and Layout Map |
|
||||
|
|
|
||||
|
|
|
||||
|
|
|
||||
Table |
|
|
||||
Table 1.1 |
Contact Information of Key Personnel |
|
||||
Table 2.1 |
Air Quality Monitoring Locations |
|
||||
Table 2.2 |
Action and Limit Levels for 1-hour TSP |
|
||||
Table 2.3 |
Action and Limit Levels for 24-hour TSP |
|
||||
Table 3.1 |
Construction Noise Monitoring Locations |
|
||||
Table 3.2 |
Action and Limit Levels for Construction Noise |
|
||||
Table 4.1 |
Water Quality Monitoring Stations (construction phases) |
|
||||
Table 4.2 |
Action and Limit Levels for Water Quality |
|
||||
Table |
Action and Limit Levels for Chinese White Dolphin Monitoring ¡V
Approach to Define Action Level ( |
|
||||
Table 5.1b |
Action and Limit Levels for Chinese White Dolphin Monitoring - |
|
||||
Table 6.1 |
Summary of marine sediment disposed to dumping site via Contract No.
HY/2013/03 |
|
||||
Table 7.1 |
Construction Activities for coming month |
|
||||
|
|
|
||||
|
|
|
||||
|
|
|
||||
APPENDICES |
|
|||||
Location of Works Areas |
|
|||||
Project Organization for Environmental Works |
|
|||||
Construction Programme |
|
|||||
Event and Action Plan |
|
|||||
Monthly Summery of Waste Flow Table & Monthly Summery of Marine
Sediment |
|
|||||
Environmental Licenses and Permits |
|
|||||
Implementation Schedule for Environmental Mitigation Measures (EMIS) |
|
|||||
Statistics on Environmental Complaints, Notification of Summons and
Successful Prosecutions |
|
|||||
Environmental Site Inspection Schedule |
|
|||||
Complaint
Investigation Report |
|
|||||
|
|
|
||||
|
|
|
|
|||
|
|
|
|
|||
|
|
This Monthly Environmental
Monitoring and Audit (EM&A) Report is
prepared for Contract HY/2013/02 ¡§Hong Kong¡VZhuhai-Macao Bridge Hong Kong
Boundary Crossing Facilities (HKBCF) ¡V Infrastructure Works Stage I (Western
Portion)¡¨ (hereafter referred to as ¡§the Contract¡¨) for the Highways Department
of Hong Kong Special Administrative Region (HKSAR). The Contract was awarded to
China Harbour Engineering Co., Ltd. (hereafter referred to as ¡§the Contractor¡¨)
and ETS-Testconsult Limited was appointed as the Environmental Team (ET) by the
Contractor.
The Contract is part of Hong Kong¡VZhuhai¡VMacao
Bridge HKBCF which is a ¡§Designated Project¡¨, under Schedule 2 of the
Environmental Impact Assessment Ordinance (EIAO) (Cap 499) and Environmental
Impact Assessment (EIA) Report (Register No. AEIAR-145/2009) was prepared for
the Project. The current Environmental Permit (EP) No.
EP-353/2009/K for HKBCF was issued on 11 April 2016. These documents are
available through the EIA Ordinance Register. Site preparation works of the
Contract was started on 25 July 2014 and the construction works of the Contract
commenced on 24 November 2014.
ETS-Testconsult Limited has been appointed by
the Contractor to implement the Environmental Monitoring & Audit (EM&A)
programme for the Contract in accordance with the Updated EM&A Manual for
HKBCF (Version 1.0) and provide environmental team services to the Contract.
This is the Twenty-fifth Monthly Environmental
Monitoring and Audit (EM&A) Report for the Contract which summaries
findings of the EM&A works conducted during the reporting
period from 01 December 2016 to 31 December 2016.
Site Activities
As
informed by the Contractor, site
activities were carried out in
this reporting month:
¡±
Bored piles works in Portion C
& F;
¡±
Pier / Abutment in Portion C
& F;
¡±
Pile Cap in Portion C & F;
¡±
Pre-bored H-pile for sign
gantries in Portion D;
¡±
Storm drain and water main
construction;
¡±
Retaining wall, slop and earth
works;
¡±
Footing construction of
directional signs, cable trench and ducting;
¡±
Marine
Delivery of precast segment &
Construction of bridge deck in Portion D, A, E, C & F
¡±
Marine sediment excavation activities from the land-based works and corresponding disposal at the designated disposal sites.
Environmental Monitoring and Audit Progress
The monthly EM&A programme was
undertaken in accordance with the Updated EM&A Manual for HKBCF (Version
1.0). It should be noted that the air quality and noise monitoring works for
the Contract are covered by Contract No. HY/2010/02 ¡§Hong Kong-Zhuhai-
Environmental Site Inspection:
01, 09, 15,
22 & 29 December 2016
Breaches
of Action and Limit Levels
Summary of
Action and Limit Level exceedance of 1-hr TSP level and 24-hr TSP level at AMS6
shall be referred to the monthly EM&A report prepared by Contract No.
HY/2011/03.
There was no Action and Limit Level exceedance
of 1-hr TSP level and 24-hr TSP level
recorded at station AMS7 by the Environmental Team of Contract No. HY/2010/02 during the reporting period.
There was no Action and Limit Level exceedance
for noise recorded at
station NMS2 and station NMS3B by the Environmental Team of Contract No.
HY/2010/02 during the reporting period.
There was one Action Level exceedances of SS on
impact water quality monitoring at station IS(Mf)9 during mid-flood tide recorded on 14 December 2016. After investigation, there was concluded that the exceedance was not
relevant to this Contract since there was no marine works or barge of this
Contract worked at HKBCF reclamation site near the sea area or area near the
monitoring station IS(Mf)9 from 01 December 2016 to the water quality monitoring period at 07:51 on
14 December 2016 which was unlikely to generate suspended solids in the marine
water. Therefore, it is unlikely that the SS exceedance recorded at IS(Mf)9 during mid-flood
tide on 14 December 2016 was contributed by the works under Contract No.
HY/2013/02. There was no
Action and Limit Level
exceedance recorded on other monitoring
date at the monitoring stations showed at Table 4.1 by
the Environmental Team of Contract No. HY/2010/02 during the reporting period.
Impact
dolphin monitoring results at all transects are reported in the EM&A Report
prepared for Contract No. HY/2010/02.
Complaint Log
There
were four complaints received during the reporting period.
1.
One complaint was received by EPD from
public on 01 December 2016 and was forwarded by EPD to the HYD and ENPO and
then to the R.E. (AECOM) on 01 December 2016.Then the R.E. (AECOM) forwarded
the complaint by email to the Contractor (
2.
One complaint was received by Contract No.
HY/2010/02 referred by the Government¡¦s Hotline (1823) on 02 December 2016 and
was forwarded by ENPO to the R.E. (AECOM), the Contractor (
3.
One complaint was received by EPD on 13 December
2016 and referred by EPD to the ENPO on 14 December 2016. Then the ENPO
forwarded the complaint by email to the R.E. (AECOM), the Contractor (
4.
One complaint was received by Highways Department and
referred by Highways Department to Contract No. HY/2010/02 on 28 December 2016.
Then the ENPO forwarded the complaint by email to the R.E. (AECOM), the
Contractor (
The
follow-up inspections for the above mentioned complaints on 01, 02 13 December
2016 were performed by the ET of Contract No. HY/2013/02 on 02
and 15 December 2016. The complaint investigation reports
(Log No. 006, 007 and 008) were issued by the ET of Contract No. HY/2013/02 and
verified by the IEC/ENPO on 14, 16 and 19 December 2016. The follow-up
inspection for the above mentioned complaint on 28 December 2016 was performed
by the ET of Contract No. HY/2013/02 on 29 December
2016. The complaint investigation report (Log No. 009) was issued by the ET
of Contract No. HY/2013/02 on 31 December 2016 which is still under review with
the IEC/ENPO and will be followed in the EM&A Report of January
2017.
According to the investigation, after checked
for the Contract No. HY/2013/02, no mud/slurry was observed around the East
Coast Road site entrance during the site inspection and audit on 01 December
2016, no stone debris and mud/slurry were observed around the East Coast Road
site entrance according to the Contractor and RE¡¦s site checking on 02 December
2016 and the construction works of this Contract during the past month was
carried out from 08:00 up to 23:00 and no any works and PME operation were
undertaken at night-time after 23:00 until 13
December 2016 by Contract No.
HY/2013/02. The complaints were found non-related to
Contract No. HY/2013/02. The complaint investigation reports (Log No. 006, 007 and 008) for the above mentioned
complaints on 01, 02 13 December 2016 were
provided in Appendix J.
Notifications of Summons and Successful
Prosecutions
There were no
notifications of summons or prosecutions received during the reporting period.
Reporting Change
There were no
reporting changes during the reporting period.
Future
Key Issues
The future key
issues to be undertaken in the upcoming month are as follows:
¡±
Pier / Abutment in Portion C
& F;
¡±
Pile Cap in Portion C & F;
¡±
Pre-bored H-pile for sign
gantries in Portion C
& F;
¡±
Storm drain and water main
construction;
¡±
Retaining wall, slop and earth
works
¡±
Footing construction of
directional signs, cable trench and ducting;
¡±
Delivery of precast segment
& Construction of bridge deck in Portion D, A, E, C & F
¡±
Marine sediment excavation activities from the land-based works and corresponding disposal at the designated disposal sites.
1.
INTRODUCTION
1.1.
Basic Project Information
1.1.1.
This Monthly Environmental
Monitoring and Audit (EM&A) Report is
prepared for Contract HY/2013/02 ¡§Hong Kong¡VZhuhai-Macao Bridge Hong Kong
Boundary Crossing Facilities (HKBCF) ¡V Infrastructure Works Stage I (Western
Portion)¡¨ (hereafter referred to as ¡§the Contract¡¨) for the Highways Department
of Hong Kong Special Administrative Region (HKSAR). The Contract was awarded to
China Harbour Engineering Co., Ltd. (hereafter referred to as ¡§the Contractor¡¨)
and ETS-Testconsult Limited was appointed as the Environmental Team (ET) by the
Contractor.
1.1.2.
The Contract is part of
Hong Kong¡VZhuhai¡VMacao Bridge HKBCF which is a ¡§Designated Project¡¨, under
Schedule 2 of the Environmental Impact Assessment Ordinance (EIAO) (Cap 499)
and Environmental Impact Assessment (EIA) Report (Register No. AEIAR-145/2009)
was prepared for the Project. The current Environmental Permit (EP) No. EP-353/2009/K for HKBCF was issued on 11 April 2016.
These documents are available through the EIA Ordinance Register. Site
preparation works of the Contract started on 25 July 2014 and the construction
works of the Contract commenced on 24 November 2014. The works area of the
Contract is shown in Appendix A.
1.1.3.
The proposed works under this
Contract comprise the following:
¡±
Construction of the viaducts
and roads at the western portion of Hong Kong Boundary Crossing Facilities
(HKBCF) mainly for connection with the Hong Kong¡VZhuhai¡VMacao Bridge (HZMB), Hong Kong Link Road (HKLR), Hong Kong International
Airport (HKIA) and the Tuen Mun-Chek Lap Kok Link (TM-CLKL);
¡±
Construction of the road modification at the SkyCity Interchange
at
¡±
Construction of associated street lighting, street
furniture, road marking, road signage, drainage, sewerage, fresh water and
flushing water supply, irrigation, landscape, electrical and mechanical
(E&M), utilities and services works;
¡±
Provisioning of civil engineering works and power supply
installation for the Traffic Control and Surveillance System TCSS;
¡±
Other works in accordance with the
Contract.
1.1.4.
This is the Twenty-fifth Monthly Environmental Monitoring and
Audit (EM&A) Report for the Contract which summaries the audit findings of
the EM&A programme during the reporting period from 01 December
2016 to 31
December 2016.
1.2.
Project Organization
1.2.1.
The project organization structure and
lines of communication with respect to the on-site environmental management
structure is shown in Appendix B.
The key personnel contact names and numbers are summarized in Table 1.1.
Table 1.1 Contact Information of Key Personnel
Party |
Position |
Name of Key Staff |
Tel. No. |
Fax No. |
Engineer or Engineer¡¦s
Representative (AECOM Asia Co. Ltd.) |
Resident
Engineer |
Mr. Dominic Mow |
6274
0909 |
315205116 |
Environmental Project Office
/ Independent Environmental Checker (Ramboll Environ Hong Kong
Limited) |
Environmental
Project Office Leader |
Mr. Y. H. Hui |
3465
2888 |
3465
2899 |
Independent
Environmental Checker |
Mr.
Raymond Dai |
3465
2888 |
3465
2899 |
|
Environmental
Site Supervisor |
Mr.
Ray Yan |
5181
8165 |
3465
2899 |
|
Contractor (China
Harbour Engineering Co., Ltd.) |
Environmental
Officer |
Mr.
Richard Ng |
5977
0593 |
3915
0300 |
Assistant
Environmental Officer |
Mr.
Paper Chan |
6486
8967 |
3915
0300 |
|
Environmental
Supervisor |
Mr.
Endy Tse |
5512
2662 |
3915
0300 |
|
Environmental Team (ETS-Testconsult Ltd.) |
Environmental Team Leader |
Mr. C. L. Lau |
2946 7791 |
2695 3944 |
1.3 Construction Programme
1.3.1 A
copy of the Contractor¡¦s construction programme is provided in Appendix C.
1.4 Construction Works Undertaken
During the Reporting Period
1.4.1
A summary of the
construction activities undertaken during this reporting period is shown below:
¡±
Bored piles works in Portion C
& F;
¡±
Pier / Abutment in Portion C
& F;
¡±
Pile Cap in Portion C & F;
¡±
Pre-bored H-pile for sign
gantries in Portion D;
¡±
Storm drain and water main
construction;
¡±
Retaining wall, slop and earth
works;
¡±
Footing construction of
directional signs, cable trench and ducting;
¡±
Marine
Delivery of precast segment &
Construction of bridge deck in Portion D, A, E, C & F
¡±
Marine sediment excavation activities from the land-based works and corresponding disposal
at the designated disposal
sites.
2.1 Monitoring
Locations
2.1.1 The air
quality monitoring works for the Contract are covered by Contract No.
HY/2010/02 Hong Kong-Zhuhai-
Table 2.1 Air Quality Monitoring Locations
Identification No. |
Location Description |
AMS6(1) |
Dragonair / CNAC (Group) Building |
AMS7(1) (2) |
Hong Kong SkyCity Marriott Hotel |
Remarks: |
(1)
The ET of this Contract should conduct impact air quality
monitoring at the AMS listed in the table as part of EM&A programme according
to latest notification from ENPO when the monitoring station(s) is/are no
longer covered by another ET of the HZMB project. |
(2)
The air quality monitoring location
AMS7A was relocated back to the original monitoring location AMS7 of
the updated EM&A Manual started from January 2016. |
2.2 Monitoring
Requirements
2.2.1 The monitoring
requirements, monitoring equipment, monitoring parameters, frequency and
duration, monitoring methodology, monitoring schedule, meteorological
information are detailed in the monthly EM&A Reports prepared for Contract
Nos. HY/2010/02 and HY/2011/03.
2.2.2 The Action and Limit Levels for 1-hr TSP and 24-hr TSP are
provided in Table 2.2 and Table 2.3 respectively. The Action and
Limit Levels of AMS7 are as same as its original levels and AMS7A.
Table 2.2 Action and Limit Levels for 1-hour TSP
Monitoring Station |
Action Level,mg/m3 |
Limit Level,mg/m3 |
AMS6 ¡V Dragnair / SNAC (Group) Building (HKIA) |
360 |
500 |
AMS7 ¡V Hong Kong SkyCity Marriott Hotel |
370 |
500 |
Table 2.3 Action and Limit Levels for 24-hour TSP
Monitoring Station |
Action Level,mg/m3 |
Limit Level,mg/m3 |
AMS6 ¡V Dragnair / SNAC (Group) Building (HKIA) |
173 |
260 |
AMS7 ¡V Hong Kong SkyCity Marriott Hotel |
183 |
260 |
2.2.3 The event and action plan is provided in Appendix D.
2.2.4 If exceedance(s) at these stations is/are recorded by the ET of the
Contract or referred by the other ET under the HZMB project to the Contract,
the ET of the Contract will carry out an investigation and findings will be
reported in the monthly EM&A Report.
2.3 Monitoring
Results
2.3.1 The monitoring results for AMS6 and AMS7 are reported in the monthly
EM&A Reports prepared for Contract Nos. HY/2011/03 and HY/2010/02
respectively.
2.3.2 Summary of
Action and Limit Level exceedance of 1-hr TSP level and 24-hr TSP level at AMS6
shall be referred to the monthly EM&A report prepared by Contract No.
HY/2011/03.
2.3.3 There was no Action and Limit Level exceedance
of 1-hr TSP level and 24-hr TSP level
recorded at station AMS7 by the Environmental Team of Contract No. HY/2010/02 during the reporting period.
3.1 Monitoring Locations
3.1.1 The noise
monitoring works for the Contract are covered by Contract No. HY/2010/02 Hong
Kong-Zhuhai-
Table 3.1 Construction Noise Monitoring Locations
Identification No. |
Location Description |
|
NMS2(1) |
Sea |
|
NMS3B(1) (2) |
Site Boundary of
Site Office Area at Works Area WA2 |
|
Remarks: |
||
(1)
The ET of this Contract should conduct impact noise monitoring
at the NMS listed in the table as part of EM&A programme according to
latest notification from ENPO when the monitoring station(s) is/are no longer
covered by another ET of the HZMB project. |
||
(2)
The Action and Limit Levels for schools will be applied for this
alternative monitoring location. |
3.2 Monitoring
Requirements
3.2.1 The monitoring requirements, monitoring equipment, monitoring
parameters, frequency and duration, monitoring methodology, monitoring
schedule, meteorological information are detailed in the monthly EM&A
Reports prepared for Contract No. HY/2010/02.
3.2.2 The Action and Limit Levels for construction noise are provided in Table 3.2
Table 3.2 Action and Limit Levels for Construction Noise
Parameter |
Action Level |
Limit Level |
|
07:00 ¡V 19:00 hours on normal weekdays |
When one documented complaint is received |
75 dB(A)* |
|
Notes: |
|
||
If works are to be carried out during restricted hours, the conditions stipulated in the construction noise permit issued by the Noise Control Authority have to be followed. |
|
||
* Reduce
to 70
dB(A) for schools and 65 dB(A) during school examination period. |
|
||
3.2.3 The event and action plan is provided in Appendix
D.
3.2.4 If exceedance(s) at these stations is/are recorded by
the ET of the Contract or referred by the other ET under the HZMB project to
the Contract, the ET of the Contract will carry out an investigation and
findings will be reported in the monthly EM&A Report.
3.3 Monitoring
Results
3.3.1
The monitoring
results for NMS2 and NMS3B are reported in the monthly EM&A Reports
prepared for Contract No. HY/2010/02.
There was no exceedance for noise recorded
at station NMS2 and station NMS3B by the Environmental Team of Contract No.
HY/2010/02 during the reporting period.
4.1
Monitoring
Locations
The water monitoring works for the Contract are
covered by Contract No. HY/2010/02 Hong Kong-Zhuhai-
Table 4.1 Water Quality Monitoring
Stations (construction phases)
Station |
Description |
East |
North |
|
IS5 |
Impact Station (Close to HKBCF
construction site) |
811579 |
817106 |
|
IS(Mf)6 |
Impact Station (Close to HKBCF
construction site) |
812101 |
817873 |
|
IS7 |
Impact Station (Close to HKBCF
construction site) |
812244 |
818777 |
|
IS8 |
Impact Station (Close to HKBCF
construction site) |
814251 |
818412 |
|
IS(Mf)9 |
Impact Station (Close to HKBCF
construction site) |
813273 |
818850 |
|
IS10 |
Impact Station (Close to HKBCF
construction site) |
812577 |
820670 |
|
IS(Mf)11 |
Impact Station (Close to HKBCF
construction site) |
813562 |
820716 |
|
IS(Mf)16 |
Impact Station (Close to HKBCF
construction site) |
814328 |
819497 |
|
IS17 |
Impact Station (Close to HKBCF
construction site) |
814539 |
820391 |
|
SR3 |
Sensitive receivers (San Tau SSSI) |
810525 |
816456 |
|
SR4(N) |
Sensitive receivers (Tai Ho) |
814705 |
817859 |
|
SR5 |
Sensitive receivers (Artificial Reef in
NE Airport) |
811489 |
820455 |
|
SR6 |
Sensitive receivers (Sha Chau and |
805837 |
821818 |
|
SR7 |
Sensitive receivers (Tai Mo Do) |
814293 |
821431 |
|
SR10A [1] |
Sensitive receivers (Ma Wan FCZ)1 |
823741 |
823495 |
|
SR10B(N)[1] |
Sensitive receivers (Ma Wan FCZ)2 |
823683 |
823187 |
|
CS(Mf)3 |
Control Station |
809989 |
821117 |
|
CS(Mf)5 |
Control Station |
817990 |
821129 |
|
CS4 |
Control Station |
810025 |
824004 |
|
CS6 |
Control Station |
817028 |
823992 |
|
CSA [2] |
Control Station |
818103 |
823064 |
|
Note: |
|
|||
(1)
Additional
monitoring station for Ma Wan FCZ. |
|
|||
(2)
Additional
control monitoring station for Ma Wan FCZ |
|
|||
Remarks: |
|
|||
The ET of
this Contract should conduct impact water quality monitoring at the WQMS
listed in the table as part of EM&A programme according to latest
notification from ENPO when the monitoring station(s) is/are no longer
covered by another ET of the HZMB project. The ET of the Contract shall communicate and share the monitoring
data to the ET(s) of other works contracts if the water quality monitoring
station(s) is/are as part of EM&A programme. |
|
|||
4.2
Monitoring
Requirements
The
monitoring requirements, monitoring equipment, monitoring parameters, frequency
and duration, monitoring methodology, monitoring schedule, meteorological
information are detailed in the monthly EM&A Reports prepared for Contract
No. HY/2010/02.
4.2.1
The event and
action plan is provided in Appendix D.
4.2.2
The Action and Limit Levels for Water Quality are provided in Table 4.2
Table 4.2 Action and Limit Levels
for Water Quality
|
Parameters |
Action |
Limit |
|
|
DO in mg/L (Surface, Middle & Bottom) |
Surface and Middle 5.0 Bottom 4.7 |
Surface and Middle 4.2 (except 5 mg/L for FCZ) Bottom 3.6 |
|
|
SS in mg/L (depth-averaged) at all monitoring stations and control stations |
23.5 and 120% of upstream control station's SS at the same tide of the
same day* |
34.4 and 130% of upstream control station's SS at the same tide of the
same day and 10mg/L for WSD Seawater intakes* |
|
|
Turbidity in NTU (depth-averaged) |
27.5 and 120% of upstream control station's turbidity at the same tide
of the same day* |
47.0 and 130% of upstream control station's turbidity at the same tide
of the same day* |
|
* Remarks: Reference is made to EPD approval of adjustment of water
quality assessment criteria issued and became effective on 18 February 2013. |
|
|||
Notes: 1. "depth-averaged" is
calculated by taking the arithmetic means of reading of all three depths. |
|
|||
2. For DO, non-compliance of the water quality
limits occurs when monitoring result is lower than the limits. |
|
|||
3. For turbidity, SS, non-compliance of the water quality limits occurs
when monitoring result is higher than the limits. |
|
|||
4. All the figures given in the table are used for
reference only and the EPD may amend the figures whenever it is considered as
necessary. |
|
|||
5. The 1%-ile of baseline data for dissolved oxygen
(surface and middle) and dissolved oxygen (bottom) are 4.2mg/L and 3.6mg/L
respectively. |
|
|||
4.2.3 If
exceedance(s) at these stations is/are recorded by the ET of the Contract or
referred by the other ET under the HZMB project to the Contract, the ET of the
Contract will carry out an investigation and findings will be reported in the
monthly EM&A Report.
4.3
Monitoring Result
4.3.1
The monitoring
results for the monitoring stations showed in Table 4.1 are reported in
the monthly EM&A Report prepared for Contract No. HY/2010/02. There was one
Action
Level exceedance of Suspended Solids on impact water quality monitoring at
station IS(Mf)9 during mid-flood tide recorded on 14 December 2016.
4.3.2
Exceedance
was not due to operation of the works under Contract No. HY/2013/02 because there was no marine works or barge of this
Contract worked at HKBCF reclamation site near the sea area or area near the
monitoring station IS(Mf)9 from 01 December 2016 to the water quality
monitoring period at 07:51 on 14 December 2016 which was unlikely to generate
suspended solids in the marine water. Therefore, it is unlikely that the SS
exceedance recorded at IS(Mf)9 during mid-flood tide on 14 December 2016
was contributed by the works under Contract No. HY/2013/02. The water quality
mitigation measures as mentioned in EM&A Manual and EP was fully
implemented in this Contract which including maintenance of the silt curtain on
a daily basis etc. Hence, the exceedance was considered as non-Project related.
4.3.3
After
investigation, there was concluded that the exceedance was not relevant to this
Contract due to the above mentioned reasons. The Investigation Report
(including the causes of exceedance, action taken and recommendation for
mitigation) for Action or Limit Level Non-compliance was prepared by the ET of
Contract No. HY/2010/02 and detailed in the monthly EM&A Report prepared
for Contract No. HY/2010/02. There was no Action and Limit Level exceedance
recorded on other monitoring date at the monitoring
stations showed in Table 4.1 by the Environmental Team of Contract No.
HY/2010/02 during the reporting period.
4.3.4
Although the exceedance was not relevant to this
Contract, the Contractor was reminded to ensure that the maintenance of
perimeter silt curtains with respect to the work boundary of this Contract
carried out by the Contractor of Contract
No. HY/2010/02 are maintained properly.
5 DOLPHIN MONITORING
5.1 Monitoring Locations
The dolphin monitoring
works for the Contract are covered by Contract No. HY/2010/02 Hong Kong-Zhuhai-
Remarks:
The ET
of this Contract should conduct impact dolphin monitoring as part of EM&A
programme according to latest notification from ENPO when the monitoring
transect(s) is/are no longer covered by another ET of the HZMB project.
5.2 Monitoring
Requirements
The
monitoring requirements, monitoring equipment, monitoring parameters, frequency
and duration, monitoring methodology, monitoring schedule, meteorological
information are detailed in the monthly EM&A Reports prepared for Contract
Nos. HY/2010/02.
5.2.1
The event and
action plan is provided in Appendix D.
5.2.2
The Action and Limit Levels for Chinese White Dolphin Monitoring are provided in Table 5.1a & Table 5.1b
Table 5.1a Action and Limit Levels for Chinese
White Dolphin Monitoring ¡V Approach to
Define
Action Level (
|
|
|
NEL |
NWL |
|
Action Level |
(STG < 70% of baseline) & (ANI < 70% of baseline) |
(STG < 70% of baseline) & (ANI < 70% of baseline) |
Limit Level |
[(STG < 40% of baseline) & (ANI < 40% of baseline)] AND [(STG < 40% of baseline) & (ANI < 40% of baseline)] |
For North Lantau Social Cluster, action level
will be trigger if either NEL or NWL fall below the criteria; limit level will
be triggered if both NEL and NWL fall below the criteria.
Table 5.1b Derived Value of
Action Level (
Dolphin
Monitoring
|
|
|
NEL |
NWL |
|
Action Level |
(STG < 4.2) & (ANI < 15.5) |
(STG < 6.9) & (ANI < 31.3) |
Limit Level |
[(STG < 2.4) & (ANI < 8.9)] AND [(STG
< 3.9) & (ANI < 17.9)] |
5.2.3 If exceedance(s) at these transects
is/are recorded by the ET of the Contract or referred by the other ET under the
HZMB project to the Contract, the ET of the Contract will carry out an
investigation and findings will be reported in the monthly EM&A Report.
5.3
Monitoring Result
The dolphin survey results for all transects are reported in the monthly
EM&A Reports prepared for Contract No. HY/2010/02.
6 ENVIRONMENTAL
SITE INSPECTION AND AUDIT
6. 1 Site
Inspection
6.1.1 Site Inspections were carried out on a weekly
basis to monitor the implementation of proper environmental pollution control
mitigation measures for the project. During the reporting period, site
inspections were carried out on 01, 09, 15, 22 & 29 December 2016.
6.1.2 Particular observations during
the site inspections are described below:
24 November 2016
(a)
No label for temporary storage of C & D wastes was observed at
Portion A. Label for temporary storage of C & D
wastes was provided at Portion A. The
observation was closed on 01 December 2016.
01 December 2016
(a)
Muddy
water was found accumulated on the road between vehicle washing facility and
exit. Muddy water was cleared on the road
between vehicle washing facility and exit. The
observation was closed on 09 December 2016.
09 December 2016
(a)
C
& D materials mixed with general refuse was observed at Portion A. C
& D materials and general refuse was sorted at Portion A. The
observation was closed on 15 December 2016.
(b)
Mud / Soil was observed on the
road side near the site exit. Mud / Soil was cleaned on the road side near the site exit. The
observation was closed on 15 December 2016.
15 December 2016
(a)
No observation was made during this site
inspection.
22 December 2016
(a)
Oil
container without drip tray was observed at Portion F. Oil container was
removed at Portion F. The observation was closed on 29 December 2016.
(b)
Improper
storage of C & D materials was observed at Portion I. C & D materials
was collected at Portion I. The observation was closed on 29 December 2016.
(c)
Pulverized
soil without impervious cover was observed at Portion I. Impervious cover was
provided at Portion I. The observation was closed on 29 December 2016.
29 December 2016
(a)
Improper
disposal of general refuses was observed at Portion A. Follow-actions for outstanding
observation will be inspected during the next site inspection.
(b)
Improper
disposal of general refuses was observed at Portion D. Follow-actions
for outstanding observation will be inspected during the next site inspection.
6. 2 Advice on
the Solid and Liquid Waste Management Status
6.2.1 The Contractor
registered as a chemical waste producer for the Contract. Sufficient numbers of
receptacles were available for general refuse collection and sorting.
6.2.2 There was no excavated marine sediment generated in this reporting
period. The excavated marine sediment was stored
properly on site during this reporting period until further instruction by the
Engineer. The disposal of excavated sediment as per EP-353/2009/K to be
implemented subject to confirmation.
6.2.3 Disposal of Marine
Sediment
6.2.3.1 For the marine sediment disposal, after the
acceptance of the review of the approved Sediment Quality Report (SQR) for this
Project under EPD letter dated 19 August 2015, an approval to dispose the
marine sediment extracted from bored piling for this Project was then approved
under memo from Secretary, Marine Fill Committee of CEDD dated 20 August 2015
for the disposal of marine sediment extracted from bored piling works. The
disposal sites allocated to this Project are the Mud Pit CMP2 of the Confined
Marine Sediment Disposal Facility to the South of The Brothers (or at the East
of Sha Chau). As advised by CEDD in the memo dated 19 February 2016, from 00:00
on 22 March 2016 onward, the disposal space at CMP2 of the South of The
Brothers is closed and all disposal of contaminated sediment is to be carried
out at CMP Vd to the East of Sha Chau (ESC). As a practical means, the disposal
operation is managed by one contractor who is also responsible for applying
dumping permit and its subsequent extension applications from EPD. Contract No.
HY/2013/03 has been assigned to coordinate and arrange for disposal of
extracted marine sediment from Contract No. HY/2013/02, HY/2013/03 and HY/2013/04.
6.2.3.2 For the dumping arrangement, the barge for
disposal of marine sediment will moor at the temporary loading and unloading at
the east shore of the
6.2.3.3 During dumping, HY/2013/02 is responsible
for transporting the marine sediment from his site area to the barge by Land
transportation. The estimated quantity of marine sediment in each truck is
confirmed by Resident Site Staff of each Contract.
The trip tickets for transportation and disposal of marine sediment are
collected and checked. Contract No. HY/2013/03 as the dumping permit holder
(EP/MD/17-132 in this reporting period) is responsible for reporting to EPD
the quantity disposed of as the condition stipulated in the dumping permit.
6.2.4 There
were 1568 m3 marine sediment extracted from bored piling in this Contract disposed to allocated
dumping site via Contract No. HY/2013/03 in this
reporting period. The
quantity disposed up to end of December 2016 was 18520 m3. The Monthly Summary of Marine sediment disposed to
dumping site was provided in Appendix E and Table 6.1.
Table 6.1 Summary of marine sediment
disposed to dumping site via Contract No.
HY/2013/03
Month/Year |
Quantity disposed (m3) |
January
2016 |
1272 |
February 2016 |
2816 |
March
2016 |
600 |
April
2016 |
5128 |
May
2016 |
0 |
June
2016 |
1200 |
July
2016 |
728 |
August
2016 |
1784 |
September
2016 |
2328 |
October
2016 |
1096 |
November
2016 |
0 |
December
2016 |
1568 |
Total = |
18520 |
6.2.5 The Contractor shall ensure no spilling and
overflowing of materials during loading / unloading / transportation is
allowed.
6.2.6 The monthly
summary of waste flow table is detailed in Appendix E.
6.2.7 The Contractor was reminded that chemical waste containers should be
properly treated and stored temporarily in designated chemical waste storage
area on site in accordance with the Code of Practice on the Packing, Labelling
and Storage of Chemical Waste.
6.3 Environmental Licenses and
Permits
The valid
environmental licenses and permits during the reporting period are summarized
in Appendix F.
6.4 Implementation Status of Environmental Mitigation
Measures
6.4.1 In response to the site audit findings, the Contractor carried out
corrective actions.
6.4.2 The Contractor waters 8 times per day on all exposed soil within the
project site and associated works areas when construction activities are being
undertaken.
6.4.3 The Contractor was reminded to provide well-maintained
plant operated on-site and plant served regularly;
6.4.4 The Contractor was reminded to switch off vehicles and
equipment while not in use;
6.4.5 The Contractor was reminded to schedule the construction
works to minimize noise nuisance etc.
6.4.6 The implementation status of Regular Marine Travel Route Plan (RMTRP)
was checked by ET. Training material of Regular Marine Travel
Route Plan was prepared and given to relevant staff. Those records were kept
properly. Since the marine delivery of precast segments was commenced and the
RMTRP training was provided for the Captain on 21
July 2016, the Captain was reminded to use regular travel routes in order to minimize the chance of vessel
collision and the routes would not go through the
dolphin hotspot in
6.4.7 The tool box training of dolphin was carried out in Dec 2015. According
to the action plan and communication flow chart of dolphin instruction, if any
dolphin intruded BCF perimeter silt curtain, ETL should be informed. There was
no notification received on any dolphin intrusion during the reporting period.
6.4.8 A summary of the implementation Schedule of Environmental Mitigation
Measures (EMIS) is presented in Appendix G. Most of the necessary
mitigation measures were implemented properly.
6.5 Summary of
Exceedance of the Environmental Quality Performance Limit
6.5.1 Summary of
Action and Limit Level exceedance of 1-hr TSP level and 24-hr TSP level at AMS6
shall be referred to the monthly EM&A report prepared by Contract No. HY/2011/03.
6.5.2 There was no Action and Limit Level exceedance
of 1-hr TSP level and 24-hr TSP level
recorded at station AMS7 by the Environmental Team of Contract No. HY/2010/02 during the reporting period.
6.5.3 There was no Action and Limit Level exceedance
for noise recorded at
station NMS2 and station NMS3B by the Environmental Team of Contract No.
HY/2010/02 during the reporting period.
6.5.4 There were one Action Level exceedance of SS on impact water quality monitoring at station IS(Mf)9 during mid-flood tide recorded on 14 December 2016. After investigation, there was concluded that the exceedance was not relevant to this Contract since
there was no marine works or barge of this Contract worked at HKBCF
reclamation site near the sea area or area near the monitoring station IS(Mf)9 from 01 December
2016 to the water quality monitoring period at 07:51 on 14 December 2016 which
was unlikely to generate suspended solids in the marine water. Therefore, it is
unlikely that the SS exceedance recorded at IS(Mf)9 during mid-flood
tide on 14 December 2016 was contributed by the works under Contract No.
HY/2013/02. There was no
Action and Limit Level
exceedance recorded on other monitoring
date at the monitoring stations showed in Table 4.1 by
the Environmental Team of Contract No. HY/2010/02 during the reporting period. The Investigation Report (including the causes of exceedance, action
taken and recommendation for mitigation) Action or Limit Level Non-compliance was prepared by the ET of Contract of HY/2010/02
and detailed in the monthly EM&A Report prepared for Contract No.
HY/2010/02. Although the
exceedance was not relevant to this
Contract, the Contractor was reminded
to ensure that the maintenance of perimeter silt curtains with respect to the
work boundary of this Contract carried out by the Contractor of Contract No.
HY/2010/02 are maintained properly.
6.5.5 Impact dolphin monitoring results at all transects are reported in the EM&A Reports
prepared for Contract No. HY/2010/02.
6.6
Summary of
Complaints, Notification of Summons and Successful Prosecution
6.6.1
There were four complaints received
during the reporting period.
1.
One complaint was received by EPD from
public on 01 December 2016 and was forwarded by EPD to the HYD and ENPO and
then to the R.E. (AECOM) on 01 December 2016.Then the R.E. (AECOM) forwarded
the complaint by email to the Contractor (
2.
One complaint was received by Contract No.
HY/2010/02 referred by the Government¡¦s Hotline (1823) on 02 December 2016 and
was forwarded by ENPO to the R.E. (AECOM), the Contractor (
3.
One complaint was received by EPD on 13 December
2016 and referred by EPD to the ENPO on 14 December 2016. Then the ENPO
forwarded the complaint by email to the R.E. (AECOM), the Contractor (
4.
One
complaint was received by Highways Department and referred by Highways
Department to Contract No. HY/2010/02 on 28 December 2016. Then the ENPO
forwarded the complaint by email to the R.E. (AECOM), the Contractor (
6.6.2
The follow-up inspections for the above
mentioned complaints on 01, 02 13 December 2016 were performed by the ET of
Contract No. HY/2013/02 on 02 and 15 December 2016.
The complaint investigation reports (Log No. 006, 007 and 008) were issued by
the ET of Contract No. HY/2013/02 and verified by the IEC/ENPO on 14, 16 and 19
December 2016. The follow-up inspection for the above mentioned complaint on 28
December 2016 was performed by the ET of Contract No. HY/2013/02 on 29
December 2016. The complaint investigation report (Log No. 009)
was issued by the ET of Contract No. HY/2013/02 on 31 December 2016 which is still
under review with the IEC/ENPO and will be followed in the
EM&A Report of January 2017.
6.6.3
According to the investigation, after checked
for the Contract No. HY/2013/02, no mud/slurry was observed around the East
Coast Road site entrance during the site inspection and audit on 01 December
2016, no stone debris and mud/slurry were observed around the East Coast Road
site entrance according to the Contractor and RE¡¦s site checking on 02 December
2016 and the construction works of this Contract during the past month was
carried out from 08:00 up to 23:00 and no any works and PME operation were
undertaken at night-time after 23:00 until 13
December 2016 by Contract No. HY/2013/02.
The complaints were found non-related to Contract No. HY/2013/02. The complaint
investigation reports (Log No. 006, 007 and 008) for
the above mentioned complaints on 01, 02 and 13 December 2016 were
provided in Appendix J.
6.6.4
Although the complaints were
non-related to Contract No. HY/2013/02, the Contractor of Contract No.
HY/2013/02 was reminded to provide appropriate mitigation measures such as:
1.
To check the
2.
To clean up the mud/slurry immediately to avoid public nuisance no
matter the mud/slurry was generated from them or not once received the
complaint of the location which specified within Contract No. HY/2013/02¡¦s site
boundary at portion I;
3.
To provide one person stayed at the site entrance
during working hours for cleaning up the mud/slurry;
4.
Provide well-maintained plant operated on-site and
plant served regularly;
5.
Switched off vehicles and equipment while not in
use;
6.
Scheduled the construction works to minimize noise
nuisance;
7.
Avoid to use hammering equipment during any night
works; and
8.
Comply with the valid CNP for overnight operation.
6.6.5
There were no notifications of summons
or prosecutions received during the reporting period.
6.6.6
Statistics on
environmental complaints,
notifications of summons and successful prosecutions are summarized in Appendix H.
7.1 Construction
Programme for the Coming Months
7.1.1 As informed by the Contractor, the major construction activities
for January 2017 are summarized in Table 7.1.
Table 7.1 Construction Activities for Coming Month
Site Area |
Description of Activities |
Portion
C & F |
Pier / Abutment |
Pile Cap |
|
Pre-bored H-pile for sign gantries |
|
Portion
D, A, E, C & F |
Marine delivery of precast segment
& Construction of bridge deck |
|
Footing construction of directional
signs and dust laying |
|
Storm drain and water main construction |
|
Retaining wall, slop and earth works |
|
Marine sediment
excavation activities from the land-based works and corresponding disposal at the
designated disposal sites |
7.2 Environmental
Site Inspection Schedule for the Coming Month
7.2.1 The tentative schedule for weekly site inspections for January 2017 is
provided in Appendix I.
8.1 Conclusions
8.1.1 The
site preparation work of the Contract was started on 25 July 2014 and the
construction works of the Contract commenced on 24 November 2014.
8.1.2 Summary of
Action and Limit Level exceedance of 1-hr TSP level and 24-hr TSP level at AMS6
shall be referred to the monthly EM&A report prepared by Contract No.
HY/2011/03.
8.1.3 There was no Action and Limit Level
exceedance of 1-hr TSP level and 24-hr TSP
level recorded at station AMS7 by the Environmental Team of Contract
No. HY/2010/02 during the reporting period.
8.1.4 There was no
Action and Limit Level
exceedance for noise recorded
at station NMS2 and station NMS3B by the Environmental Team of Contract No.
HY/2010/02 during the reporting period.
8.1.5
There were
one Action Level exceedance of SS on impact water quality monitoring at station IS(Mf)9 during mid-flood tide recorded on 14 December 2016. After investigation, there was concluded that the exceedance was not relevant to this Contract since
there was no marine works or barge of this Contract worked at HKBCF
reclamation site near the sea area or area near the monitoring station IS(Mf)9 from 01 December
2016 to the water quality monitoring period at 07:51 on 14 December 2016 which
was unlikely to generate suspended solids in the marine water. Therefore, it is
unlikely that the SS exceedance recorded at IS(Mf)9 during mid-flood
tide on 14 December 2016 was contributed by the works under Contract No.
HY/2013/02. There was no
Action and Limit Level
exceedance recorded on other monitoring
date at the monitoring stations showed in Table 4.1 by
the Environmental Team of Contract No. HY/2010/02 during the reporting period. The Investigation Report (including the causes of exceedance, action
taken and recommendation for mitigation) Action or Limit Level Non-compliance was prepared by the ET of Contract of HY/2010/02
and detailed in the monthly EM&A Report prepared for Contract No.
HY/2010/02. Although the
exceedance was not relevant to this
Contract, the Contractor was reminded
to ensure that maintenance of perimeter silt curtains with respect to the work
boundary of this Contract carried out by the Contractor
of Contract No. HY/2010/02 are maintained properly.
8.1.6 Impact dolphin monitoring results at all transects are reported in the EM&A Reports
prepared for Contract No. HY/2010/02.
8.1.7
There were four complaints received
during the reporting period.
1.
One complaint was received by EPD from
public on 01 December 2016 and was forwarded by EPD to the HYD and ENPO and
then to the R.E. (AECOM) on 01 December 2016.Then the R.E. (AECOM) forwarded
the complaint by email to the Contractor (
2.
One complaint was received by Contract No.
HY/2010/02 referred by the Government¡¦s Hotline (1823) on 02 December 2016 and
was forwarded by ENPO to the R.E. (AECOM), the Contractor (
3.
One complaint was received by EPD on 13 December
2016 and referred by EPD to the ENPO on 14 December 2016. Then the ENPO
forwarded the complaint by email to the R.E. (AECOM), the Contractor (
4.
One complaint was received by Highways Department and referred by
Highways Department to Contract No. HY/2010/02 on 28 December 2016. Then the
ENPO forwarded the complaint by email to the R.E. (AECOM), the Contractor (
After the
investigation, the complaints on 01, 02 and 13 December 2016
were found non-related to Contract No. HY/2013/02. The complaint investigation
reports (Log No. 006, 007 and 008) were issued by
the ET of Contract No. HY/2013/02 and verified by the IEC/ENPO on 14, 16 and 19
December 2016.which were provided in Appendix J. The complaint investigation report (Log
No. 009) was issued by the ET of Contract No. HY/2013/02 on 31 December 2016
which is still under review with the IEC/ENPO and will be followed in
the EM&A Report of January 2017.
8.1.8
There were no notifications of summons or
prosecutions received during the
reporting period.
- END OF REPORT -
